Antenna Experts AC9-150 Installation Manual

ANTENNA EXPERTS
E-mail:
Model # AC9-150
FIBERGLASS COLLINEAR ANTENNA – INSTALLATION MANUAL
NOTICE:
Installation, maintenance or dismounting of the antenna system requires qualified and
experienced personnel. Antenna Experts antenna Installation instructions have been prepared
and are meant for skilled personnel only.
Antenna Experts disclaims any liability or responsibility as a result of improper or unsafe
installation practices.

MATERIALS:

Following materials are used for the fabrication of Antennas and its accessories.
Support Pipe:
Radiating Elements:
Radome:
Mounting Hardware:
Fasteners:
Connector:
Insulator:

PACKING LIST:

Sl. No.
1. Antenna Fiberglass Collinear in two (Upper and Lower) sections.
2. LOWER SUPPORT - Grounded Mounting Assembly with 1.5 Inch diameter,
4.5 Feet long Aluminum Pipe fitted with Three crossover plate clamps set.
3. UPPER SUPPORT - Insulated Mounting Assembly with 1.5 Inch diameter,
4.5 Feet long Nylon Rod fitted with Three crossover plate clamps set.
4. Installation Manual.
5. Test Report.

INSTALLATION INSTRUCTIONS:

1. The antenna is supplied in two sections for ease of handling and shipping.
2. Unpack the Collinear antenna and mounting hardware from the packing box and
remove the plastic sleeve/tube from the fiberglass enclosure.
3. A serial number sticker is provided at the bottom of lower section and the top of upper
section of each antenna. Before attempting to assemble an antenna, make sure that the
lower and upper sections of the antenna bear the same serial number markings on both
lower and upper sections of the antenna.
info@antennaexperts.in
6063T6 Aluminum.
Brass
Fiberglass
All Stainless Steel.
All Stainless Steel.
Silver-plated brass body & Gold plated pin.
Nylon.
ITEM/DESCRIPTION
Website:
www.antennaexperts.in
136 – 174 MHz. 9 dBi. Gain
QUANTITY
1 Each.
2 Nos.
1 Each.
1 Each.
1 Each.
