FLYCLE FY29635 Installation Instructions

Installation Instructions
Fig. 1-1
Fig. 2-1
Fig. 2-2
rubber tab
Fig. 2-3
1. Prepare the Roof Rail for Crossbar
Front of
Installation
Vehicle
(a) Using a nylon panel removal tool, carefully
STOP
NOTE: Remove and save all four cap covers.
(b) Neatly open the hardware bag and remove
Front of
Vehicle
2. Install the Front Crossbar
(a) Locate "FRT RH/LH" with the directional
(b) Place the crossbar supports inside the roof
NOTE: Align the crossbar support through hole
with the roof rail support threaded hole.
(c) Insert the M8 vehicle attachment bolt and
NOTE: The head of the bolt is on the same side
STOP
as the prongs on the anti-rotation clips (Fig. 2-2).
(d) Repeat on the other side.
(e) Make sure rubber pads are flushed to support
(f) Hand start the bolts.
(g) Fasten bolts using electric wrench (None
(h) Torque bolts to 12 N.m. (Fig. 2-4).
Torque: 12 N•m (106 in.lb)
DESCRIPTION:
FOR 2019+ TOYOTA RAV4
insert into the roof rail cap covers notch and
pry four cap covers completely off from roof
rail (Fig. 1-1).
the M8 vehicle attachment bolts and anti-
rotation clips.
arrow on the bottom of the right-hand side
and left-hand side of the supports (Fig. 2-1).
rail openings.
the anti-rotation clip (Fig. 2-2).
of cross bar. If necessary, pull rubber tab
through hole (Fig. 2-3).
impact).
CROSSBAR KIT
