Page 1: Operation Manual
SPLIT TYPE ROOM AIR CONDITIONER OPERATION MANUAL HSU-09LEB13-H HSU-12LEB13-H HSU-14LEB13-H Please read this operation manual before using the air conditioner. 0010515267... - Page 2 Safety Instructions and Warnings Before disposing an old air conditioner that Before starting the air conditioner, read the goes out of use, please make sure it's inop- information given in the User's Guide caref- erative and safe. Unplug the air conditioner ully.
-
Page 3: Specifications
3. If the fuse of indoor unit on PC board is broken,please change it with the type of T. 3.15A/ 250V. 4. The wiring method should be in line with the local wiring standard. -
Page 4: Safety Instruction
Do not attempt to install the air conditioner by yourself because improper works may cause electric shock, fire, water leakage. lnstallation in a inadequate place may cause accidents. Do not install in the following place. CAUTION Do not install in the... - Page 5 PROHIBITION PROHIBITION CAUTION Take fresh air occasionally especially Do not operate the switch with Do not use for the purpose of storage of food, art work, precise equipment, when gas appliance is running at the wet hand. breeding, or cultivation.
-
Page 6: Parts And Functions
Horizontal flap (adjust up and down air flow. Don't adjust it manually) Vertical blade (adjust left and right air flow) Actual inlet grille may vary from the one shown in the manual according to the product purchased Outdoor Unit HSU-09LEB13-H HSU-12LEB13-H... -
Page 7: Clock Set
6. LOCK display displayed and this room temperature is only for reference. Clock set When unit is started for the first time and after replacing batteries in remote controller, clock should be adjusted as follows: Press CLOCK button, "AM" or "PM" flashes. -
Page 8: Remote Controller's Operation
When sudden power failure happens during unit operation in power failure resume mode, the air conditioner is not desired for use in a long period, please shut off the power supply in case that the unit automatically resume operation when power is re-supplied,... -
Page 9: Auto Operation
Press ON/OFF button, the unit stops. Hints Remote controller can memorize settings in each operation mode. To run it next time just select the operation mode and it will start with the previous setting. No reelecting is needed.(TIMER ON/OFF、SLEEP、SWING needs reelecting) -
Page 10: Cool Operation
Hints On cooling only unit, heating mode is not available. Remote controller can memorize each operation status. When starting it next time, just press ON/OFF button and unit will run in previous status. No reelecting is needed.(TIMER ON/OFF、SLEEP、SWING needs reelecting) -
Page 11: Dry Operation
Hints On cooling only unit, heating mode is not available. Remote controller can memorize each operation status. When starting it next time, just press ON/OFF button and unit will run in previous status. No reelecting is needed.(TIMER ON/OFF、SLEEP、SWING needs reelecting) -
Page 12: Fan Operation
Press ON/OFF button, the unit stops. Hints In FAN operation mode, the unit will not operate in COOL mode but only in FAN mode , AUTO is not available in FAN mode.And temp.setting is disabled. In FAN mode,SLEEP operation is not available. -
Page 13: Air Flow Direction Adjustment
Do not try to adjust the flap by hand. When adjusting the flap by hand,turn off the unit ,and use the remote controller to restart the unit. When humidity is high,condensate water might occur at air outlet if all vertical louvers are adjusted to left or right. -
Page 14: Operation Mode
It has no SLEEP function. When TIMER function is set, the sleeping function can't be set up .After the sleeping function is set up, if user resets TIMER function, the sleeping function will be cancelled; the machine will be in the state of timing-on. -
Page 15: Timer On/Off Operation
Timer On/Off Operation Set Clock correctly before starting Timer operation You can let unit start or stop automatically at following times: Before you wake up in the morning, or get back from outside or after you fall asleep at night. - Page 16 Follow the same procedures in "Time setting for TIMER ON". (6) Time confirming for TIMER OFF After time setting, press SET button to confirm, "OFF" stops flashing Time displayed: Unit stops at X hour X min. To cancel TIMER mode...
-
Page 17: Emergency Operation
Removal of the restriction of emergency or test operation: Press the emergency operation switch once more, or manipulate through the remote controller; the "Pi" sound, the emergency or test operation is terminated. When the remote controller is manipulated, it gets the system back to the normal operation mode. -
Page 18: Maintenance
Use the timer effectively during operation During cooling operation prevent the penetration of direct sunlight with curtain or blind Use the louvers effectively If the unit is not to be used for a long time, turn off the power supply main switch. -
Page 19: Remote Controller
Maintenance For Smart Use of The Air Conditioner WARNING Before maintenance,be sure to turn off the system and the circuit breaker. Remote Controller Indoor Body Wipe the air conditioner by using a soft and dry cloth.For serious stains,use a neutral Do not use water ,wipe the controller with a detergent diluted with water.Wring the water... -
Page 20: Replacement Of Air Purifying Filter
The photocatalyst air purifying filter will be solarized in fixed time. In normal family, it will be solarized every 6 months. The bacteria-killing medium air purifying filter will be used for a long time,no need for replacement. But in the period of using them ,you should remove the dust frequently by using vacuum cleaner or flaping them lightly,otherwise ,its performance will be affected. -
Page 21: Troubleshooting
Should there be a big noise from air flow in unit operation, air filter may be too dirty. This is because the system circulates smells from the interior air such as the smell of Smells are generated.
