IGM VP-PHJ1 Manual

- EN
Manual
Pocket Hole Jig
Manual
Dear Customer,
thank you for the confidence you have placed in us with
the purchase of your new IGM jig. This manual was
prepared for the owner and operator of IGM Pocket
Hole Jig to promote safety during setup, operation and
maintenance. Please read carefully and understand the
information contained in this manual. To obtain
maximum service life and performance, use the jig
according to these instructions and safety guidelines.
Observe work safety.
We wish you a lot of work satisfaction and joy when
working with the IGM Pocket Hole Jig.
Intended Use
This jig is designed only for joining wood and wooden
materials by pocket hole joints. To join the material, use
appropriate screws.
Warranty
IGM always strives to deliver a high-quality and efficient
product. The warranty is governed by the valid terms
and conditions of IGM.
Safety Instructions
Warning! Read all instructions and safety guidelines.
Failure to follow safety instructions may result in
damage to the jig and serious injury to the operator.
Keep the manual for future reference.
- Check the technical condition of the jig and cutting
tool before work. The cutting tool must be sharp
and free from damage. Do not use the jig or cutting
www.igmtools.com
VP-PHJ2S Pocket Hole Jig Manual EN v1.1.00 A4ob
tool when damaged.
- The working area must be clean and well-lit. There
must be sufficient space around the work area.
- Take care of your safety when working. Long hair,
loose clothing and jewellery may cause injury. Wear
suitable work clothing, footwear and eye, ear and
respiratory protec�on.
- Watch your hands and fingers. Always use both
hands when working with the jig.
- Ensure that the jig is held securely in place. If
necessary, use a clamp. Never hold the jig with your
hand while working!
- Keep the jig out of reach of children and unqualified
persons.
- Do not leave the jig in a damp environment and do
not expose it to rain.
Symbols
Warning of general danger.
Wear work gloves.
Use ear protection. Use eye protection. Use
respiratory protection.
Specification
Minimum Workpiece Thickness:
Maximum Workpiece Thickness:
Drill Bit:
Shank:
Drill Length:
Driver Bit:
Shank:
1
VP-PHJ1
VP-PHJ2
VP-PHJ2S
2024-04-26
12,7 mm
38 mm
9,5 mm
hex
158 mm
square, #2
hex
