User Manual
ATS-850R
Read all instructions before installation and use.
• This product should only be connected to a 120V outlet.
Our company does not provide warranty for its quality with
different power supplies and voltage.
• The warranty of the product is included in this manual.
Please keep it in a safe place.
220808_ATS-850R USER's MANUAL.indd 1
220808_ATS-850R USER's MANUAL.indd 1
Safety and product information
• Important safeguards
• Product components
Installation & operation
• Installation
• Initial operation
• Operation
SE AT
DR YE
EN ER
R
GY
PR ES
SA VIN
SU RE
G
NO ZZ
LE
PO SIT
ION
WA TER
NO ZZ
LE
CL EA
N
Maintenance
• Maintenance
• Water draining/product detachment
Extra information
• Troubleshooting
• Specifications
• Warranty
2
7
9
11
12
16
18
19
20
22
2022-08-08 오후 3:10:31
2022-08-08 오후 3:10:31
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lotus ATS-850R
Summary of Contents for Lotus ATS-850R
- Page 1 User Manual ATS-850R Safety and product information • Important safeguards • Product components Installation & operation • Installation • Initial operation • Operation SE AT DR YE EN ER PR ES SA VIN SU RE NO ZZ PO SIT WA TER...
- Page 2 Important safeguards • READ ALL INSTRUCTIONS BEFORE INSTALLATION AND USE DANGER - To reduce the risk of electrocution: 1. Do not place or store product where it can fall or be pulled into a tub or sink. 2. Do not place in or drop into water or other liquid. 3.
- Page 3 This Product must be on a separated circuit. No other appliance should share the circuit with this product. WARNING Sharing a circuit could cause the branch circuit fuse to blow or the circuit breaker to trip. Continuous usage under these conditions may result in fire or property damage.
-
Page 4: Important Safeguards
Important safeguards “Important safeguards/general cautions ” are information that can protect the user from safety hazards and also prevent losses. Please be sure to read the manual correctly for proper usage. Indicates potentially hazardous Indicates an imminently situation which, if not avoided, hazardous situation which, may result in minor or moderate Danger... - Page 5 Do not supply electrical power to the product Do not use multiple plugs in one outlet until it is installed on the toilet and the water at the same time. supply hose is properly connected. Prohibited Prohibited • Plugging in may result in a fire or • Do not connect the product to the power wiring of a fan or equipment failure.
-
Page 6: Safety Cautions
Important safeguards Safety cautions Caution Do not stand on top of the seat cover, Do not used a damaged product. seat or main body unit. Prohibited Prohibited • Using damaged product can cause fire or electric shock. Please contact • This can damage or break the unit. customer service office when it’s damaged. Prevent children from putting foreign substances Do not slam or close the seat or seat cover forcefully. or inserting their hands into the dryer outlet or onto the nozzle. -
Page 7: Product Components
Product components Main unit Turbo Wash Lady Seat Cover Caution label Deodorizer (*option) Unit Separation button Warm Dryer Night light Simple key Skin Sensor Nozzle IR receiver part Power/Energy Saving Heated Seat Wash Stop/Power Accessories Manual Pipe Materials Product Mounting Materials Remote controller material (warranty included) User Manual... -
Page 8: Remote Control
Product components Remote control ENERGY SEAT SAVING DRYER NOZZLE PRESSURE POSITION NOZZLE WATER CLEAN ENERGY SEAT SAVING ENERGY Press to use turbo wash the nozzle spray is more SEAT SAVING focused on producing the effect of strong wash, Press this button to stop all operation. ENERGY DRYER NOZZLE... -
Page 9: Order Of Installation
Installation • This is product requires 120V usage. • Please do not plug in the electrical cord prior to installation. • Please consult with a licensed electrician if electrical work is needed, and in case a grounded Warning before outlet is not available, grounding should be done in order to prevent short circuits or electric shock. Installing •... - Page 10 Installation Toilet seat Fixed Bracket rubber nut Toilet Mounting plate Unscrew the nuts on both sides of the Insert each fixed rubber nut into the Place the mounting plate and bracket existing toilet seat to remove toilet mounting hole. in order, on the toilet. the seat and lid.
-
Page 11: Initial Operation
Initial operation Turn the water valve counter clockwise to open, and check if the connected areas ❶ ~ ❺ are not leaking. ❶ ❺ ❷ ❸ ❹ Water valve Connect the power plug to a 120V outlet. • When the plug is connected, the product will make “beep” sound. The product is ready to function. -
Page 12: Operation
Operation Please set seat temperature as 'LOW' when the following persons use it : Please set seat temperature as 'LOW' when the following persons use it : Children, Elderly Special precautions should be taken for children, elderly, those who cannot adjust the Caution temperature and those who have sensitive skin. - Page 13 ENERGY WATER SAVING Water temperature Seat temperature ENERGY NOZZLE WATER SEAT SAVING CLEAN ˙Warm water temperature can be adjusted 5 level(off - 1 - 2 - 3 - 4) by pressing (WATER) button. NOZZLE ENERGY SEAT WATER SAVING ENERGY CLEAN WATER SAVING ˙Seat temperature can be adjusted 5 level(off - 1 - 2 - 3 - 4) by pressing...
- Page 14 Operation ENERGY WATER SAVING ENERGY WATER SAVING Skin sensor NOZZLE SEAT CLEAN NOZZLE SEAT CLEAN ˙ User can turn off the skin sensor on the product. ˙Setting ENERGY WATER SAVING Press the (STOP + NOZZLE CLEAN) button. ENERGY WATER SAVING NOZZLE SEAT CLEAN...
- Page 15 ENERGY 3sec WATER *Simple key SAVING Power ON/OFF NOZZLE SEAT CLEAN ˙ Turn off the product power when the product is not used in long period by pressing (stop/power) button. ENERGY WATER SAVING ˙ Power OFF mode (“be-beep”) NOZZLE SEAT CLEAN Press the simple key Stop/Power) button over 3seconds...
-
Page 16: Maintenance
Maintenance Cleaning the nozzle 1. Automatic nozzle cleaning ENERGY WATER SAVING ˙Press (NOZZLE CLEAN) button for 3 sec while not seated, Automatic nozzle cleaning function NOZZLE SEAT CLEAN will be activated. Water will be sprayed on nozzle while nozzle is moving back and forth. ˙Press stop button to stop this function. - Page 17 Disassembling the toilet seat cover ˙It can be cleaned after the seat cover is removed if it is necessary. ˙How to remove/assemble seat cover ❶ Lift up the right side of seat cover. ❷ Lift up the left side of seat cover. ❸...
- Page 18 Water draining/product detachment When removing product from the toilet for cleaning or relocating, do as the following. Hose for bidet ② Water Valve separation button ① Disconnect power plug from the outlet. Shut the water valve and separate On the side, press the separation button the connected water hose.
-
Page 19: Troubleshooting
Troubleshooting ※ Incorrect Installation and usage may cause the product to cause problems in operating. ※ Users will be charged a certain fee to receive customer services for the following. Symptoms Check the following When water • Check if water supply is cut off. does not come out •... -
Page 20: Specification
Specification Specification ATS-850R Power Rating AC 120 V~ / 60 Hz / 1270 W Water supply method Direct connection to waterworks Water supply Water pressure range 0.07 ~ 0.74 MPa(0.7 ~ 7.5 kgf/cm WASH Max. 650 cc ± 100 cc LADY Max. - Page 21 220808_ATS-850R USER's MANUAL.indd 21 220808_ATS-850R USER's MANUAL.indd 21 2022-08-08 오후 3:10:39 2022-08-08 오후 3:10:39...
-
Page 22: Limited Warranty
General Limited Warranty Covered The Manufacturer, Lotus Hygiene Systems Inc. will warrant to the original retail buyer only, which fails in normal use and within the applicable periods specified below, following the terms of this warranty. Lotus Hygiene Systems Inc. replacement will be warranted to the original purchaser of the products. - Page 23 SEND To ensure your warranty protection, you must complete and return this registration with a copy of the original sales receipt to Lotus Hygiene System Inc. within 15 days after data of purchase to validate your warranty. 1621 E. Saint Andrew Pl.
- Page 24 2022 AUG 0.0 2022 MAR 0.0 Lotus Hygiene Systems Inc. www.LotusSeats.com Tel: 1-877-808-0055 Email: info@lotusseats.com 220808_ATS-850R USER's MANUAL.indd 24 220808_ATS-850R USER's MANUAL.indd 24 2022-08-08 오후 3:10:40 2022-08-08 오후 3:10:40...
