HyperHanger
Setup Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the HyperHanger and is the answer not in the manual?

Questions and answers

Related Manuals for Hyperspace HyperHanger

Summary of Contents for Hyperspace HyperHanger

  • Page 1 HyperHanger Setup Guide...

  • Page 2: What's In The Box

    The HyperHanger is a hanger designed to suspend the HyperCube15 (HC15) only. It is made from aluminum and polycarbonate with a weight capacity >100lb, while the HC15 weighs only 15lb. Once suspended, the HyperHanger securely latches onto the cube and will hold it in place indefinitely.
  • Page 3 Setting Up Watch the setup video by scanning the QR code: Or follow the instructions below. Attach 1x Strut (A) to 1x Corner (B), using 2x Nuts and Bolts (C). Use a Phillips-head screwdriver and an M5 wrench or pliers to securely tighten.
  • Page 4 Note: Again, while tightening the Nuts, position the pieces so the Strut and second Corner is suspended in the air, as shown to the right. This will ensure it is in a position that best latches to the cube. Repeat steps 1-2 twice, until there are 3x Struts (A) coming out of a central Corner Bracket (B).
  • Page 5 Attach the assembled Hanger to your HyperCube15 With the cube on a table, position the cord along the table. Place the central corner of the hanger over the corner of the cube opposite the cord. Pull all three Corners of the hanger over the corners of the cube. You may need to slide one corner of the cube off the table to attach the last corner.
  • Page 6 Firmly tighten any remaining bolts on the hanger if needed. Note: the hanger is not intended to be fully locked into place at this stage. It may shift when moved or feel slightly loose. Once hung, tension from the cables will keep it tightly held in place. Attach the loose ends of the three Cables (F) on the hanger to 1x Large Carabiner (E).
  • Page 7 10. (Optional) Attach the Controller Extension Cable (H) to the cable on the cube. Note the orientation of the cable. Screw the retaining ring into place. 11. Attach the cube’s control box to the cable. 12. Clamp the Hose Clamp (I) around the Chain (G) and cable. This serves as a backup suspension point in case of failure.

  • Page 8: Maintenance And Inspection

    Warning - Structural Integrity: Ensure the mounting surface and ● hardware can support the weight of the lighting equipment. Warning - Weight Limits: The HyperHanger is designed to only hold ● the HyperCube15. Do not hang any other objects from the HyperHanger.
