  • Page 1 User Manual Series Network Turret Camera EN Ver 2023010199...
  • Page 2 Thank you very much for choosing Anpviz. Our products are supported by the world's first video monitoring manufacturers and they have adopted military level of protection. It is our top priority to ensure your data safety and offer you asatis factory service.
  • Page 3 About this Manual The Manual includes instructions for using and managing the product Picture, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.
  • Page 4 —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver Is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC Conditions This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1.
  • Page 5 Warnings: Serious Injury or death may occur if any of the warnings are neglected. Cautions: Injury or equipment damage may occur if any of the cautions are neglected. Warnings: Follow these safeguards to Cautions: Follow these precautions to prevent serious injury or death. prevent potential injury or material damage.
  • Page 6 • Do not place the camera In extremely hot, cold (the operating temperature shall be -30°C to +60°C, or -40"C to +60*C if the camera model has an "H1 in its suffix), dusty or damp Locations, and do not expose it to high electromagnetic radiation. •...
  • Page 7 1.Appearance Description Type I Type II Turret Camera Overview...
  • Page 8 Descripton Camera Body Enclosure Moun ng Base Microphone SD Card Slot /Reset Buton* Network Cable Power Cord Trim Ring Table Description Notes: ● Theitems marked with the "*" are only supported by certain camera models. ● For cameras support power over Ethernet (PoE), the poweris passed along with data on Ethernet cabling.And a switch supports PoE functionis required.

  • Page 9: Memory Card Installation

    2. Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts areincluded. ● The standard power supplyis 12 VDC or PoE Swicth , make power supply matches with your camera. sure your ●...
  • Page 10 Figure 2-1 Unscrew the Cover and Insert Memory Card 1. Insert the memory card into the memory card slot. 2. (Optional)To unmount the memory card, push to get it ejected. 3. Screw the cover back to the camera. 2.2 Ceiling Mounting Before you start: Both wall mounting and ceiling mounting are suitable for the turret camera.
  • Page 11 2. Drill the screw holes and the cable hole in the ceiling according to the drill template. Notes: Drill the cable hole, if adopting ceiling outlet to route the cable. 3. Disassemble the camera. 1). Rotate the camera to align the notch to one of the marks.
  • Page 12 4. Fix the mounting base to the ceiling with supplied screws. Notes: ● In the supplied screw package, both self-tapping screws, and expansion bolts are contained. ● If the ceiling is cement, expansion bolts are required to fix the camera. If the ceiling is wooden, self-tapping screws are required.

  • Page 13: Mounting With Junction Box

    2.3 Mounting with Junction Box Before you start: ● You need to purchase a junction box separately if you adopt the mounting with a junction box. ● Both wall mounting and ceiling mounting are suitable for the turret camera. Wall mounting will be taken as an example in this section.
  • Page 14 3. Take apart the junction box, and fix the camera's mounting base with three MP4 screws on the junction box's cover. Figure 2-8 Fix screws on the junction box's Cover 4. Secure the junction box's body on the wall with four PA4 ×...
  • Page 15 6. Repeat steps 5 to 8 of 2.2 Ceiling Mounting to complete the installation. 2.4 Mounting with Inclined Base Before you start: ● You need to purchase an inclined base separately if you adopt the mounting with an inclined base. ●...
  • Page 16 1. Disassemble the inclined base by the screw driver. 2. Install the turret camera's mounting base on the inclined base cover with three PM4 screws. Figure 2-1 1 Fix Camera's Mounting Base 5. Install the inclined base's body on the ceiling/wall with four PA4×25 screws.

  • Page 17: Wall Mounting

    2.5 Wall Mounting Note: You need to purchase a wall mounting bracket separately. Steps: 1. Drill four screw holes in the wall according to the holes of the bracket. 2. Install the bracket to the wall by aligning the four screw holes of the bracket with expansion screws on the wall.

  • Page 18: Waterproof Measures

    Figure 2-1 4 Install the Mounting Base on the Wall Mounting Bracket 5. Repeat steps 5 to 8 of 2.2 Ceiling Mounting to complete the installation. 2.6 Waterproof Measures If the camera is installed outdoor, you should use the waterproof accessory or tapes to waterproof the cables. Otherwise, the cables might get wet or a short circuit occurs.
  • Page 19 Steps: 1. Feed the network cable through ① and ③ in order. 2. Fix ② on the network cable between ① and ③. 3. Place ⑤ onto the end of ⑥, and plug the RJ45 male connector into RJ45 female connector. 4.
  • Page 20 3. Activate and Access Network Camera Scan the QR code to get Activate and Access Network Camera. Note that mobile data charges may apply if Wi-Fi is unavailable 4. Operate IPCameras via pc Browser You can configure the IPcameras In the LAN network via the IE browser. 1.Power on the camera with a DC 12 V adapter or POE Swtich and connectit to the same router as your computer with a network cable.
  • Page 21 3.Check the box of the camera and then activate the camera by creating alogin password. Note: If the camera is directly connected to ANPVIZ HK Series NVR, or hikvision NVR, the camera does not need to be activated, and can output images by directly connecting to the NVR POE interface through a network cable.
  • Page 22 4.Double click the camera's address or you caninput the IPaddress on the PC browser to enter thelogin page.The default account nameis admin and the passwordis the one youjust set up. 5. Download and install the plug-in to view live video and manage the camera. Close the browser when installing the plug-in.
  • Page 23 7. Alarm Setting Login the IP address of the camera through the browser, enter the camera configuration -Event-motion detection, and set the detection area, sensitivity, alarm schedule, linkage mode, etc. The camera supports Motion2.0 AI technology, which can realize the detection target classification, detect the target Human/Vehicle video, greatly reduce false alarms, and push the Human/Vehicle alarm information more accurately and timely .
  • Page 24 5. Remote Live Stream via Smart phones You can view the IPcamera remotely via your mobile phone with the GuardingVisionApp. 1. Power on the camera with a DC 12 V adapter and connectit to the same router as your computer with a network cable. Make sure the router has connected to the Internet. 2.
  • Page 25 4. Click Read and Agree GuardingVision terms of service to enable GuardingVision service before continuing to add the device. Create a verification code and finish the adding process. After that, the device will be shown in the device list. Click the device name to get live view.
  • Page 26 1.Power on the camera and connectit to the same router as your computer with a network cable. 2.Install the desktop software Guarding Vision/IVMS 4200 and search the camera. You can download Guarding Vision/IVMS 4200 from our website: www.anpvizsecurity.com/download/software&Tools-HK Series https://www.anpvizsecurity.com/download-21725...
  • Page 27 3. Launch Guarding Vision/IVMS 4200 software. The control panel and live view interface of Guarding Vision/IVMS 4200 are shown below. 4.Go to Control Panel-Device Management-Device. At the bottom of the screen and in the Online Devices section, the screen will display all devices on the network. Create a password to active the device if the device's status is inactive.
  • Page 28 6.Go to Control Panel-Main View. If you have added the IP camera, you can get a live view in the screen (as shown in the picture below). For more information, Please press F1 to get user manual 7.View Live Stream with Other Software thats Supports RTSPProtocol The IPcamera supports RTSPprotocol.The camera can be accessed via the VLC player.
  • Page 29 NVR7608Q16P NVR is 8MP, a nd it can only be connected to an IP camera with a resolution of 8MP. 2. Make sure that the NVR is activated and can be used normally. ANPVIZ HK series cameras do not need to activate the camera.
  • Page 30 4. After the ANPVIZ HK Series IPC camera is activated, the onvif function is enabled by default, and the onvif Username and password are the same as those of the C amera. If the connection fails, you can enter the camera menu to check, please go to Configuration ->...
  • Page 31 6.Input the correct ONVIF user name and password of the IPcamera (instead of the login user name and password).The status will be greenif the additionis successful. ClickApply and you will see thelive view.

  • Page 32: Madein China

    Anpviz Security Electronics Co.,Ltd. Tech Support Email Address: Support@AnpvizSecurity.com www.AnpvizSecurity .com Madein China...
