- Page 1 HSP02WNB MANUAL 10/22/01 12:34 PM Page 1 Compact Refrigerator Réfrigérateur Compact Refrigerador Compacto User Manual- Model # Guide de l’Utilisateur- Modèle HSP02WNB Manual del Usuario- Para Modelo de...
-
Page 2: Safety Precautions
"…Thawed ground meats, poultr y, or fish that have any off-odor or off-color should not be refrozen and should not be eaten. Thawed ice cream should be discarded. If the odor or color of any food is poor or questionable, discard it. The food may be dangerous to eat."... - Page 3 10/22/01 12:34 PM Page 3 English 10) This refrigerator should not be recessed or built-in an enclosed cabinet. It is designed for freestanding installation only. 11) Do not operate your refrigerator in the presence of explosive fumes. SAVE THESE INSTRUCTIONS DANGER Risk of child entrapment.
-
Page 4: Table Of Contents
General Features..................10 Refrigerator Interior Shelves..............10 Using The Lock ..................11 Defrosting....................12 Food Storage Information ..............13 Normal Operating Sounds..............13 Proper Refrigerator Care and Cleaning ........14 Cleaning and Maintenance ..............14 Power Interruptions ................15 Vacation and Moving Care ..............15 Troubleshooting ................16 Warranty Information ..............17... -
Page 5: Parts And Features
HSP02WNB MANUAL 10/22/01 12:34 PM Page 5 English Parts And Features 1. Ice Cube Tray 4. Full Width Refrigerator Shelf 2. Adjustable Temperature Control 5. Fixed Door Shelf 3. Freezer Compartment 6. Lock and Key... -
Page 6: Installing Your Refrigerator
2. Inspect and remove any remains of packing, tape or printed materials before powering on the refrigerator. Leveling Your Refrigerator • Your refrigerator has leveling legs which are located at the bottom of your refrigerator. After properly placing your refrigerator in its final position, you can level your refrigerator. -
Page 7: Electrical Requirements
• Make sure there is a suitable power Outlet (115 volts, 15 amps outlet) with proper grounding to power the refrigerator. • Avoid the use of three plug adapters or cutting off the third grounding in order to accommodate a two plug outlet. This is a dangerous practice since it provides no effective grounding for the refrigerator and may result in shock hazard. -
Page 8: Door Alignment
2. Remove the top hinge cover. 3. Loosen the top hinge screws using a phillips head screwdriver. 4. Adjust the door or put a spacer in between and then tighten the screws. 5. Replace the top hinge cover. fig. # 1... -
Page 9: Door Reversal
Insert and tighten the screws.(see fig. # 3) 8. Align the bottom hole on the left side of the door with the pin of the lower hinge and slide into place. - Page 10 Page 10 English 9. Align the pin of the top hinge with top hole on the left side of the door and push into place. Replace the screws in the upper hinge bracket but do not tighten all the way. (see fig. # 2) 10.
-
Page 11: Refrigerator Features And Use
Refrigerator Interior Shelves To remove or replace a full-width slide-out shelf: (see fig. # 4) 1. Gently tilt the shelf up and slide forward until the shelf has been completely removed. 2. To replace the shelf, gently slide the shelf back. -
Page 12: Using The Lock
English Using the Lock • Your refrigerator is equipped with a lock and key (located at the bottom center of the door) for optional security, should you choose. Simply close the refrigerator door, insert the key and turn. To open, insert the key and turn in the opposite direction. -
Page 13: Defrosting
Note that frost tends to accumulate more during the summer months. • To defrost, remove the food and ice cube tray from the freezer section. Make sure the drip tray is under the freezer section and push the defrost button on the thermostat. -
Page 14: Food Storage Information
Food Storage Information Fresh Food • When storing fresh food, which is not prepackaged, be sure to wrap or store food in airtight and moisture proof material unless otherwise noted. This will ensure proper shelf life and prevent the transfer of odors and tastes. -
Page 15: Proper Refrigerator Care And Cleaning
Use sponge or soft cloth, dampened with the cleaning solution, to wipe down your refrigerator. • Rinse with clean warm water and dry with a soft cloth. • Do not use harsh chemicals, abrasives, ammonia, chlorine bleach,concentrated detergents, solvents or metal scouring pads. -
Page 16: Power Interruptions
Power Interruptions • Occasionally there may be power interruptions due to thunderstorms or other causes. Remove the power cord from AC outlet when a power outage occurs. When power has been restored, replug power cord to AC outlet. If outage is for a prolonged period, inspect and discard spoiled or thawed food in freezer and refrigerator. -
Page 17: Troubleshooting
• Check if thermostat control is not in the “OFF” position. • Check if refrigerator is plugged in. • Check if there is power at the ac outlet, by checking the circuit breaker. Food temperature appears too warm • Frequent door openings. -
Page 18: Warranty Information
1. The mechanical and electrical parts, authorized dealer or service center. which serve as a functional, purpose Decorative trims or replaceable of this appliance for a period of 12 light bulbs. months. This includes all parts except Transportation and shipping. - Page 19 IMPORTANTE No regrese este producto a la tienda Si tiene algún problema con este producto, por favor contacte el "Centro de Servicio al Consumidor de Haier" al 1-877-337-3639 (Válido solo en E.U.A). NECESITA UNA PRUEBA DE COMPRA FECHADA PARA EL SERVICIO DE LA GARANTIA...
