Antenna Experts ADY-150 User & Installation Manual

INSTALLATION MANUAL – VHF DUAL YAGI ANTENNA
NOTICE:
Installation, maintenance or dismounting of the antenna system requires qualified and
experienced personnel. Antenna Experts antenna Installation instructions have been
prepared and are meant for skilled personnel only.
Antenna Experts disclaims any liability or responsibility as a result of improper or unsafe
installation practices.

MATERIALS:

Following materials are used for the fabrication of Antennas and its accessories.
Yagi Boom and Elements:
Stacking Pipe:
Mounting Hardware:
Fasteners:
Connector:
Insulator:
Housing:

PACKING LIST:

Sl. No.
01. Yagi Antenna
Accessories for each Yagi antenna
(a). Main Boom Square Section.
(b). Reflector Element.
(c). Dipole complete with Feed.
(d). Directors 1- 4.
(e). Mounting Clamp Square Boom-to-Horizontal cross
member (fixed on Square Boom).
02. Phasing Harness Cable complete with connectors.
03. Horizontal cross member, 1.5 Inch O.D., 9 feet long
Aluminum tube in two sections.
04. Mounting clamps for Horizontal cross member to
Vertical Mast suitable for 2 Inch Outer Dia tube.
05. Cable ties for dressing the Phasing Harness Cable
06. Installation Instruction.
07. Test Report.
ANTENNA EXPERTS
E-mail: info@antennaexperts.in
Model ADY-150
6063T6 Aluminum.
6063T6 Aluminum.
All stainless steel.
All Stainless Steel.
Silver Plated Brass body & Gold plated pin.
TEFLON.
NYLON
ITEM/DESCRIPTIONS
Website: www.antennaexperts.in
134 – 174 MHz. 15dBi Gain
QUANTITY
2 Nos.
1 Each.
1 Each.
1 Each
4 Nos.
1 Each.
1 Each.
1 Each.
2 Nos.
10 Nos.
1 Each.
1 Each.
