Panasonic CZ-CAPZ1S Installation Instructions Manual

Safety Precautions

Please Read Before Starting
●This Zone Control Box must be installed by the sales dealer or installer.
This information is provided for use only by authorized.
● These instructions are all you need for most installation sites and main-
tenance conditions. If you require help for a special problem, contact our
sales/service outlet or your certifi ed dealer for additional instructions.
● We assume no responsibility for accidents or damages resulting from
methods other than those described in the Installation Instructions or meth-
ods using unspecifi ed parts. Malfunctions that occur due to unauthorised
installation methods are not covered by the product warranty.
● Zone Control Box must be installed in accordance with National Wiring Regulations.
●When relocating or repairing Zone Control Box, provide the Installation
Instructions to the servicing personnel.
● Please provide this Installation Instructions to the user after installation.
Instruct user to keep it in a safe place along with the air conditioner instruc-
tion manuals.
Electrical shock can cause severe
personal injury or death.
Only a qualifi ed, experienced electrician
should attempt to wire this system.
 Highly dangerous electrical voltages are used in
this system. Carefully refer to the wiring diagram
and these instructions when wiring. Improper
connections and inadequate grounding can cause
accidental injury or death.
 Zone Control Box is strongly recommended to be
installed with Earth Leakage Circuit Breaker (ELCB) or
Residual Current Device (RCD). Otherwise, it may cause
electrical shock and fi re in case of equipment breakdown
or insulation breakdown. Earth Leakage Circuit Breaker
(ELCB) must be incorporated in the fi xed wiring in
accordance with the wiring regulations. The Earth
Leakage Circuit Breaker (ELCB) must be an approved
10 A, having a contact separation by 3 mm in all poles.
 To reduce the risk of electric shock, smoke, or fi re, install
a circuit breaker and earth leakage protective device.
 Turn off the circuit breaker of the units before
installation or servicing.
 Provide a power outlet to be used exclusively for
Zone Control Box.
 Do not supply power to the unit until all wiring is
completed or reconnected and checked.
1006 Kadoma, Kadoma City, Osaka, Japan
https://eu.datanavi.ac.smartcloud.panasonic.com/documents/
●The product meets the technical requirements of EN/IEC 61000-3-3.
●This product is intended for professional use.Permission from the power
●Read the Installation Instructions supplied with indoor units and outdoor
WARNING
 To prevent possible hazards from insulation
 Do not set up in hospitals or places where
 Zone Control Box must be securely installed in
 Use only the parts specifi ed by Panasonic as
 Select an installation location which is rigid and
 No disassembly or modifi cation of this Zone
 Electric work must be performed by authorised
 Terminal block cover panel of the Zone Control
 Do not operate with wet hands.
 In case of an abnormal condition (such as a
 When installing the Zone Control Box, use
Installation Instructions
Zone Control Box
Model No.
supplier is required when installing the CZ-CAPZ1S , CZ-CAPZ1M that
is connected to a 16 A distribution network.
units as well.
This symbol refers to a hazard or unsafe
practice which can result in severe
personal injury or death.
This symbol refers to a hazard or unsafe
practice which can result in personal injury
or product or property damage.
Prohibited matters
failure, the unit must be grounded.
electronic medical devices are located.
accordance with the Installation Instructions.
supplied accessories.
strong enough to support or hold Zone Control
Box, and select a location for easy maintenance.
Control Box is allowed under any circumstances.
personnel in accordance with the local
regulations and the instructions detailed in the
Installation Instructions.
Box must be fi rmly fi xed. If the cover panel is
mounted improperly, dust and moisture may
enter the Zone Control Box, and it may cause
electric shock or fi re.
burning smell),turn the breaker OFF.
appropriate protective equipment and tools for safety.
CZ-CAPZ1S
CZ-CAPZ1M
ACXF60-43611
W0321-20921
