- Page 1 HyperCube User’s Manual Don’t Panic! This is your personal guide to your new hyper- dimensional portal device...
-
Page 2: Table Of Contents
What’s in the box?! ..........3 Powering up ............3 Hyper-Care ............4 Operation ..............4 The Button ............5 The Hyperspace App ..........6 Setup ..............6 Usage ..............11 Troubleshooting ............. 16 Warranty ..............18 Contact ..............18... -
Page 3: Getting Started
Getting Started What’s in the box?! ❖ HyperCube Control Box ❖ Power Supply ❖ Powering up Plug the power supply into an outlet (accepts outlet voltage from 100-240 V). Connect the HyperCube cable to the control box cable. Twist the screw-ring to secure... -
Page 4: Hyper-Care
Connect the power supply barrel jack to the front of the control box. The blue button on the control box will light up. Let there be light! Hyper-Care The HyperCube is an art piece; while it is sturdy, it is not meant to be handled excessively. -
Page 5: The Button
Meditative: calm, classy and slowed down patterns ❖ to help you relax (24 patterns) Sound Reactive: dance and entrance, with specially ❖ designed patterns that respond to the beat. A microphone is located inside the control box (31 patterns) Each mode is essentially a playlist of unique patterns. By default, a pattern plays for 60 seconds before switching. -
Page 6: The Hyperspace App
The Hyperspace App Hyperspace Lighting Download the “Hyperspace Lighting” app to fully control and customize your HyperCube! Setup The setup process will connect your HyperCube to your home WiFi network for convenient smartphone control. (NOTE: the HyperCube only connects to 2.4 GHz networks) 1. - Page 7 2. Press “Add New 3. Enter your home WiFi HyperCube” credentials and press “Connect!” Note: if the connection fails, press “Can’t Connect?” at the bottom of the screen and follow the instructions.
- Page 8 4. You’re done - press “My HyperCube” to pilot the controls! Trouble connecting? If the process finished but the cube isn’t showing on the device list, press “Discover Cube” in the “+” menu. Leave for 10-20s, then press the check mark If this does not work, reset the WiFi by holding the button on the control box for 10s (until the LEDs flash green)
- Page 9 HyperCube! All you need is an internet browser on your PC or phone. On your phone, connect to the “HyperCube” WiFi network. Password: hyperspace A new window will appear (or a prompt will appear asking you to log in. Press this). Enter your home WiFi network information.
- Page 10 Connecting via E1.31 The HyperCube also supports pixel mapping via sACN/E1.31 protocol. Various third-party software can be used to control the LEDs, such as xLights and MadMapper. This feature is experimental, not guaranteed to work smoothly, and is recommended only for users with pixel mapping experience. The setup process differs for all software.
-
Page 11: Usage
Usage Patterns Menu (default) Nightlight: dims Sync with Sync brightness to brightness over other cubes music (makes any 60 minutes pattern sound reactive) Toggle Settings power Pattern menu Mode selection Next & previous pattern Stay on current pattern in the mode playlist Choose individual pattern (from any... - Page 12 Colors Menu Choose pre-defined color palette Customize your own colors Adjust brightness of selected color Choose up to 3 unique colors...
- Page 13 More Controls Menu Adjust overall brightness Adjust pattern intensity (unique effects on each pattern) Symmetry menu Adjust pattern speed Pause or freeze animation Change the symmetry of motion each pattern displays...
- Page 14 Favorites Menu Save your favorite patterns for easy playback! All color, speed, intensity, and symmetry customizations are also saved. To save: To load: 1. Press “saving Press a mode” highlighted slot number with a 2. Press a slot previously saved number to save pattern to that slot...
- Page 15 Settings Menu Play time before Toggle advanced pattern transition settings within each mode Random color change time Patterns play in fixed or random order Startup settings Blend time between auto- transitions Blend time between button-press transitions...
-
Page 16: Troubleshooting
Troubleshooting Trouble connecting the app? Try the alternative connection process here. Scan the QR code below with your smartphone. A new window will open (or a prompt will appear asking you to log in. Press this). Enter your home WiFi information Open the app, press the “+”... - Page 17 Cube not found or lost in the app? If your HyperCube disappears from the main menu in the app, try the following steps: ❖ Re-discover device: press the “+” in the top right of the main menu, then “Discover Cube”. Return to the main menu with the check in the top right.
-
Page 18: Warranty
Warranty The Hyperspace Lighting Company, LLC offers a 1-year limited warranty on each HyperCube. We guarantee that each product purchased will arrive in working condition, without damage, and will be free from defects in electrical operation for a period of one (1) year from the date of delivery. -
Page 19: Tech Specs
Tech Specs HyperCube10 HyperCube15 Dimensions (per side) 10.04” (255 mm) 15.16” (385 mm) Total LEDs LEDs Per Edge Max Power Draw 11.25W (2.25A) 20W (4A) Avg Power Draw 6W (1.2A) 10W (2A) Weight 5.7 lb (2.6 kg) 12.3 lb (5.6 kg)
