Alarm.Com ADC-V729 Installation Manual page 6

To wire, mount, and power the ADC-V729AC:
Caution: There is a risk of electrical shock when installing the ADC-V729AC. Ensure the power is off at the circuit
breaker before doing any work.
To wire the ADC-V729AC:
1. Connect the neutral green wire to connect to the corresponding ground wire. Use the included wire nut to secure
the wires together.
2. Connect the white wire to the corresponding neutral white wire. Use the included wire nut to secure the wires
together.
3. Connect the black wire (hot) to the corresponding black wire. Use the included wire nut to secure the wires
together.
4. Gently pull on the wires to ensure they are secure.
To mount the ADC-V729AC:
1. Push the wires back into the junction box.
2. Disconnect the hook and align it along the bottom of the unit, or place the hook with the wires in the junction box.
3. Align the two holes on the back of the floodlight base with the metal poles.
a. For HWV 0104+ the mounting screws come captive in the unit. To install the unit on the mounting bracket for
HWV 0104:
i. Remove the weatherproof caps.
ii. Align the two holes on the back of the floodlight base with the metal poles and push the unit into
bracket.
