Page 5 WELCOME Thank you for purchasing a POLARIS vehicle, and welcome to our world-wide family of POLARIS enthusiasts. Be sure to visit us online at www.polaris.com for the latest news, new product introductions, upcoming events, career opportunities and more. Here at POLARIS we proudly produce an exciting line of utility and recreational products.
Page 6 SAFETY SYMBOLS AND SIGNAL WORDS The following signal words and symbols appear throughout this manual and on your vehicle. Your safety is involved when these words and symbols are used. Become familiar with their meanings before reading the manual. DANGER DANGER indicates a hazardous situation which, if not avoided, WILL result in death or serious injury.
Page 7 Specifications ....209 POLARIS Products ....217 Troubleshooting ....219 Warranty .
Page 9 WARNING Failure to heed the warnings and safety precautions contained in this manual can result in severe injury or death. A POLARIS ATV is not a toy and can be hazardous to operate. This vehicle handles differently than other vehicles, such as motorcycles and cars.
Page 10: Vehicle Identification Numbers
An ignition key can be duplicated only by ordering a POLARIS key blank and mating it with one of your existing keys. The ignition switch must be replaced if all keys are lost.
Page 11: Radio Compliance Statements
COMPONENT COMPONENT ID MANUFACTURER B1 Gauge TT-B1B Polaris Industries Inc. Ride Command RC-7W RC-7W Polaris Industries Inc. Display This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 12 For applications that use vehicle-to-vehicle (V2V) communication, radio transmitter IC 5966A-RC7W has been approved by Innovation, Science and Economic Development Canada (ISED) to operate with Polaris antenna (part number 4080356) with gain of 3 dBi. Any antenna that has a gain greater than 3 dBi is prohibited for use with this device.
Page 13: Safety Training
You should review this information on a regular basis. If you purchased a used POLARIS ATV in the United States, you can enroll in the ATV RiderCourse℠ for a fee. Call ATV Enrollment Express at 1-800-887-2887 or visit www.atvsafety.org. If you purchased a POLARIS ATV outside the United States, please contact your dealer or local law enforcement agencies, or visit www.polaris.com for information about safety training.
Page 14: Eye Protection
HELMET Wearing a helmet can prevent a severe head injury. Whenever riding this POLARIS vehicle, always wear a helmet that meets or exceeds established safety standards. Clasp the buckle and pull each strap tight to ensure the helmet is properly secured to the head.
Page 15: Safety Warnings
SAFETY SAFETY WARNINGS WARNING Failure to operate this vehicle properly can result in a collision, loss of control, accident or rollover, which may result in serious injury or death. Heed all safety warnings outlined in this section of the owner’s manual. See the operation section of this owner’s manual for proper operating procedures.
Page 16: Using Alcohol Or Drugs
SAFETY USING ALCOHOL OR DRUGS Never consume alcohol or drugs before or while operating this vehicle. Operating this vehicle after consuming alcohol or drugs could adversely affect operator judgment, reaction time, balance and perception. CARRYING MORE THAN ONE PASSENGER ON A 2-UP ATV Carrying more than one passenger on a 2-up ATV greatly reduces the operator's ability to balance and control the ATV, which may...
Page 17: Handling Gasoline
SAFETY HANDLING GASOLINE Gasoline is highly flammable and explosive under certain conditions. • Always exercise extreme caution whenever handling gasoline. • Always refuel with the engine stopped, and outdoors or in a well ventilated area. • Never carry fuel or other flammable liquids on this vehicle. Failure to follow this instruction could lead to serious burn injuries or death.
Page 18: Operating On Pavement
SAFETY OPERATING ON PAVEMENT This vehicle's tires are designed for off-road use only, not for use on pavement. Operating this vehicle on paved surfaces (including sidewalks, paths, parking lots and driveways) may adversely affect the handling of the vehicle and may increase the risk of loss of control and accident or rollover.
Page 19: Physical Control Of The Vehicle
SAFETY PHYSICAL CONTROL OF THE VEHICLE Removing even one hand or foot can reduce ability to control the vehicle or could cause loss of balance and ejection from the ATV. If a person's feet are not firmly planted on the footrests, they could come into contact with the wheels or other moving parts and lead to accident or injury.
Page 20: Jumps And Stunts
SAFETY JUMPS AND STUNTS Exhibition driving increases the risk of an accident or rollover. DO NOT do power slides, “donuts”, jumps or other driving stunts. Avoid exhibition driving. IMPROPER HILL CLIMBING Improper hill climbing could cause loss of control or rollover. Use extreme caution when operating on hills.
Page 21: Stalling While Climbing A Hill
SAFETY STALLING WHILE CLIMBING A HILL Stalling, rolling backwards or improperly dismounting while climbing a hill could cause a rollover. • Always maintain a steady speed when climbing a hill. • Always engage ADC mode (if equipped) before ascending or descending a hill. If ADC mode is not equipped, apply AWD mode before ascending or descending a hill.
Page 22: Operating On Steep Hills
SAFETY OPERATING ON STEEP HILLS Operating on excessively steep hills could cause an overturn. Never operate on hills too steep for the ATV or for your abilities. Never operate this ATV on hills steeper than 15 degrees. OPERATING ON SLIPPERY TERRAIN Failure to use extra caution when operating on excessively rough, slippery or loose terrain could cause loss of traction, loss of...
Page 23: Improper Tire Maintenance
SAFETY IMPROPER TIRE MAINTENANCE Operating this vehicle with improper tires or with improper or uneven tire pressure could cause loss of control or accident. Always use the size and type of tires specified for your vehicle. Always maintain proper tire pressure as described in the owner's manual and on safety labels.
Page 24: Skidding Or Sliding
SAFETY SKIDDING OR SLIDING Failure to use extra caution when operating on excessively rough, slippery or loose terrain could cause loss of traction, loss of control, accident or rollover. Do not operate on excessively slippery surfaces. Always slow down and use additional caution when operating on slippery surfaces.
Page 25: Improper Cargo Loading
SAFETY IMPROPER CARGO LOADING Overloading the vehicle or carrying cargo improperly may cause changes in stability and handling, which could cause loss of control or an accident. • Always follow the instructions in this owner’s manual for carrying cargo. • Never exceed the stated load capacity for this vehicle. •...
Page 26: Hot Exhaust Systems
SAFETY HOT EXHAUST SYSTEMS WARNING Exhaust system components are very hot during and after use of the vehicle. Hot components can cause burns and fire. Do not touch hot exhaust system components. Always keep combustible materials away from the exhaust system.
Page 27: Equipment Modifications
SAFETY EQUIPMENT MODIFICATIONS Your POLARIS vehicle is designed to provide safe operation when used as directed. Modifications to your vehicle may negatively impact vehicle stability. Failure of critical machine components may result from operation with any modifications, especially those that increase speed or power. This vehicle may become less stable at speeds higher than those for which it is designed.
Page 28: Safety Labels And Locations
If an informational or graphic label becomes illegible or comes off, contact your POLARIS dealer to purchase a replacement. Replacement safety labels are provided by POLARIS at no charge. The part number is printed on the label. SPORTSMAN TOURING 570...
Page 29 SAFETY SPORTSMAN X2 570 Front Rack / Container Warning General Warning Passenger Safety Warning Age 16 Warning Reverse Override / AWD Warning Clutch Cover Warning Fuel Transport Warning Tire Pressure / Load Warning Passenger Warning...
Page 30 SAFETY SPORTSMAN 6X6 570 Front Rack / Container Warning General Warning Discretionary Warning Age 16 Warning Reverse Override / AWD Warning Clutch Cover Warning Fuel Transport Warning Tire Pressure / Load Warning Passenger Warning...
Page 31 SAFETY FRONT RACK / CONTAINER WARNING WARNING • DO NOT TOW FROM RACK OR BUMPER. Vehicle damage or tipover may result causing severe injury or death. Tow only from tow hooks or hitch. • Maximum Combined Front Rack and Container Load: 90 lbs (41 kg) Part Number: 7174201 REAR RACK WARNING (TOURING MODELS) WARNING...
Page 32 SAFETY WARNING • Never operate this ATV on HILLS steeper than 15 degrees. To prevent overturn on hilly terrain, use throttle and brakes gradually, and shift weight uphill. • REVERSE operation can be dangerous even at low speeds. Steering becomes difficult. To prevent loss of control, avoid sudden braking or sharp turns.
Page 33 SAFETY TIRE PRESSURE / LOAD WARNING (X2 MODELS) WARNING Improper tire pressure or overloading can cause loss of control. Loss of control can result in severe injury or death. • Cold tire pressure: – Front: 7.0 psi (48.3 kPa) – Rear: 7.0 psi (48.3 kPa) •...
Page 34: Age 16 Warning
SAFETY AGE 16 WARNING WARNING Operating this ATV if you are under the age of 16 increases the chances of severe injury or death to both operator and passenger. NEVER operate this vehicle if you are under age 16. Part Number: 7186124 GENERAL WARNING WARNING Improper use can result in SEVERE INJURY or DEATH...
Page 35: Clutch Cover Warning
SAFETY REVERSE OVERRIDE / AWD WARNING WARNING Improper use of override button can lead to loss of control resulting in severe injury or death. Do not activate override while throttle is engaged. Always apply throttle gradually, while in reverse. CAUTION Do not push switch to engage 4X4 (AWD) if the rear wheels are spinning.
Page 36 SAFETY PASSENGER WARNING (6X6 MODELS) WARNING • Passengers can be thrown off. This can cause serious injury or death. • Never carry passengers in the cargo box. WARNING Maximum Box Load: 800 lbs (363 kg) Part Number: 7301055 FUEL TRANSPORT WARNING WARNING NEVER carry fuel or other flammable liquids on this vehicle.
Page 37: Features And Controls
FEATURES AND CONTROLS FEATURES AND CONTROLS OVERVIEW NOTICE Image is for reference only. Your model might differ slightly. Ignition Switch Auxiliary Switch (if equipped) Engine Stop Switch Hand Warmer Switch (if equipped) Mode / Reverse Override Switch Thumb Warmer Switch (if equipped) Headlight Switch Brake Lever Throttle Lever...
Page 38: Ignition Switch
FEATURES AND CONTROLS IGNITION SWITCH Use the ignition switch to start the engine. The key can be removed from the switch when it is in the OFF position. NOTICE Image is for reference only. Your model might differ slightly. SWITCH FUNCTION POSITION Turn the key to the OFF position to stop the engine.
Page 39: Left-Hand Controls
FEATURES AND CONTROLS LEFT-HAND CONTROLS ENGINE STOP SWITCH Move the engine stop switch to the OFF position to stop the engine quickly. Move the engine stop switch to the RUN position before attempting to start the engine. The engine will not start or run when the switch is off.
Page 40: Right-Hand Controls
Operating an ATV with sticking or improperly operating throttle controls could cause an accident. Never start or operate an ATV that has a sticking or improperly operating throttle. Immediately contact your POLARIS dealer or other qualified person for service if throttle problems arise.
Page 41 FEATURES AND CONTROLS DRIVELINE SWITCH (ADC MODELS) (IF EQUIPPED) The All Wheel Drive (AWD) system is controlled by the Driveline Switch Use this switch to engage ADC, 4x4, or 2x4. The vehicle automatically engages AWD when operating in forward or reverse if the switch is set to 4x4.
Page 42: Performance Mode
FEATURES AND CONTROLS DRIVE MODE SWITCH (IF EQUIPPED) The Drive Mode Switch has three positions: • Performance (PERF) • Standard (STND) • Work (WORK) Always use low gear for any of the following conditions regardless of the selected throttle control setting. •...
Page 43: All Wheel Drive System
FEATURES AND CONTROLS ALL WHEEL DRIVE SYSTEM NOTICE Switching to AWD or ADC mode (if equipped) while the rear wheels are spinning may cause severe drive shaft and gearcase damage. Always switch to AWD or ADC mode (if equipped) while the rear wheels have traction or are at rest.
Page 44: Engaging Awd
FEATURES AND CONTROLS AWD MODE When the driveline switch is set to 4x4 or AWD, the ATV is in four-wheel drive, and the AWD indicator icon is visible on the digital display. When in AWD, the demand drive unit will automatically engage any time the rear wheels lose traction.
Page 45 FEATURES AND CONTROLS ALL WHEEL DRIVE SYSTEM Available on Ultimate, X2, and 6x6 Models The All Wheel Drive (AWD) system is controlled by the AWD Momentary Switch Engage AWD before getting into conditions where front wheel drive may be needed. If the rear wheels are spinning, release the throttle before switching to AWD mode.
Page 46 FEATURES AND CONTROLS 2X4 MODE To engage 2x4 mode, push the momentary switch to the left. AWD will disengage when engine speed slows to below 2800 RPM. The gauge will display “2x4.” AWD MODE To engage AWD mode, push the momentary switch to the right. AWD will engage when engine speed slows to below 2800 RPM.
Page 47: Active Descent Control (Adc) System
FEATURES AND CONTROLS ACTIVE DESCENT CONTROL (ADC) SYSTEM (IF EQUIPPED) The ADC system allows engine braking to all four wheels when the vehicle descends a hill or incline. Always move the 4x4 or AWD switch to ADC before ascending or descending a hill. ENGAGING ACTIVE DESCENT CONTROL The ADC system will automatically engage when all four of the following conditions occur:...
Page 48: Brake System
Any sponginess would indicate a possible fluid leak or low master cylinder fluid level, which must be corrected before riding. Contact your POLARIS dealer or other qualified service facility for proper diagnosis and repairs. MASTER CYLINDER/BRAKE FLUID WARNING An over-full master cylinder may cause brake drag or brake lock-up, which could result in an accident.
Page 49 FEATURES AND CONTROLS 4. If the fluid level is low, remove the cover screws and add fluid to the fill line. Do not overfill. Use DOT 4 brake fluid only. 5. Reinstall the cover. Torque screws to 7 in-lbs (1 N·m). WARNING Never store or use a partial bottle of brake fluid.
Page 50: Auxiliary Foot Brake
FEATURES AND CONTROLS AUXILIARY FOOT BRAKE WARNING Never back down a hill. Applying the auxiliary brake when backing down a hill may cause rear tipover, which could result in serious injury or death. Use caution when applying the auxiliary brake. Do not aggressively apply the auxiliary brake when going forward.
Page 51: Brake Fluid Level
FEATURES AND CONTROLS BRAKE FLUID LEVEL Check the brake fluid level frequently for the auxiliary brake system. The reservoir is located on the frame and can be accessed through the front right wheel well. Maintain the fluid level between the maximum and minimum marks. Use DOT 4 brake fluid only.
Page 52: Automatic Transmission Gear Selector
FEATURES AND CONTROLS AUTOMATIC TRANSMISSION GEAR SELECTOR The transmission gear selector is located on the right side of the vehicle. H: High Gear L: Low Gear N: Neutral R: Reverse P: Park To shift gears, brake to a complete stop. When the engine is idling, move the lever to the desired gear.
Page 53 FEATURES AND CONTROLS PASSENGER SEAT (X2 MODELS) Always make sure the passenger seat lock-out is functioning properly before operating with a passenger. Do not operate the vehicle with the seat in the 2-up position when operating without a passenger. Always return the seat to the 1-up position for single-rider operation.
Page 54 FEATURES AND CONTROLS 4. Pull the passenger backrest upward from the bed of the cargo box.
Page 55 FEATURES AND CONTROLS 5. Lift the adjustment latch at the top of the passenger backrest. Raise the backrest to the desired position. Release the latch, making sure it locks into one of the three operating positions. The backrest must be moved out of the lowest position before it can be secured in the upright position.
Page 56 If the dump latch releases, the seat is not secure. Repeat the set-up procedure. If the lock-out is not working properly, do not allow a passenger to ride the vehicle. See your POLARIS dealer for service. 8. To return the vehicle to single-rider operation, reverse all steps. Always lower the passenger backrest to the lowest position before folding it down into the cargo box.
Page 57: Instrument Cluster
FEATURES AND CONTROLS INSTRUMENT CLUSTER NOTICE Features vary by model. Refer to the Ride Command chapter for more information about the Ride Command display. Your vehicle is equipped with one of four available gauge variants, (1) a standard gauge (no Bluetooth® functionality), (2) a Bluetooth®-equipped gauge, (3) a no-button gauge, or (4) a 7”...
Page 58 All segments including the fuel icon will flash. Refuel immediately. A flashing wrench symbol alerts the operator that the Service preset service interval has been reached. Your POLARIS Indicator dealer can provide scheduled maintenance. See page 74 for more information.
Page 59: Indicator Lamps
EPS Warning (if This indicator illuminates when a fault equipped) has occurred in the EPS system. Your authorized POLARIS dealer can assist. EPS operation is possible with key on/engine off for up to 5 minutes. Engine Hot This lamp illuminates to indicate an overheated engine.
Page 60 FEATURES AND CONTROLS NO BUTTON GAUGE Some Sportsman models are equipped with a no-button gauge. This gauge style does not come equipped with a clock feature. Other available features may vary. To toggle through available features, press Reverse Override / Mode Button from the left hand controls.
Page 61: Display Area
FEATURES AND CONTROLS DISPLAY AREA 1 Pressing the MODE button will change the information displayed in Area 1 DISPLAY AREA 1 FUNCTION Speed The vehicle’s speed will be displayed in mph, or km/h. Engine The vehicle’s current engine temperature will be Temperature displayed.
Page 62 FEATURES AND CONTROLS DISPLAY AREA 2 Toggle the Up/Down buttons to change the information displayed in Area 2 DISPLAY AREA 2 FUNCTION Odometer The vehicle’s odometer reading will be displayed. Engine The vehicle Engine Temperature will be displayed. Temperature Trip 1 The vehicle Trip 1 mileage will be displayed.
Page 63: Options Menu
FEATURES AND CONTROLS OPTIONS MENU From the options menu you can view diagnostic codes, access the advanced menu, set the clock, and much more. For a full list of available options see below. To enter the Options Menu, press and hold the MODE button.
Page 64: Diagnostic Code
FEATURES AND CONTROLS DIAGNOSTIC CODE Diagnostic Code Screen will show available MIL that has come on during that ignition cycle. To access the Diagnostic Code Screen, do the following: 1. Press and hold the MODE button to enter the Options Menu.
Page 65: Advanced Menu
FEATURES AND CONTROLS NOTICE When the gauge is displaying a fault code, the warning telltale (check engine or EPS) will blink to indicate which controller set the fault code. 3. To exit the Options Menu the user can select Exit Menu function from Options Menu, can hold Mode Button and exit out of Options Menu, or not press any button for 10 seconds, which will exit out of the Options Menu.
Page 66 FEATURES AND CONTROLS MAXIMUM SPEED (IF EQUIPPED) 1. Press and hold the MODE button to enter the Options Menu. NOTICE “OPTIONS” will display on the screen for 3 seconds before showing first menu item. 2. Select “ADVANCED MENU” by pressing the MODE Button. 3.
Page 67 FEATURES AND CONTROLS GEOFENCING (IF EQUIPPED) Before you can use the geofencing features, you must first download the POLARIS Ride Command app from the Apple App Store® or Google Play® and create an account. Enabling and disabling a geofence, as well as changing...
Page 68 FEATURES AND CONTROLS INSIDE GEOFENCE SPEED 1. Press and hold the MODE button to enter the Options Menu. NOTICE “OPTIONS” will display on the screen for 3 seconds before showing first menu item. 2. Select “ADVANCED MENU” by pressing the MODE button. 3.
Page 69 FEATURES AND CONTROLS OUTSIDE GEOFENCE SPEED 1. Press and hold the MODE button to enter the Options Menu. NOTICE “OPTIONS” will display on the screen for 3 seconds before showing first menu item. 2. Select “ADVANCED MENU” by pressing the MODE button. 3.
Page 70: Change Pin
FEATURES AND CONTROLS CHANGE PIN 1. Press and hold the MODE button to enter the Options Menu. NOTICE “OPTIONS” will display on the screen for 3 seconds before showing first menu item. 2. Select “ADVANCED MENU” by pressing the MODE button. 3.
Page 71: Unit Selection Distance
FEATURES AND CONTROLS UNIT SELECTION DISTANCE 1. Press and hold the MODE button to enter the Options Menu. NOTICE “OPTIONS” will display on the screen for 3 seconds before showing first menu item. 2. Select “Units-Distance” from the Options Menu by pressing the MODE button.
Page 72: Unit Selection Temperature
FEATURES AND CONTROLS UNIT SELECTION TEMPERATURE 1. Press and hold the MODE button to enter the Options Menu. NOTICE “OPTIONS” will display on the screen for 3 seconds before showing first menu item. 2. Select “Units - Temp” from the Options Menu by pressing the MODE button. Reference the image shown above: Press the MODE button.
Page 73 FEATURES AND CONTROLS CLOCK (IF EQUIPPED) 1. Press and hold the MODE button to enter the Options Menu. NOTICE “OPTIONS” will display on the screen for 3 seconds before showing first menu item. 2. Select “Clock” from the Options Menu by pressing the MODE button. Reference the image shown above: Press the MODE button.
Page 74: Back Light Color
FEATURES AND CONTROLS BACK LIGHT COLOR 1. Press and hold the MODE button to enter the Options Menu. NOTICE “OPTIONS” will display on the screen for 3 seconds before showing first menu item. 2. Select “Backlight Color” from the Options Menu by pressing the MODE button.
Page 75: Back Light Level
FEATURES AND CONTROLS BACK LIGHT LEVEL 1. Press and hold the MODE button to enter the Options Menu. NOTICE “OPTIONS” will display on the screen for 3 seconds before showing first menu item. 2. Select “Backlight Level” from the Options Menu by pressing the MODE button.
Page 76: Service Hours
FEATURES AND CONTROLS SERVICE HOURS 1. Press and hold the MODE button to enter the Options Menu. NOTICE “OPTIONS” will display on the screen for 3 seconds before showing first menu item. 2. Select “Service Hours” from the Options Menu by pressing the MODE button. Reference the image shown above: Press the MODE button.
Page 77 FEATURES AND CONTROLS ELECTRONIC POWER STEERING (EPS) (IF EQUIPPED) Electronic power steering (EPS), if equipped, engages when the ignition key is turned to the ON position. EPS remains engaged whether the vehicle is moving or idle. See the Instrument Cluster section for EPS Warning Indicator information.
Page 78: Auxiliary Outlet
FEATURES AND CONTROLS AUXILIARY OUTLET A 12-volt accessory outlet is located on the pod. Use the outlet to power an auxiliary light or other optional accessories or lights. FUEL CAP This vehicle is equipped with a digital fuel gauge that will indicate a low fuel condition.
Page 79 FEATURES AND CONTROLS BATTERY CHARGE PORT Your vehicle is equipped with a battery charge port . The battery charge port allows you to quickly and easily connect a battery charger or maintainer to your vehicle’s battery. For more information see page 198. NOTICE Image is for reference only.
Page 81: Before You Ride
Be aware of all applicable local laws that may affect the use of electronic devices while riding. For the latest information about your Ride Command display, including software, maps, and trail updates, please visit: ridecommand.polaris.com/display. BEFORE YOU RIDE WARNING Failure to pay attention to operating your vehicle could result in loss of control, injury, or death.
Page 82 7" DISPLAY BY RIDE COMMAND (IF EQUIPPED) • Download the Polaris RIDE COMMAND App from the Apple®/Google Play® store and create your personalized account. • Check your display to ensure you have the appropriate maps and trails visible for your area. To change or update maps/trails see page 89.
Page 83: Button Description
Zooms in when using the map and Up Button scrolls up through lists of features. Opens and closes the Badge Panel. Polaris Button Zooms out when using the map and Down Button scrolls down through lists of features. Cycles all screens and backs user Back Button out of menus.
Page 84 7" DISPLAY BY RIDE COMMAND (IF EQUIPPED) CONFIGURE GAUGE SCREEN The display allows up to four customized gauge screens. All but one screen can be deleted; one will always remain as the default. NOTICE In the gauge configuration panel, display buttons and hand controls will not work.
Page 85 7" DISPLAY BY RIDE COMMAND (IF EQUIPPED) For single value slots, choose 1 data item. For list slots, choose up to 3 or up to 5 data items, depending on the configuration of the gauge layout as selected above. NOTICE Keep your display software up-to-date as more widget options become available.
Page 86 7" DISPLAY BY RIDE COMMAND (IF EQUIPPED) GAUGE VIEW MODE Press to toggle between the two available gauge view modes, analog and digital.
Page 87: Icon Description
7" DISPLAY BY RIDE COMMAND (IF EQUIPPED) ICON BAR The Icon Bar is located across the top of the touchscreen and displays cell phone, headset, and wireless internet connectivity, fuel level, compass heading and local time. NOTICE The Icon Bar will not appear when the Badge Panel is open. ICON DESCRIPTION FUNCTION...
Page 88 7" DISPLAY BY RIDE COMMAND (IF EQUIPPED) ICON DESCRIPTION FUNCTION Vehicle Direction Displays vehicle direction Clock Displays current time...
Page 89 Day/Night Display Mode ACCESSING THE BADGE PANEL There are two ways to open the Badge Panel, press the Badge Panel button (Polaris Logo) the top of the touchscreen or the Polaris Menu hard button on the right of the display.
Page 90: Controls Tab
7" DISPLAY BY RIDE COMMAND (IF EQUIPPED) APP TRAY The App Tray provides easy access to key features on the display screen. Tap on any of the listed icons to navigate to that display screen. For example, tap the Maps button to navigate to the Map Screen, or press the Music button to navigate to the Audio Screen.
Page 91: Usb Drive
7" DISPLAY BY RIDE COMMAND (IF EQUIPPED) ENGINE OVERHEAT INDICATOR If the engine goes over temperature, a red banner will appear at the top of your display stating: ENGINE OVERHEATING – STOP IMMEDIATELY. The appearance of this banner indicates continued operation of your ATV could result in serious engine damage.
Page 92: Error Messages
2. Remove and reconnect the USB flash drive securely. 3. Ensure display files are not inside a folder on the flash drive. 4. Only POLARIS display files should be on the flash drive while performing updates. Remove other files, if necessary.
Page 93: Software Updates
Vehicle Health, Vehicle Locator and Issue Diagnostics along with a variety of features via the Polaris mobile app. You will need a cellular connection to view these features. To learn more about RIDE COMMAND+,...
Page 95: Safe Operation Practices
OPERATION OPERATION SAFE OPERATION PRACTICES WARNING Failure to operate the vehicle properly can result in a collision, loss of control, accident or rollover, which may result in serious injury or death. Read and understand all safety warnings outlined in the safety section of this owner’s manual.
Page 96: Trail Etiquette
Familiarize yourself with all laws and regulations concerning the operation of this vehicle in your area. Respect the environment in which you ride your vehicle. Find out where the designated riding areas are by contacting your POLARIS dealer, a local riding club, or local officials.
Page 97: Vehicle Break-In Period
OPERATION VEHICLE BREAK-IN PERIOD The break-in period for your new POLARIS vehicle is the first 25 hours of operation, or the time it takes to use the first two tanks full of gasoline. No single action on your part is as important as a proper break-in period. Careful treatment of a new engine and drive components will result in more efficient performance and longer life for these components.
Page 98: Brake System Break-In
OPERATION BRAKE SYSTEM BREAK-IN Apply only moderate braking force for the first 50 stops. Aggressive or overly forceful braking when the brake system is new could damage brake pads and rotors. Perform the following steps on a new vehicle or anytime brake pads are replaced on the vehicle: 1.
Page 99: Pre-Ride Checklist
OPERATION PRE-RIDE CHECKLIST Failure to inspect and verify that the ATV is in safe operating condition before operating increases the risk of an accident. Always inspect the ATV before each use to make sure it's in safe operating condition. ITEM REMARKS PAGE Ensure proper operation.
Page 100: New Operator Driving Procedures
OPERATION DRIVING PROCEDURES NEW OPERATOR DRIVING PROCEDURES 1. Complete a certified safety training course. See the Safety Training section. 2. Wear protective riding gear. See the Safe Riding Gear section. 3. Perform the pre-ride inspection. 4. Place the transmission in PARK. 5.
Page 101: Turning The Vehicle
OPERATION TURNING THE VEHICLE Both rear wheels drive equally at all times. This means that the outside wheel must travel a greater distance than the inside wheel when turning, and the inside tire must slip traction slightly. 1. Slow down. 2.
Page 102: Driving On Slippery Surfaces
OPERATION DRIVING ON SLIPPERY SURFACES Whenever riding on slippery surfaces such as wet trails or loose gravel, or during freezing weather, follow these precautions: 1. Do not operate on excessively rough, slippery or loose terrain. 2. Slow down when entering slippery areas. 3.
Page 103: Driving Uphill
OPERATION DRIVING UPHILL Braking and handling are greatly affected when operating in hilly terrain. Improper procedure could cause loss of control or overturn. Whenever traveling uphill, follow these precautions: 1. Always engage ADC before ascending or descending a hill. 2. Drive straight uphill. 3.
Page 104: Driving Downhill
OPERATION DRIVING DOWNHILL When driving downhill, follow these precautions: 1. Always check the terrain carefully before descending a hill. 2. Always engage ADC mode before ascending or descending a hill. 3. Avoid steep hills. Maximum incline is 15° 4. Always descend a hill with the transmission in forward gear. Do not descend a hill with the transmission in neutral.
Page 105: Driving On A Sidehill (Sidehilling)
OPERATION DRIVING ON A SIDEHILL (SIDEHILLING) Driving on a sidehill is not recommended. Improper procedure could cause loss of control or overturn. Avoid crossing the side of any hill unless absolutely necessary. If crossing a sidehill is unavoidable, follow these precautions: 1.
Page 106: Turning Around On A Hill (K-Turn)
OPERATION TURNING AROUND ON A HILL (K-TURN) If the vehicle stalls while climbing a hill, never back it down the hill! Use the K-turn to turn around. 1. Stop and lock the temporary brake lock while keeping body weight uphill. 2.
Page 107: Driving Through Water
If the vehicle tips or overturns in water, or if the engine stops during or after operating in water, service is required before starting the engine. Your POLARIS dealer can provide this service. If it's impossible to bring the vehicle in before starting the engine, perform the service outlined in the Vehicle Immersion section of this manual, and take the vehicle in for service at the first opportunity.
Page 108: Driving Over Obstacles
OPERATION DRIVING OVER OBSTACLES Follow these precautions when operating over obstacles: 1. Always check for obstacles before operating in a new area. 2. Look ahead and learn to read the terrain. Be constantly alert for hazards such as logs, rocks and low hanging branches. 3.
Page 109: Driving In Reverse
OPERATION DRIVING IN REVERSE Follow these precautions when operating in reverse: 1. Always check for obstacles or people behind the vehicle. 2. Always avoid backing downhill. 3. Back slowly. 4. Apply the brakes lightly for stopping. 5. Avoid turning at sharp angles. 6.
Page 110: Starting The Engine
OPERATION STARTING THE ENGINE 1. Position the vehicle on a level surface outdoors or in a well- ventilated area. 2. Place the transmission in PARK. 3. Lock the temporary brake lock. 4. Sit on the vehicle and move the engine stop switch to RUN. NOTICE Do not press the throttle while starting the engine.
Page 111: Fuel Recommendation
Carbon Clean to the fuel tank at every oil change will help reduce carbon deposits. Seasonal Blends POLARIS recommends using gasoline that is purchased during the season the vehicle is being used, especially summer vs. winter. Between seasons, refineries typically change the gasoline blend to avoid temperature induced engine performance issues.
Page 112: Parking The Vehicle
OPERATION PARKING THE VEHICLE 1. Stop the vehicle on a level surface. When parking inside a garage or other structure, be sure that the structure is well ventilated and that the vehicle is not close to any source of flame or sparks, including any appliance with pilot lights.
Page 113: Hauling Cargo
OPERATION HAULING CARGO CARGO WARNING WARNING Overloading the vehicle or carrying or towing cargo improperly can alter vehicle handling and may cause loss of control or brake instability, which can result in serious injury or death. Always follow these precautions when hauling cargo: REDUCE SPEED AND ALLOW GREATER DISTANCES FOR BRAKING WHEN HAULING CARGO.
Page 114 OPERATION HAULING CARGO GUIDELINES When hauling cargo, adhere to the following: 1. Never exceed the weight capacities specified for your ATV on warning labels and in the specifications section of this manual. 2. Always load a cargo box with the load as far forward as possible. Make sure the cargo box dump latch is securely latched before loading and operating.
Page 115: Towing Loads
Using an improper hitch or exceeding the maximum tongue weight capacity can result in serious damage to the vehicle. Never install a hitch longer than 4 in (10 cm). Never install automotive accessories on your POLARIS ATV. Always install POLARIS-approved (or equivalent) accessories designed for ATV use.
Page 116: Cargo Box Dumping (If Equipped)
OPERATION CARGO BOX DUMPING (IF EQUIPPED) WARNING Operating with the cargo box in the raised position can cause serious injury and damage to the vehicle. The cargo box could close unexpectedly and injure the driver. The rear tires will also catch the rear of the bed, damaging the vehicle and creating hazardous driving conditions.
Page 117 OPERATION SPORTSMAN X2 570 SPORTSMAN 6X6 570...
Page 118: Towing Your Vehicle
OPERATION TOWING YOUR VEHICLE If towing your vehicle is necessary, shift the transmission into neutral for better mobility and to prevent damage to the belt. Always attach the tow cable to the front tow loop of the disabled vehicle. A rider must be on board to steer the disabled vehicle while towing.
Page 119: Winch Safety Precautions
WINCH GUIDE (IF EQUIPPED) WINCH GUIDE (IF EQUIPPED) WINCH SAFETY These safety warnings and instructions apply if your vehicle came equipped with a winch or if you choose to add an accessory winch to your vehicle. WARNING Improper winch use can result in SEVERE INJURY or DEATH. Always follow all winch instructions and warnings in this manual.
Page 120 WINCH GUIDE (IF EQUIPPED) 12. If winching at an angle is unavoidable, follow these precautions: a. Look at the winch drum occasionally. Never let the winch cable “stack” or accumulate at one end of the winch drum. Too much winch cable at one end of the winch drum can damage the winch and the winch cable.
Page 121: Winch Operation
WINCH GUIDE (IF EQUIPPED) WINCH OPERATION Read the Winch Safety Precautions in the preceding pages before using your winch. Consider practicing the operation and use of your winch before you actually need to use it in the field. WARNING Improper winch use can result in SEVERE INJURY or DEATH. Always follow all winch instructions and warnings in this manual.
Page 122 Replace the winch cable at the first sign of damage to prevent SEVERE INJURY or DEATH in the event of failure. For your safety, always replace POLARIS winch parts (including the cable) with genuine POLARIS replacement parts available at your authorized POLARIS dealer, or other qualified dealer.
Page 123 WINCH GUIDE (IF EQUIPPED) • If possible, keep the winch cable aligned with the centerline of the winching vehicle. This will help the spooling of the winch cable and reduce the load on the fairlead. • If freeing a stuck vehicle by attaching to a tree, use an item such as a tow strap to avoid damaging the tree during winch operation.
Page 124 WINCH GUIDE (IF EQUIPPED) c. On a long pull, it may be necessary to stop winching so that the damper can be repositioned to the new mid-point of the winch cable. Always release the tension on the winch cable before repositioning the damper. d.
Page 125 WINCH GUIDE (IF EQUIPPED) 13. Extensive winching will run down the battery on the winching vehicle. Let the winching vehicle’s engine run while operating the winch to prevent the battery from running low if winching for long periods. 14. The winch motor may become hot during winch use. If you winch for more than 45 seconds, or if the winch stalls during operation, stop winching and permit the winch to cool down for 10 minutes before using it again.
Page 126: Winch Cable Care
Use of worn or damaged cable could lead to sudden failure and SEVERE INJURY. For your safety, always replace POLARIS winch parts (including the cable) with genuine POLARIS replacement parts available at your authorized POLARIS dealer, or other qualified person.
Page 127: Shock Loading
WINCH GUIDE (IF EQUIPPED) SHOCK LOADING WARNING Your winch cable is very strong but it is NOT designed for dynamic, or “shock” loading. Shock loading may tension a winch cable beyond its strength and cause the cable to break. The end of a broken winch cable under such high loading can cause SEVERE INJURY or DEATH to you and other bystanders.
Page 128: Winch Maintenance And Service Safety
3. Never work on your winch without first disconnecting the battery connections to prevent accidental activation of the winch. 4. For your safety, always replace POLARIS winch parts (including the cable) with genuine POLARIS replacement parts available at your authorized POLARIS dealer, or other qualified person.
Page 129: Noise Emission Control System
EMISSION CONTROL SYSTEMS EMISSION CONTROL SYSTEMS NOISE EMISSION CONTROL SYSTEM Do not modify the engine, intake or exhaust components, as doing so may affect compliance with U.S.A. EPA noise control requirements (40 CFR 205) and local noise level requirements. OPERATION ON PUBLIC LANDS IN THE U.S.A. Your vehicle has a spark arrester that was tested and qualified to be in accordance with the USFS standard 5100-1a.
Page 131: Periodic Maintenance
PERIODIC MAINTENANCE Any qualified repair shop or person may maintain, replace or repair the emission control devices or systems on your vehicle. An authorized POLARIS dealer can perform any service that may be necessary for your vehicle. POLARIS also recommends POLARIS parts for emissions-related service, however equivalent parts can be used.
Page 132 MAINTENANCE POLARIS MAINTENANCE SCHEDULE The intervals shown are based on vehicles operated under normal conditions. Each interval is given in hours and miles (kilometers). Items should be serviced at whichever interval comes first. Continue to reference the following maintenance schedules at the given intervals as hours and miles (kilometers) increase on the vehicle.
Page 133 MAINTENANCE Vehicles subjected to severe use must be serviced at 50% of the stated interval. Examples of Severe Use: Frequent immersion in mud, water, or sand, constant high RPM use, prolonged low-speed heavy load operation, extended idle, and short trip cold weather operation. EVERY 100 HOURS / 1000 MILES (1600 KM) OR YEARLY Replace air filter.
Page 134 Check fluid. Wiring Inspect for wear, routing, and retention. * Have an authorized Polaris dealer or other qualified person perform these services. Vehicles subjected to severe use must be serviced at 50% of the stated interval. Examples of Severe Use: Frequent immersion in mud, water, or sand, constant high RPM use, prolonged low-speed heavy load operation, extended idle, and short trip cold weather operation.
Page 135 MAINTENANCE ELEVATING THE VEHICLE FOR SERVICE Some service procedures require elevation of the vehicle. Always position the vehicle on a firm, level surface before elevating. Do not position a jack or jack stand under any components other than the frame. Use an appropriate lift or floor jack.
Page 136 MAINTENANCE SPORTSMAN 6X6 570...
Page 137: Lubrication Guide
Vehicle operation with insufficient, deteriorated, or contaminated engine oil will cause accelerated wear and may result in engine seizure, accident and injury. Always check and change the engine oil at the intervals outlined in the Polaris Maintenance Schedule. Always use the recommended engine oil.
Page 138: Oil Recommendations
POLARIS recommends the use of POLARIS PS-4 Full Synthetic 5W-50 4-cycle oil or a similar oil for this engine. Oil may need to be changed more frequently if POLARIS oil is not used. Always use 5W-50 oil. Follow the manufacturer's recommendations for ambient temperature operation.
Page 139 MAINTENANCE 3. Clean the area around the dipstick. 4. With the engine off, remove the dipstick. Wipe it dry with a clean cloth. 5. Install the dipstick and tighten it all of the way to ensure an accurate measurement. 6. Remove the dipstick and check the oil level. The oil level should be between the full and add lines on the dipstick.
Page 140: Oil And Oil Filter Change
OIL AND OIL FILTER CHANGE IMPORTANT Always change the oil filter when you change the engine oil. The engine oil and oil filter should be changed in accordance with the Polaris Maintenance Schedule. See the Lubrication Guide section for fluid recommendations and capacities.
Page 141 MAINTENANCE 1. Position the vehicle on a level surface. Put the transmission in PARK (P) and lock the temporary brake lock. 2. Clean the area around the drain plug 3. Put a drain pan below the drain plug. 4. Remove the drain plug and washer .
Page 142 MAINTENANCE 7. Put a drain pan below the oil filter 8. Use an Oil Filter Wrench (available from your POLARIS dealer) to turn the oil filter counter-clockwise to remove it. Oil Filter Wrench PU-50105 9. Use a clean dry cloth to clean the oil filter sealing surface on the engine crankcase.
Page 143 MAINTENANCE 12. Remove the engine access panel on the right side of the vehicle. 13. Clean the area around the dipstick. 14. Remove the dipstick. Use a funnel to slowly add the recommended oil to bring the oil level between the full and add lines on the dipstick. Do NOT overfill.
Page 144: Transmission Fluid
Images are for reference only. Your model might differ slightly. The transmission fluid should be checked and changed in accordance with the Polaris Maintenance Schedule. See the Lubrication Guide section for fluid recommendations and capacities. Maintain the fluid level at the bottom of the fill plug hole.
Page 145: Fluid Change
MAINTENANCE 6. Install the fill plug and torque to specification. TORQUE Transmission Drain / Fill Plug: 12 ft-lbs (16 N·m) 7. Clean any residual fluid off of the vehicle and inspect for leaks. 8. Install the rear left wheel. See page 170. FLUID CHANGE 1.
Page 146 MAINTENANCE 6. Remove the drain plug and allow the fluid to drain completely. Discard the used fluid properly. 7. Clean any dirt or debris on the drain plug. Inspect the o-ring and replace if necessary. 8. Install the drain plug and torque to specification. TORQUE Transmission Drain / Fill Plug: 12 ft-lbs (16 N·m)
Page 147 MAINTENANCE 11. Remove the fill plug. 12. Use a funnel to slowly add the proper amount of the recommended fluid. The fluid level should reach the bottom of the fill hole threads. FLUID CAPACITY Recommended Lubricant: Capacity: 32 fl oz (948 mL) 13.
Page 148: Front Gearcase (Demand Drive) Fluid
NOTICE If the front gearcase is makes excessive noise during ADC operation, change the demand drive fluid. If the noise continues, please see your POLARIS dealer or other qualified service facility for service. Use the recommended fluid. Use of other fluids may result in improper operation of components.
Page 149 MAINTENANCE FLUID CHECK 1. Position the vehicle on a level surface. Put the transmission in PARK (P) and lock the temporary brake lock. 2. Clean the area around the fill plug 3. Remove the fill plug and check the fluid level. The fluid level is correct if fluid is visible at the fill hole threads.
Page 150 MAINTENANCE FLUID CHANGE 1. Position the vehicle on a level surface. Put the transmission in PARK (P) and lock the temporary brake lock. 2. Clean the area around the drain plug 3. Put a drain pan below the drain plug. 4.
Page 151 MAINTENANCE 9. Use a funnel to slowly add the proper amount of the recommended fluid. The fluid level should reach the bottom of the fill hole threads. FLUID CAPACITY Recommended Lubricant: Demand Drive Fluid Capacity: 9 fl oz (265 mL) 10.
Page 152: Power Steering Unit
Check the coolant level and maintain as recommended by adding coolant to the recovery bottle. POLARIS recommends the use of POLARIS Antifreeze 50/50 Premix. This antifreeze is already premixed and ready to use. Do not dilute with water. See...
Page 153: Recovery Bottle Coolant
MAINTENANCE RECOVERY BOTTLE COOLANT The recovery bottle is located under the front cab and can be accessed through the front right wheel well. 1. View the fluid level in the bottle. 2. If the level is low, remove the bottle cap and add coolant as needed. Maintain the coolant level between the minimum and maximum marks on the bottle (when the fluid is cool).
Page 154: Radiator Coolant
5. Install the pressure cap. Use of a non-standard pressure cap will not allow the recovery system to function properly. Your POLARIS dealer can provide the correct replacement part. 6. Close the radiator cap access cover and front rack.
Page 155 MAINTENANCE BRAKES HAND BRAKE CAUTION Brake discs can become extremely hot after operation. Allow the discs to cool before performing maintenance to prevent risk of burns. The front and rear brakes are hydraulic disc brakes, activated by moving the single brake lever toward the handlebar. These brakes are self- adjusting. Under normal operation, the diaphragm extends into the reservoir as fluid level drops.
Page 156: Seat Removal
MAINTENANCE SEAT REMOVAL TOURING MODELS 1. Pull up on the passenger seat latch lever 2. Tilt the passenger seat forward and then lift up to remove the seat from the vehicle.
Page 157 MAINTENANCE 3. Lift the rear of the driver seat and slide the seat towards the back of the vehicle to remove it.
Page 158 MAINTENANCE X2 MODELS 1. Pull up on one of the cargo box latch levers and tilt the cargo box backwards. 2. Lift the rear of the driver seat and slide the seat towards the back of the vehicle to remove it. NOTICE The rear seat can be adjusted to three different positions.
Page 159 MAINTENANCE 6X6 MODELS 1. Lift up on the cargo box release lever on either side of the vehicle and tilt the cargo box backwards. 2. Lift the rear of the driver seat and slide the seat towards the back of the vehicle to remove it.
Page 160: Seat Installation
MAINTENANCE SEAT INSTALLATION TOURING MODELS 1. Align the two openings in the bottom of the driver seat with the two seat base brackets 2. Slide the driver seat forward and lower the rear.
Page 161 MAINTENANCE 3. Press the rear of the driver seat down firmly to seat the two pins into the grommets...
Page 162 MAINTENANCE 4. Install the passenger seat onto the vehicle by pushing back on the backrest and down on the passenger seat latch lever until you feel and hear a click. NOTICE Make sure you push the passenger seat latch lever all of the way down so that it latches into place.
Page 163 MAINTENANCE X2 MODELS 1. Slide the driver seat forward and lower the rear. 2. Tilt the cargo box to the upright position.
Page 164 MAINTENANCE 6X6 MODELS 1. Slide the driver seat forward and lower the rear. 2. Tilt the cargo box to the upright position.
Page 165 MAINTENANCE SIDE PANEL / FOOTWELL REMOVAL LEFT SIDE PANEL / FOOTWELL 1. Remove the seat. 2. Use the multi-function pliers (included in your vehicle’s toolkit) to remove the three push rivets from the side panel / close off panel. 3. Grasp the rear of the side panel. With a firm motion, pull the side panel outward to disengage the side panel / close off panel from the vehicle.
Page 166 MAINTENANCE 4. Remove the two screws and two push rivets from the footwell. 5. Remove the six screws and nuts from the bottom of the footwell. Pull the footwell downward and outward to remove it.
Page 167 MAINTENANCE RIGHT SIDE PANEL / FOOTWELL 1. Remove the seat. 2. Use the multi-function pliers (included in your vehicle’s toolkit) to remove the two push rivets from the side panel. 3. Grasp the rear of the side panel. With a firm motion, pull the side panel outward to disengage it from the vehicle.
Page 168 NOTICE Observe the condition of each push rivet and check for damage. If damaged, POLARIS recommends that you replace the push rivet before installation. 2. Loosely install the two screws and two push rivets into the footwell. 3. Install the side panel / close off panel onto the vehicle and install the three...
Page 169 NOTICE Observe the condition of each push rivet and check for damage. If damaged, POLARIS recommends that you replace the push rivet before installation. 2. Loosely install the two screws and two push rivets into the footwell. 3. Install the close off panel / shield onto the vehicle.
Page 170: Tire Tread Depth
MAINTENANCE TIRES WARNING Operating your ATV with worn tires, improperly inflated tires, non-standard tires or improperly installed tires will affect vehicle handling and could cause an accident resulting in serious injury or death. Always follow all tire maintenance procedures as outlined in this manual and on the labels on the vehicle. Always use original equipment size and type when replacing tires.
Page 171: Wheel Removal
MAINTENANCE WHEEL REMOVAL WARNING Do not service axle nuts that have a cotter pin installed. Your authorized dealer can assist. 1. Stop the engine, put the transmission in PARK (P), and lock the temporary brake lock. 2. Loosen the wheel nuts slightly.
Page 172: Wheel Installation
MAINTENANCE WHEEL INSTALLATION 1. Stop the engine, put the vehicle in PARK (P), and set the temporary brake lock. 2. Place the wheel on the hub with the valve stem toward the outside and rotation arrows on the tire pointing toward forward rotation (if equipped). 3.
Page 173 MAINTENANCE 4. Lower the vehicle to the ground. 5. Torque the wheel nuts to specification.
Page 174: Wheel Nut Torque Specifications
MAINTENANCE WHEEL NUT TORQUE SPECIFICATIONS Check the wheel nut torques occasionally and when they've been loosened for maintenance service. Lug Nut 30 ft-lbs (41 N·m) (Aluminum Front and Rear PLUS 70 degrees Wheels) 2-Piece Flange Nut 27 ft-lbs (37 N·m) Front and Rear (Steel Wheels)
Page 175: Toe Alignment
1/4–1/2 inch (6–12 mm) toe out alignment. 5. Repeat the measurement procedure on the other side of the vehicle. 6. If you discover improper alignment, see your POLARIS dealer for service.
Page 176 MAINTENANCE CAMBER AND CASTER The camber and caster are non-adjustable. AIR FILTER It is recommended that the air filter is replaced annually. When riding in extremely dusty conditions, replacement is required more often. 1. Lift up on the rear of the seat. 2.
Page 177 MAINTENANCE 5. Loosen the air filter hose clamp and remove air filter assembly. 6. Inspect the air filter and replace if necessary. If the filter has been soaked with fuel or oil, it must be replaced. 7. Reinstall the air filter on the main filter mount.
Page 178: Fuse Replacement
MAINTENANCE FUSE REPLACEMENT If the engine stops or will not start, or if you experience other electrical failures, a fuse may need replacement. Locate and correct any short circuits that may have caused the blown fuse, then replace the fuse. Spare fuses are provided in the tool kit.
Page 179: Headlight Lamp Replacement
5. Reassemble the pod. LED HEADLIGHT REPLACEMENT (IF EQUIPPED) On models equipped with LED headlights, if the headlights become inoperable, the entire assembly must be replaced by your authorized Polaris dealer or other qualified service facility.
Page 180: High Beam Adjustment
MAINTENANCE HIGH BEAM ADJUSTMENT The headlight beam can be adjusted slightly upward or downward. Use the following procedure to make the adjustment. NOTICE Image is for reference only. Your model might differ slightly. 1. Position the vehicle on a level surface with the headlight approximately 25 ft (7.6 m) from a wall .
Page 181 MAINTENANCE BUMPER LIGHT ADJUSTMENT The low beam can be adjusted slightly upward or downward. To adjust the bumper headlight, do the following: 1. Loosen the Phillips® screw located at the rear of the headlamp. 2. Tilt the headlamp upward or downward.
Page 182: Headlight Housing Replacement
MAINTENANCE HEADLIGHT HOUSING REPLACEMENT 1. Remove the four headlight pod screws and remove the front half of the pod from the vehicle. 2. Remove each rubber o-ring retainer on each side of the pod bracket and remove the headlight adjuster screw 3.
Page 183: Lower Headlamp Replacement
MAINTENANCE 4. Lift the headlight out of the vehicle to remove it. 5. Reverse steps for installation. Torque screws to specification. TORQUE Headlight Pod Screws: 10 in-lbs (2 N·m) 6. Adjust the headlight pod. LOWER HEADLAMP REPLACEMENT 1. Turn the back of the headlight harness counter-clockwise and pull the harness assembly away from the headlight assembly.
Page 184: Spark Plug Recommendations
Refer to the specifications section for the recommended spark plug type and gap for your vehicle. Torque spark plugs to specification. NOTICE Using non-recommended spark plugs can result in serious engine damage. Always use POLARIS-recommended spark plugs or their equivalent. ENGINE TORQUE SPECIFICATION 9 ft-lbs (12 N·m) SPARK PLUG INSPECTION Spark plug condition is indicative of engine operation.
Page 185: Vehicle Immersion
If your vehicle becomes immersed, major engine damage can result if the machine is not thoroughly inspected. Take the vehicle in for service before starting the engine. Your POLARIS dealer can provide this service. If it's impossible to take your ATV to a dealer before starting it, follow the steps outlined below.
Page 186: Spark Arrestor Service
MAINTENANCE SPARK ARRESTOR (TOURING MODELS) SPARK ARRESTOR SERVICE WARNING Do not perform clean out immediately after the engine has been run, as the exhaust system becomes very hot. Serious burns could result from contact with exhaust components. To reduce fire hazard, make sure that there are no combustible materials in the area when purging the spark arrestor.
Page 187 MAINTENANCE 4. If particles are still suspected to be in the muffler, back the machine onto an incline so the rear of the machine is one foot higher than the front. Put the transmission in PARK (P), lock the temporary brake lock, and block the wheels to prevent roll back.
Page 188 MAINTENANCE The spark arrestor should be periodically cleaned to remove accumulated carbon. A plugged spark arrestor will affect engine performance. Replace a cracked or damaged spark arrestor before running the vehicle. 1. Remove the spark arrestor screen fasteners 2. Remove the spark arrestor from the end of the muffler.
Page 189: Pvt System
• See your POLARIS dealer, or other qualified person, for service and repair assistance. • This PVT system is intended for use on POLARIS products only. Do not install it in any other product. • Always make sure the PVT housing is securely in place during operation.
Page 190: Pvt Drying
MAINTENANCE The air temperature in the clutch cover is substantially reduced by using low range while operating at low ground speeds. Reducing the temperature inside the clutch cover greatly extends the life of the PVT components (belt, cover, etc.). WHEN TO USE LOW RANGE AND HIGH RANGE CONDITION RANGE TO USE Operating at speeds less than 7 MPH...
Page 191 MAINTENANCE 4. Remove the left side panel / footwell. See page 163. 5. Loosen the PVT outlet duct clamp. 6. Remove the 10 fasteners securing the outer PVT cover to the inner PVT cover. 7. Using care, pull the outer PVT cover out the side of the vehicle.
Page 192: Drive Belt Inspection
MAINTENANCE 8. Note the orientation of the drive belt so that it can be installed in the same direction. 9. Insert the Belt Removal Tool (included in your vehicle’s toolkit) into the threaded hole on the driven clutch as shown and turn clockwise to spread the clutch.
Page 193: Drive Belt Installation
MAINTENANCE DRIVE BELT INSTALLATION 1. Clean the inside of the PVT covers thoroughly. WARNING Failure to remove all debris when replacing the belt could result in vehicle damage, loss of control, and severe injury or death. IMPORTANT Orient the belt as it was removed or orient the new belt so that you can read the text.
Page 194 MAINTENANCE 5. Rotate / spin the driven clutch and belt approximately 5-7 times clockwise to properly seat the belt into the driven clutch.
Page 195 MAINTENANCE 6. Install the outer PVT cover and 10 fasteners. Torque fasteners to specification. TORQUE Outer PVT Cover Fasteners: 44 in-lbs (5 N·m)
Page 196 MAINTENANCE 7. Install the PVT outlet duct and clamp. 8. Torque the PVT outlet duct clamp to specification. TORQUE Outlet Duct Clamp: 27 in-lbs (3 N·m) 9. Install the left side panel / footwell. See page 166. 10. Install the seat. BATTERY WARNING Improperly connecting or disconnecting battery cables can result in an...
Page 197: Battery Removal
MAINTENANCE BATTERY REMOVAL WARNING Improperly connecting or disconnecting battery cables can result in an explosion and cause serious injury, death, vehicle damage, and/or battery damage. When removing the battery, always disconnect the negative (-) black cable first. When reinstalling the battery, always connect the negative (-) black cable last.
Page 198: Battery Storage
MAINTENANCE NOTICE Using a new battery that has not been fully charged can damage the battery and result in a shorter life. It can also hinder vehicle performance. Refer to the battery charging information in the Maintenance chapter before installing the battery.
Page 199 POLARIS recommends maintaining battery charge by using a POLARIS battery trickle charger or by charging once a month using the battery charge port The POLARIS offered battery trickle charger can be left connected during the storage period, and will automatically charge the battery if the voltage drops below a pre-determined point.
Page 200: Battery Charging
MAINTENANCE BATTERY CHARGING Read all instructions before proceeding with the installation of this battery. The battery is already filled with electrolyte and has been fully charged at the factory. Never pry the caps off or add any other fluid to this battery. The single most important thing about maintaining the battery is to keep it fully charged.
Page 201: Battery Identification
It is important to identify the type of battery installed in the vehicle. Different types of batteries require different service procedures. Proper servicing and upkeep of the battery is very important for maintaining long battery life. All Polaris ORV models include either a Conventional battery or a Low Maintenance battery. CONVENTIONAL BATTERY •...
Page 202 LOW MAINTENANCE BATTERY BEST PRACTICES Some Polaris ORV models include either a Lead Acid or Absorbed Glass Mat (AGM) Low Maintenance battery. See the Service Manual for procedures on how to charge, maintain, and test a Lead Acid or AGM Low Maintenance battery.
Page 203: Suspension Spring Preload Adjustment
MAINTENANCE LOW MAINTENANCE BATTERIES CHARGING • Polaris recommends using a BatteryMINDer® 1.5 AMP (PN 2830404) charger, which can be ordered through your normal parts channel. • Nominal voltage is 12.6–12.8 Volts when fully charged. If the voltage falls below 12.5V, charge it immediately, or the battery runs the risk of sulfation.
Page 204 Follow the adjustment procedures exactly, or see your POLARIS dealer for service. 1. Remove the upper headlight pod.
Page 205: Cleaning And Storage
Certain products, including insect repellents and chemicals, will damage plastic surfaces. Do not allow these types of products to contact the vehicle. The best way to clean your POLARIS vehicle is with a garden hose and a pail of mild soap and water.
Page 206: Polishing The Vehicle
• Throttle and shift cables and controls • Body panels • Seats If warning and safety labels are damaged, contact your POLARIS dealer for free replacement. Grease all zerk fittings immediately after washing. Allow the engine to run for a while to evaporate any water that may have entered the engine or exhaust system.
Page 207: Storage Tips
AIR FILTER / AIR BOX Replace the air filter. See Maintenance Chapter. Clean the air box. FLUID LEVELS Inspect the fluid levels. Add or change fluids as recommended in the Polaris Maintenance Schedule. • Demand drive fluid (front gearcase) • Rear gearcase fluid (if equipped) •...
Page 208: Fog The Engine
6. Reinstall the spark plug cap. 7. If POLARIS fuel system additive is not used, fuel tank, fuel lines, and injectors should be completely drained of gasoline. BATTERY MAINTENANCE See the Battery Storage and Battery Charging sections for storage and charging procedures.
Page 209 MAINTENANCE TRAILERING YOUR VEHICLE Follow these procedures when transporting the vehicle. 1. Stop the engine. 2. Place the transmission in PARK. 3. Secure the fuel cap, oil cap, and seat. 4. Remove the key to prevent loss during transporting. 5. Use suitable straps or rope to secure the vehicle to the front tow hook rear tow bracket .
Page 211: Specifications
SPECIFICATIONS SPECIFICATIONS SPORTSMAN TOURING 570 SPORTSMAN TOURING 570 Maximum Weight Capacity 485 lb (220 kg) (operator, cargo, accessories) Dry Weight 916 lb (415 kg) Fuel Capacity 6.75 gal (25.5 L) Engine Oil Capacity 2 qt (1.9 L) Coolant Capacity 2.7 qt (2.5 L) Demand Drive Fluid Capacity 9 fl oz (265 mL) Transmission Fluid Capacity...
Page 212 1200 +/- 50 NGK® MR7F Spark Plug Type / Gap 0.030 in (0.076 cm) Lubrication System Wet Sump Automatic PVT (POLARIS Variable Driving System Type Transmission) Touring 570 / EPS / Premium: Sealed MacPherson Ride® Strut with 8.2 in (20.8 cm) Travel...
Page 213 SPECIFICATIONS SPORTSMAN TOURING 570 Brake Lights / Taillights Dual LED Brake Lights / Taillights Instrument Cluster...
Page 214 SPECIFICATIONS SPORTSMAN X2 570 SPORTSMAN X2 570 Maximum Weight Capacity 705 lb (320 kg) (operator, cargo, accessories) Dry Weight 931 lb (422 kg) Fuel Capacity 6.75 gal (25.5 L) Engine Oil Capacity 2 qt (1.9 L) Coolant Capacity 2.7 qt (2.5 L) Demand Drive Fluid Capacity 9 fl oz (265 mL) Transmission Fluid Capacity...
Page 215 1200 +/- 50 NGK® MR7F Spark Plug Type / Gap 0.030 in (0.076 cm) Lubrication System Wet Sump Automatic PVT (POLARIS Variable Driving System Type Transmission) Sealed MacPherson Ride® Strut with 8.2 in Front Suspension (20.8 cm) Travel Rear Suspension Sealed Dual A-Arm, IRS 9.5 in (24.1 cm) Travel...
Page 216 SPECIFICATIONS SPORTSMAN 6X6 570 SPORTSMAN 6X6 570 Maximum Weight Capacity 1115 lb (506 kg) (operator, cargo, accessories) Dry Weight 1187 lb (538 kg) Fuel Capacity 6.75 gal (25.5 L) Engine Oil Capacity 2 qt (1.9 L) Coolant Capacity 2.7 qt (2.5 L) Demand Drive Fluid Capacity 9 fl oz (265 mL) Transmission Fluid Capacity...
Page 217 1200 +/- 50 NGK® MR7F Spark Plug Type / Gap 0.030 in (0.076 cm) Lubrication System Wet Sump Automatic PVT (POLARIS Variable Driving System Type Transmission) Front Suspension Sealed Dual A-Arm with 8.9 in (22.6 cm) Travel Rear Suspension Sealed Dual A-Arm, IRS 6.3 in (16 cm) Travel...
Page 219: Polaris Products
POLARIS PRODUCTS POLARIS PRODUCTS LUBRICANTS / SERVICE PRODUCTS PRODUCT SIZE PART NUMBER Fogging Oil 12 oz (340 g) aerosol 2870791 1 qt (0.95 L) 2876244 PS-4 1 gal (3.8 L) 2876245 1 qt (0.95 L) 2889395 PS-4 Extreme Duty 1 gal (3.8 L)
Page 221: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING DIAGNOSTIC DISPLAY CODE DEFINITIONS Open Load:There is a break in the wires that lead to the item listed in the chart (injector, fuel pump, etc.), or the item has failed. Short-to-Ground:The wire is shorted to ground between the electronic control unit and the item listed in the chart.
Page 222 TROUBLESHOOTING DIAGNOSTIC CODES COMPONENT CONDITION Voltage Below Normal, Or Fuel Level 1 Shorted To Low Source Data Valid But Above Normal Fuel Level 1 Operating Range - Moderately Severe Level Engine Intake Manifold #1 Voltage Below Normal, Or Pressure Shorted To Low Source Voltage Above Normal, Or Engine Intake Manifold #1 Shorted To High Source...
Page 223 TROUBLESHOOTING DIAGNOSTIC CODES COMPONENT CONDITION Voltage Above Normal, Or Battery Potential / Power Input Shorted To High Source Battery Potential / Power Input Voltage Below Normal, Or Shorted To Low Source Data Valid But Below Normal Battery Potential / Power Input Operational Range - Most Severe Level Data Valid But Below Normal...
Page 224 TROUBLESHOOTING DIAGNOSTIC CODES COMPONENT CONDITION Calibration Out Of Calibration Abnormal Frequency Or Pulse Crankshaft Position Sensor Width Or Period Data Erratic, Intermittent Or Crankshaft Position Sensor Incorrect Abnormal Frequency Or Pulse Camshaft Position Sensor Width Or Period Injector 1 (Front) (MAG) (SDI Voltage Above Normal, Or Port Injector) Shorted To High Source...
Page 225 TROUBLESHOOTING DIAGNOSTIC CODES COMPONENT CONDITION Malfunction Indicator Lamp Voltage Below Normal, Or 1213 Status Shorted To Low Source Ignition Coil Primary Driver 1 Voltage Above Normal, Or 1268 (Front) (MAG) Shorted To High Source Ignition Coil Primary Driver 1 Data Erratic, Intermittent Or 1268 (Front) (MAG) Incorrect...
Page 226 TROUBLESHOOTING DIAGNOSTIC CODES COMPONENT CONDITION ECU Power Output Supply Voltage Above Normal, Or 3598 Voltage #2 Shorted To High Source ECU Power Output Supply Voltage Below Normal, Or 3598 Voltage #2 Shorted To Low Source ECU Power Output Supply Voltage Above Normal, Or 3599 Voltage #3 Shorted To High Source...
Page 227 TROUBLESHOOTING DIAGNOSTIC CODES COMPONENT CONDITION Voltage Below Normal, Or Throttle Position Sensor 2 520198 Shorted To Low Source Voltage Above Normal, Or Throttle Position Sensor 2 520198 Shorted To High Source Current Below Normal Or Canister Purge Valve 520202 Open Circuit Voltage Above Normal, Or Canister Purge Valve 520202...
Page 228 TROUBLESHOOTING DIAGNOSTIC CODES COMPONENT CONDITION Voltage Above Normal, Or All Wheel Drive Control Circuit 520207 Shorted To High Source Voltage Below Normal, Or All Wheel Drive Control Circuit 520207 Shorted To Low Source Voltage Below Normal, Or Chassis Relay 520208 Shorted To Low Source Current Below Normal Or Chassis Relay...
Page 229 TROUBLESHOOTING DIAGNOSTIC CODES COMPONENT CONDITION IC CAN Communication with Condition Exists 520230 EPAS IC CAN Communication with Condition Exists 520230 EPAS EPAS Power Save Condition Condition Exists 520231 Accelerator Position/Brake Condition Exists 520275 Position Interaction Throttle Position Sensor (1 or 2 Data Erratic, Intermittent Or 520276 Indeterminable)
Page 230 TROUBLESHOOTING DIAGNOSTIC CODES COMPONENT CONDITION ECU Monitoring Error Condition Exists 520286 ECU Monitoring Error (Level 3) Condition Exists 520287 ECU Monitoring of Injection Condition Exists 520288 Cut Off (Level 1) ECU Monitoring of Injection Condition Exists 520289 Cut Off (Level 2) Throttle Body Control - Requested Throttle Angle Not Condition Exists...
Page 231 TROUBLESHOOTING DIAGNOSTIC CODES COMPONENT CONDITION Voltage Below Normal, Or Intercooler Pump Driver Circuit 520496 Shorted To Low Source Voltage Above Normal, Or Intercooler Pump Driver Circuit 520496 Shorted To High Source Current Below Normal Or Intercooler Pump Driver Circuit 520496 Open Circuit Bad Intelligent Device Or Farm Mode Set Speed...
Page 232: Drive Belt Wear/Burn
TROUBLESHOOTING DRIVE BELT WEAR/BURN POSSIBLE CAUSE SOLUTION Driving onto a pickup or tall Use low range during loading. trailer in high range Starting out going up a steep Use low range. incline Driving at low RPM or ground speed – 3–7 mph (4.8–11.3 Drive at a higher speed or use low range more frequently.
Page 233: Engine Doesn't Turn Over
TROUBLESHOOTING ENGINE DOESN'T TURN OVER POSSIBLE CAUSE SOLUTION Low battery voltage Recharge the battery. Loose battery Check all connections and tighten. connections Loose solenoid Check all connections and tighten. connections Loose electronic control Inspect, clean, reinstall connectors. box connections ENGINE TURNS OVER, FAILS TO START POSSIBLE CAUSE SOLUTION Out of fuel...
Page 234: Engine Pings Or Knocks
TROUBLESHOOTING POSSIBLE CAUSE SOLUTION Mechanical failure Your authorized dealer can assist Loose ignition connections Check all connections and tighten Water present in fuel Replace with fresh recommended fuel ENGINE PINGS OR KNOCKS POSSIBLE CAUSE SOLUTION Poor quality or low octane fuel Replace with recommended fuel Incorrect spark plug gap or Set gap to specs or replace plug...
Page 235: Engine Stops Or Loses Power
TROUBLESHOOTING ENGINE STOPS OR LOSES POWER POSSIBLE CAUSE SOLUTION Out of fuel Refuel Kinked or plugged fuel vent Inspect and replace line Water is present in fuel Replace with new fuel Fouled or defective spark plug Inspect, clean and/or replace spark plug Worn or defective spark plug Your authorized dealer can assist wires...
Page 237: Limited Warranty
REGISTRATION At the time of sale, the Warranty Registration Form must be completed by your dealer and submitted to POLARIS within ten days of purchase. Upon receipt of this registration, POLARIS will record the registration for warranty. No verification of registration will be sent to the purchaser as the copy of the Warranty Registration Form will be your proof of warranty coverage.
Page 238: Warranty Coverage And Exclusions
WARRANTY COVERAGE AND EXCLUSIONS LIMITATIONS OF WARRANTIES AND REMEDIES This POLARIS limited warranty excludes any failures that are not caused by a defect in material or workmanship. THIS WARRANTY DOES NOT COVER CLAIMS OF DEFECTIVE DESIGN. This warranty also does not cover acts of God, accidental damage, normal wear and tear, abuse or improper handling.
Page 239: Lubricants And Fluids
MATERIALS, COMPONENTS, OR PRODUCTS. THE REMEDIES SET FORTH IN THIS WARRANTY ARE THE ONLY REMEDIES AVAILABLE TO ANY PERSON FOR BREACH OF THIS WARRANTY. POLARIS SHALL HAVE NO LIABILITY TO ANY PERSON FOR INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES OF ANY DESCRIPTION, WHETHER ARISING OUT OF EXPRESS OR IMPLIED WARRANTY OR ANY OTHER CONTRACT, NEGLIGENCE, OR OTHER TORT OR OTHERWISE.
Page 240: How To Obtain Warranty Service
If you purchase from a private party: If you purchase a POLARIS product from a private party, to be kept and used outside of the country in which the product was originally purchased, all warranty coverage will be denied. However, we encourage you to promptly register your product at your local authorized POLARIS dealer to receive safety information and notice regarding your product.
Page 241: Exported Products
IS SOLD OUTSIDE THE COUNTRY OF THE SELLING DEALER'S AUTHORIZED LOCATION. This policy does not apply to products that have received authorization for export from POLARIS. Dealers may not give authorization for export. You should consult an authorized dealer to determine this product's warranty or service coverage if you have any questions.
Page 242: U.s.a. Epa Emissions Limited Warranty
U.S.A. EPA EMISSIONS LIMITED WARRANTY This emissions limited warranty is in addition to the POLARIS standard limited warranty for your vehicle. POLARIS Industries Inc. warrants that at the time it is first purchased, this emissions-certified vehicle is designed, built and equipped so it conforms with applicable U.S.
Page 243 The exclusive remedy for breach of this limited warranty shall be, at the exclusive option of POLARIS, repair or replacement of any defective materials, components or products. THE...
Page 244 WARRANTY Owners are responsible for performing the scheduled maintenance identified in the owner's manual. POLARIS may deny warranty claims for failures that have been caused by the owner's or operator's improper maintenance or use, by accidents for which POLARIS has no responsibility, or by acts of God.
Page 245: California Residents
California regulations and may void this limited emissions warranty offered by the manufacturer. POLARIS Inc. warrants that at the time it is first purchased, this vehicle is: 1. Designed, built, and equipped so as to conform, at the time of sale, with all applicable California evaporative emissions regulations.
Page 246: Owner's Warranty Responsibilities
POLARIS recommends that you retain all receipts covering maintenance on your OHRV-EVAP, but POLARIS cannot deny warranty solely for the lack of receipts or for your failure to ensure the performance of a scheduled maintenance.
Page 247 A violation of this requirement is punishable by civil and/or criminal punishment. If you have any questions regarding your warranty rights and responsibilities, you should contact POLARIS Owner Connections at 1-800-POLARIS (1-800-765-2747) or the California Air Resources Board at 9528 Telstar Avenue, El Monte, CA 91731.
Page 248 Owner’s Manual must be warranted for the warranty period. If any such part fails during the warranty period, it must be repaired or replaced by POLARIS according to subdivision (4) below. Any such part repaired or replaced under warranty must be fully warranted.
Page 249 OHRV. Such use, in and of itself, will not be grounds for disallowing a warranty claim made under the provisions of this Article. POLARIS is not liable under the provisions of this Article to warrant failures of warranted parts caused by the use of an add-on or modified part(s) unless such part(s) are also warranted.
Page 251: Maintenance Log
MAINTENANCE LOG MAINTENANCE LOG MAINTENANCE LOG Use the following chart to record periodic maintenance. DATE MILES (KM) TECHNICIAN SERVICE PERFORMED / OR HOURS COMMENTS...
Page 253 Active Descent Control (ADC) California Residents ....243 System (If Equipped) ....45 Camber and Caster....174 Age Restrictions ......13 Cargo Box Air Filter Dumping......114 Maintenance ....... 174 Sportsman 6x6 570 ....115 Air Filter / Air Box..... 205 Sportsman X2 570 ....115 All Wheel Drive System Cargo Warning......
Page 254 Geofencing (If Equipped) .... 65 Gloves ........12 Electromagnetic Interference ..127 Electronic Power Steering (EPS) (if equipped) Tri-Mode Settings ....75 Elevating the Vehicle for Hand Brake ......153 Service ........ 133 Handlebars ......202 Engaging AWD ......42 Handling Gasoline .....
Page 255 Passenger Seat (X2 Models)..51 Lubrication Guide ....135 Periodic Maintenance ....129 Physical Control of the Vehicle ..17 Physical Skills......23 POLARIS Products ....217 Polishing the Vehicle ....204 Maintenance Poor Visibility......23 Air Filter......174 Power Steering Unit (Cleaning)... 150 Maintenance Log.....
Page 256 Spark Arrestor Service..184-185 Spark Plug Inspection....182 Safe Operation Practices .... 93 Spark Plugs......182 Safe Riding Gear ....... 11 Specifications Safety Labels and Locations ..26 Sportsman 6x6 570 ....214 Age 16 Warning ..... 32 Sportsman Touring 570 ..209 Clutch Cover Warning....
Page 257 Turning Around on a Hill (K-Turn) ....... 104 Turning Improperly..... 17 Unauthorized Use of the Vehicle ... 24 USB Hardware......91 Vehicle Break-in Period....95 Vehicle Identification Numbers ..8 Vehicle Immersion ....183 Warning Symbols ......4 Warranty How to Obtain Warranty Service ......
Page 259 • make sure passenger reads and understands this label and passenger safety label SCAN CODE FOR PRODUCT AND SAFETY INFORMATION. FOLLOW ALL INSTRUCTIONS AND WARNINGS For your nearest Polaris dealer, call 1-800-POLARIS (765-2747) or visit www.polaris.com Polaris Inc. Part No. 9941908 Rev 01...

This manual is also suitable for:

Sportsman touring 570 eps 2025 Sportsman touring 570 premium 2025 sportsman touring 570 ultimate 2025Sportsman x2 570 2025Sportsman 6x6 570 2025

Polaris Sportsman Touring 570 2025 Owner's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Polaris Sportsman Touring 570 2025

Summary of Contents for Polaris Sportsman Touring 570 2025

This manual is also suitable for:

Table of Contents
