Permobil ROHO MOSAIC Operation Manual page 5

Important Safety Information, continued
Warnings – Motor Vehicle Transportation:
- Failure to pay attention to these warnings could result in severe injury to the individual in the wheelchair or to others.
- Whenever possible, transfer out of the wheelchair and into a manufacturer–installed vehicle seat without the cushion, and use the vehicle's
crash–tested occupant restraint system.
- The cushion must be correctly and securely installed, used, and maintained according to the instructions and warnings provided by the
cushion manufacturer.
- When the wheelchair is used as the vehicle seat, the cushion should only be used with wheelchair frames that are equipped with securement
points specified in ANSI/RESNA WC–4:2017, section 19 (WC19) or ISO 7176–19, and that have been successfully crash tested on a
wheelchair in the forward–facing position.
- The wheelchair with the cushion must be used with an effective wheelchair securement system and a properly positioned, crash–tested pelvic
and shoulder–belt restraint, or Wheelchair Tiedown and Occupant Restraint System (WTORS), following the manufacturer's instructions.
- If the cushion has been involved in an accident during transport, check the cushion for damage and replace if necessary. See the
"Troubleshooting" section in this manual.
- For more information about safely transporting wheelchair users, refer to: https://wc-transportation-safety.umtri.umich.edu/ride-safebrochure.
- A ROHO QUADTRO SELECT Cushion was included in a wheelchair seating system that was dynamically tested by a third–party testing
facility for use in a motor vehicle. The system tested meets all applicable criteria for wheelchair seating systems proposed in Section 5.1 of
ANSI/RESNA WC–4:2017 Section 20 "Wheelchair Seating Systems for Use in Motor Vehicles.
- Test results apply to seating systems intended for use by adults and children with a total body mass greater than 23 kg (51 lb, or approximately
6 years of age) who are transported facing forward in their wheelchairs in all types of motor vehicles.
- To determine whether motor vehicle third–party testing has been performed with a specific seating system combination, refer to all provided
equipment operation manuals or contact the equipment manufacturer.
Parts Detail
Package contents: cushion, cover*, repair kit, hand pump,
operation manual, limited warranty supplement.
*Instructions are provided with the cover.
To order replacement parts, contact the product provider or
Customer Support.
The serial number label is located on the bottom of the cushion.
Cushion expected lifetime: 5 years
Product Specifications
Cushion sizing (all measurements are approximate):
Model W x D in.
1616 16¼ x 16¼
1618 16¼ x 18¼
1717 17¼ x 17¼
1816 18¼ x 16¼
1818 18¼ x 18¼
2018 20¼ x 18¼
Cushion materials: flame–retardant PVC film (made
without DEHP); inflation valve: Zytel
Cover materials: Refer to the care label on the cover.
ROHO MOSAIC Cushion Operation Manual
W x D cm
41.5 x 41.5
41.5 x 46.5
44.0 x 44.0
46.5 x 41.5
46.5 x 46.5
51.5 x 46.5
- ROHO Heavy Duty Cushion Cover
- ROHO Standard Cushion Cover
Cushion
Air Cells
Back
Front
Inflation Valve
Width (W) and Depth (D) are measured
edge to edge; includes a ½ in. (1 cm)
perimeter
Cell Height Range: 2½ – 3 in. (6.5 – 7.5 cm)
D
1 in. = 2.54 cm = 25.4 mm
W
Covers and Accessories Compatible with MOSAIC
Not available in all markets. Contact Customer Support.
- ROHO Planar Solid Seat Insert
- ROHO Contour Base
3
Hand Pump
Repair Kit
