- Page 1 DHW HEAT PUMP Installation and owner's manual MUACS-200-H14 MUACS-300-H14 MUACS-200S-H14 MUACS-300S-H14 CL45006 - CL45007 CL45016 - CL45017 English www.mundoclima.com...
-
Page 2: Table Of Contents
TABLE OF CONTENT Explanation of symbols display on the unit...................... 1 Safety instructions ..............................1 Warning .................................. 1 Cautions ................................. 3 Special requirements for R290 ...........................5 INTRODUCTION ..............................6 This manual ..............................6 The unit ................................6 SAFETY INSTRUCTIONS ..........................7 Warning ................................ -
Page 3: Explanation Of Symbols Display On The Unit
Explanation of symbols display on the unit. This symbol shows that this appliance used a flammable WARNING refrigerant. If the refrigerant is leaked and exposed to an external ignition source, there is a risk of fire. This symbol shows that the operation manual should be CAUTION read carefully. - Page 4 machine in a closed area or limited space, please consider the size and ventilation of the room to prevent suffocation due to refrigerant leakage. That the appliance shall be disconnected from its power source during service and when replacing parts and, if that the removal of the plug is foreseen, it shall be clearly indicated that the removal of the plug has to be such that an operator can check from any of the points to which he has access that the plug remains removed.
-
Page 5: Cautions
Burns or frostbite are possible if you touch the refrigerant pipes. To avoid injury, give the pipes time to return to normal temperature or, if you must touch them, be sure to wear protective gloves. Do not touch the internal parts (pump, backup heater, etc.) during and immediately after operation. - Page 6 - Where acidic or alkaline vapors are present. This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources.
-
Page 7: Special Requirements For R290
If the power cord is damaged, it must be replaced by the manufacturer or its service agent or the same professional person to avoid danger. The cut-off device shall be incorporated into the fixed wiring, and the contact spacing gap of each effective conductor shall be at least 3mm. -
Page 8: Introduction
INTRODUCTION This manual This manual includes the necessary information about the unit. Please read this manual carefully before you use and maintain the unit. The unit The hot water heat pump is one of the most economical systems to heat the water for family domestic use. -
Page 9: Safety Instructions
SAFETY INSTRUCTIONS To prevent injury to the user, other people, or property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. Install the unit only when it complies with local regulations, by-laws and standards. Check the main voltage and frequency. -
Page 10: Caution
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. -
Page 11: Items Inside Product Box
ITEMS INSIDE PRODUCT BOX Before starting the installation, please make sure that all parts are found inside the box. The Unit Box Item Image Quantity Domestic hot water heat pump Operation and Installation Manual... -
Page 12: Overview Of The Unit
OVERVIEW OF THE UNIT Parts and descriptions... -
Page 13: Dimensions
Dimensions 200L 300L Φ565 Φ646 Φ177 Φ177 1135 1265 1185 1315 1020 1155 1750 1850 Φ560 Φ640 Remark: 1) The extra heat source is optional. 2) Add the solar control. While the parameter 14= 1, solar energy control is available. The terminal “TO PUMP”... -
Page 14: Schematic Overview Of The Water And Refrigeration Circuit
3) This heat pump uses electronic anode for anti-corrosion. 4) The electronic anode for anti-corrosion no need maintenance, consists of controller and titanium electrode, which makes sure the inner wall of the stainless steel tank is always protected against corrosion. When the controller reports the related fault of the electronic anode, please contact the local service provider for on-site repair in time. -
Page 15: Transportation
Make sure that there’s no remora around the unit. In the place where there is strong wind, fix the unit in the location protected from the wind. Transportation As a rule, the unit is to be stored and/or transported in its shipping container in upright position and without water charge. -
Page 16: Required Service Space
Required service space Below you will find the minimum space required to be able to complete service and maintenance tasks on the units. Note: If air inlet and/or outlet pipes are connected, portion airflow and capacity in heat pump unit will lose. -
Page 17: Installation Overview
Installation overview Note: 200S and 300S models have solar heat exchange coil. ATTENTION: The one-way safety valve must be installed. If not, it could cause damage to the unit, or even hurt people. The set point of this safety valve is 0.7 MPa. For the installation place please refer to the pipeline connection sketch. -
Page 18: Installation Positions
If the inlet water pressure is less than 0.15MPa, a pressure pump should be installed at the water inlet. For ensure the long safety using age of tank at the condition of water supply hydraulic higher than 0.65MPa, a reducing valve should be mounted at the water inlet pipe. Filters are needed in the air inlet. -
Page 19: Water Loop Connection
Water loop connection Please pay attention to the below points when connecting the water loop pipe: 1. Try to reduce the water loop resistance 2. Make sure there is nothing in the pipe and the water loop is smooth, check the pipe carefully to see if there is any leak, and then pack the pipe with the insulation. -
Page 20: Trial Running
Trial running Checks before trial running Check both the water in the tank as well as the water pipe connection. Check the power system, make sure that the power supply is normal and the wire connection is ok. ... -
Page 21: Operation The Unit
OPERATION THE UNIT User interface and operation Electrical heater Set button ‘ON’/’OFF’ button Unit ‘ON’/’OFF’ button Clock/Timer setting button DOWN adjust button UP adjust button Operations 1. Power ‘ON’ When turning ‘ON’ the power, whole icons are displayed on the controller screen for 3 seconds. - Page 22 These are the multi-purpose buttons. They are used for the temp setting, parameter setting, parameter checking, clock adjustment and adjustment of the timer. During running status, press button to adjust the setting temperature directly. Press these buttons when the unit is on clock setting status, the hour(s) and the minute(s) of the clock time can be adjusted.
-
Page 23: Led Icons
-Press the buttons to check the system parameters. 3) Adjust the system parameters - When the unit is off, press for 5 seconds, entry the parameter checking interface. - Press button to select the parameter, and press button to confirm it. - Press the buttons to adjust the selecting parameter, then press confirm the setting. - Page 24 When checking or adjusting the parameters, this section will display the relating parameter number. In case any malfunction occurs, this section will display the related error code. 8. Right temperature display The display shows the current downside temperature of the water tank. When checking or adjusting the parameters, this section will display the related parameter value.
-
Page 25: Wifi
WIFI Install the App Method I: Scan the QR code to download the App, Smart Life-Smart Living, for iOS system and Android system. Finish the download and install it. Notes: Please scan the QR code by browser for Android system. Method 2: Search the App, Smart Life-Smart Living, in App store for iOS system or in Google Play Store for Android system. - Page 26 Click "Agree". Choose country and type mobile number or email address to get the message of verification code. Please set the password, and remember it. App configuration After setting the password to log in the app, add the device. Click "Large HomeApplications" and "Water Heater"...
- Page 27 Please connect the Wi-Fi module with heat pump unit. At the same time, please keep the module and mobile devices can receive the same networks. Method 1: Power on the heat pump unit, and keep pressing the button and the button at the same time for 5 seconds.
- Page 28 Notes: when the icon flashes quickly,it mean the controller is in the Wi-Fi mode. When it flashes slowly, it means the controller is connecting with the App. During the connection, if the icon is extinguished, it means the App connection with the unit is finished. If the mobile is not connected with Wi-Fi from the router, the interface will beautomatically skipped to the following interface.
- Page 29 After click "Confirm", the Wi-Fi module, mobile device and Wi-Fi router begin to beconnected. Finsih the connecting, and the interface will be skipped to the next interface. In this interface, the device (heat pump unit) can be named as you want. Click "Done" to finish the App installation.
- Page 30 Modifybutton Click it to enter the modify interface. Temperature setting bar Move the ball to left or right by finger to set the setting temperature. Setting temperature value This value will be changed according to the location of the ball in the temperature setting bar. Water temperature value in thetank.
- Page 31 Running mode icon of the ehat pumpunit According to the mode selection, this icon will display Auto Mode, Cooling Mode and Heating Mode. Timer button Press this button to enter timer interface. Click "Add" to set the schedule. Please in this interface, setting the time and day for timer on and timer off. After setting, please click "Save"...
- Page 32 Slide the schedule from left to right to delete the schedule. On/Offbutton Click this button to switch on or switch off the heat pump unit.
-
Page 33: Parameter Checking And Adustment
PARAMETER CHECKING AND ADUSTMENT Parameter list Some parameters can be checked and adjusted by the controller. Below is the parameter list. Parameter Description Range Default Remarks Tank water setting temp. 10 ~ 70°C 50°C Adjustable Water temperature 2 ~ 15°C 5°C Adjustable gap to restart... -
Page 34: Malfunctioning Of The Unit And Error Codes
be shown in case of a malfunction Actual testing value. Error code P2 will Upper tank water temp. -9 ~ 99°C be shown in case of a malfunction Actual testing value. Error code P3 will Evaporator coil temp. -9 ~ 99°C be shown in case of a malfunction Actual testing value. - Page 35 3) PCB board failure 3) change the PCB board 1）Fill the tank with water 1）Lack of tank water Electronic anode 2）Circuit of electronic anode 2）Connect the circuit well or output open or is open or short replace an electronic anode short circuit 3）Replace a PCB board 3）PCB board failure...
-
Page 36: Maintenance
1) solar water circuit water 1) Solar water circuit fluid flow very little or without infusion and exhaust Solar thermal water flow 2) Related connecting wires collector high 2) Related connecting wires being reconnected tem protection 3) Change the water pump 3) Water pump failure 4) change the PCB board 4) PCB board failure... -
Page 37: Troubleshooting
freeze and split the pipe. Keep the unit clean by means of soft damp cloth, no maintenance is required by the operator. It is recommended to clean the tank and e-heater regularly to keep an efficient performance. It is recommended to set a lower temperature to decrease the heat release, prevent scale and ... -
Page 38: Wiring Diagram
local and national legislation. Units must be treated at a specialized treatment facility for re-use, recycling and recovery. By ensuring that this product is disposed off correctly, you will help to prevent potential negative consequences for the environment and human health. Please contact the installer or local authority for more information. - Page 39 MUACS-200-H14 / MUACS-300-H14 Electronic anode...
-
Page 40: Technical Specification
TECHNICAL SPECIFICATION MUACS- TECHNICAL DATA 200-H14 / 200S-H14 300-H14 / 300S-H14 Power supply V/Ph/Hz 220~240V/1/50Hz Water tank Volume Max power input 600+1500 (e-heater) Max current 2.61+6.8 (e-heater) Max.outlet water temperature °C range(without using E-heater) Max. water temperature °C Min. water temperature °C Ambient working temp. -
Page 41: Temperature Sensor R-T Conversion Table
TEMPERATURE SENSOR R-T CONVERSION TABLE Ｒ25= 5.0KΩ±1.0％ Ｂ25-50 = 3470K±1.0％ Rmax Rmin KΩ Rmax/ ℃ Rmin KΩ Rmax/ Rmin KΩ ℃ ℃ /KΩ KΩ /KΩ / KΩ /KΩ KΩ 36.195 37.303 38.441 5.779 5.847 5.914 1.343 1.374 1.406 34.402 35.437 36.499 5.558 5.62... - Page 42 Resistance characteristic of solar temperature sensor Ｒ25= 50KΩ±1.0％ Ｂ25-50 = 3950K±1.0％ Resistance Resistance Resistance Resistance Temp. Temp. Temp. Temp. (°C) (°C) (°C) (°C) value ( kQ) value ( kQ) value ( kQ) value ( kQ) 12.33 3.278 466.6 62.41 441.1 59.68 1 1.89 3.182...
