HSP03WNAWWdoc
10/22/01
12:35 PM
Page 1
Compact
Refrigerators
Refrigerador
Compacto

User Manual-

Model # HSP03WNAWW
Manual del Usuario-
para modelos de HSP03WNAWW

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HSP03WNAWW - 10-00 and is the answer not in the manual?

Questions and answers

Randy l Mallett
June 16, 2025

Cubic feet

Summary of Contents for Haier HSP03WNAWW - 10-00

  • Page 1: User Manual

    HSP03WNAWWdoc 10/22/01 12:35 PM Page 1 Compact Refrigerators Refrigerador Compacto User Manual- Model # HSP03WNAWW Manual del Usuario- para modelos de HSP03WNAWW...
  • Page 2: Safety Precautions

    "…Thawed ground meats, poultr y, or fish that have any off-odor or off-color should not be refrozen and should not be eaten. Thawed ice cream should be discarded. If the odor or color of any food is poor or questionable, discard it. The food may be dangerous to eat."...
  • Page 3 12:35 PM Page 3 English English 10) This refrigerator should not be recessed or built-in an enclosed cabinet. It is designed for freestanding installation only. 11) Do not operate your refrigerator in the presence of explosive fumes. For Future Reference Please...
  • Page 4: Table Of Contents

    General Features..................8 Refrigerator Interior Shelves ..............8 Adjusting Bottle Hugger ................9 Defrosting....................9 Food Storage Information ..............10 Normal Operating Sounds..............11 Proper Refrigerator Care and Cleaning ........12 Cleaning and Maintenance ..............12 Power Interruptions ................13 Vacation and Moving Car e ..............13 Troubleshooting................14 Warranty Information ..............16...
  • Page 5: Parts And Features

    HSP03WNAWWdoc 10/22/01 12:36 PM Page 5 English Parts And Features 1. Freezer Compartment 5. Drip Tray 2. Ice Cube Tray 6. Temperature Control 3. Full Width Shelf 7. Hugger 4. Storage Shelf 8. Full Width Retainer Bar...
  • Page 6: Installing Your Refrigerator

    English Installing Your Refrigerator Unpacking Your Refrigerator 1. Remove all packaging material. This includes the foam base and all adhesive tape holding the refrigerator accessories inside and outside. Slide out and remove plastic or foam guard used to secure the compressor from shipping damage due to vibration and shock.
  • Page 7: Electrical Requirements

    • Make sure there is a suitable power Outlet (115 volts, 15 amps outlet) with proper grounding to power the refrigerator. • Avoid the use of three plug adapters or cutting off the third grounding in order to accommodate a two plug outlet. This is a dangerous practice since it provides no effective grounding for the refrigerator and may result in shock hazard.
  • Page 8: Door Alignment

    2. Remove the top hinge cover. 3. Loosen the top hinge screws using a phillips head screwdriver. 4. Adjust the door or put a spacer in between and then tighten the screws. 5. Replace the top hinge cover. fig. # 1...
  • Page 9: Refrigerator Features And Use

    Refrigerator Interior Shelves To remove or replace a full-width slide-out shelf: (see fig. # 2) 1. Gently tilt the shelf up and slide forward until the shelf has been completely removed. 2. To replace the shelf, gently slide the shelf back.
  • Page 10: Adjusting Bottle Hugger

    Page 10 English English Adjusting Bottle Hugger (see fig # 3) 1. Grasp the hugger firmly and slide right or left until it is snug against the items stored on the shelf. shelf bottle hugger fig. # 3 Defrosting Your Refrigerator (see Fig.
  • Page 11: Food Storage Information

    Food Storage Information Fresh Food • When storing fresh food, which is not prepackaged, be sure to wrap or store food in airtight and moisture proof material unless otherwise noted. This will ensure proper shelf life and prevent the transfer of odors and tastes.
  • Page 12: Normal Operating Sounds

    English English Normal Operating Sounds You May Hear • Boiling water, gurgling sounds or slight vibrations that are the result of the refrigerant circulating through the cooling coils. • The thermostat control will click when it cycles on and off.
  • Page 13: Proper Refrigerator Care And Cleaning

    Use sponge or soft cloth, dampened with the cleaning solution, to wipe down your refrigerator. • Rinse with clean warm water and dry with a soft cloth. • Do not use harsh chemicals, abrasives, ammonia, chlorine bleach,concentrated detergents, solvents or metal scouring pads.
  • Page 14: Power Interruptions

    Power Interruptions • Occasionally there may be power interruptions due to thunderstorms or other causes. Remove the power cord from AC outlet when a power outage occurs. When power has been restored, replug power cord to AC outlet. If outage is for a prolonged period, inspect and discard spoiled or thawed food in freezer and refrigerator.
  • Page 15: Troubleshooting

    • Check if thermostat control is not in the “OFF” position. • Check if refrigerator is plugged in. • Check if there is power at the ac outlet, by checking the circuit breaker. Food temperature appears too warm • Frequent door openings.
  • Page 16 • Check door gaskets for proper seal. Refrigerator has an odor: • Interior needs cleaning. • Foods improperly wrapped or sealed are giving off odors. Refrigerator door does not shut properly: • Re-align refrigerator door. • Check for blockages e.g. food containers, crisper cover,...
  • Page 17: Warranty Information

    What will be done? or consequential damages, so the above limitations may not apply to you. Some 1. We will repair or replace, at our dis- States do not allow limitations on how cretion any mechanical or electrical long an implied warranty lasts, so the part which proves to be defective in above limitations may not apply to you.
  • Page 18 IMPORTANTE No regrese este producto a la tienda Si tiene algún problema con este producto, por favor contacte el "Centro de Servicio al Consumidor de Haier" al 1-877-337-3639 (Válido solo en E.U.A). NECESITA UNA PRUEBA DE COMPRA FECHADA PARA EL SERVICIO DE LA GARANTIA...
