- Page 1 PowerStand user’s Manual DOn’t Panic! This is your personal guide to your new hyper- dimensional portal device...
-
Page 2: Table Of Contents
Product Description ..............4 Setting Up .................. 5 Operation ..................7 Power Switch ................7 HyperCube Patterns and Modes ..........8 The Button ................. 8 Removing the cube from the PowerStand ....... 9 Connectivity .................11 Setup ..................11 Attachment ..................15 Troubleshooting................15 Warranty ..................16 Contact ..................16... -
Page 3: Safety And Care
Safety and Care WARNING – Fire Hazard Keep the PowerStand out of direct sunlight and extreme heat. In rare cases, the mirrors on the attached HyperCube can focus sunlight into a point that could cause burns or risk of fire. -
Page 4: Getting Started
The PowerStand is a battery-powered wireless stand for the HyperCube Nano. Your cube (sold separately) will plug and clip into the PowerStand, transforming it into a fully portable piece of immersive art. You will no longer need to use the Control Box originally supplied with your HyperCube Nano. -
Page 5: Setting Up
Or follow the instructions below. Push the connector from the HyperCube Nano through the hole in the PowerStand Top Half. Do not force it – rotate the plug until it easily fits through. Pull the cable all the way through. Rotate the PowerStand Top Half until the cable strain relief coming out of the cube easily fits through the hole in the PowerStand Top Half. - Page 6 Plug the HyperCube Nano connector into the socket in the PowerStand Bottom Half. Tuck the cable inside the PowerStand Bottom Half, beside the circuit board. Continue coiling up the wire inside the enclosure. Place the PowerStand Top Half (with HyperCube attached) on top of the Bottom Half a.
-
Page 7: Operation
Twist the PowerStand Top Half clockwise until it locks into place. The Top and Bottom Halves should be tightly connected, with no visible gap between either half on any side. Flip the power switch on [“–”] – let there be light! You may need to charge your PowerStand prior to first use. -
Page 8: Hypercube Patterns And Modes
HyperCube Patterns and Modes The PowerStand contains the same controller that your HyperCube Nano uses, thus it offers all the same patterns, modes, and features. The HyperCube Nano features 3 modes and 95 patterns: Kaleidoscopic: dynamic, fast, and colorful patterns. This is ... -
Page 9: Removing The Cube From The Powerstand
At the same time, pull the cube away from the stand with your other hand. The cube should pop out of the clips on that side. Repeat for another arm of the PowerStand, until the cube is fully disengaged. Pull the cube and cord away, twist the PowerStand Top Half... - Page 10 Simply unscrew the small screw holding the clip in place, then screw a new clip in. Be sure that is fully screwed down, and the surface of the clip is flush with the surface of the PowerStand arm.
-
Page 11: Connectivity
HyperCube! Setup The PowerStand is a new device and will need to be connected to your home network. If your HyperCube Nano was connected, it will now be listed as “offline” (as long as its controller is unplugged). - Page 12 Enter your home WiFi credentials press Press “Add New “Connect!”. All fields are Hyper-Device” case sensitive Your phone must be connected to this network. Note: if the connection fails, press “Can’t Connect?” at the bottom of the screen and follow the instructions.
- Page 13 Accept any permissions and allow your phone to connect to the HyperCube WiFi network channel Wait for the connection process to finish. This could take up to one minute You may go back at any time to re-enter your WiFi credentials or restart the process.
- Page 14 Trouble connecting? Refresh: If the connection process finished but the cube isn’t showing up, refresh the device list by swiping down anywhere on the screen If this does not work, power the cube off and on, then reset the cube’s WiFi by holding the button on the control box for 10s (until the LEDs in the cube flash red then green) Repeat steps 1-7.
-
Page 15: Attachment
This will leave you connected to the HyperCube WiFi channel. Attachment The PowerStand can be hung or secured by the M5 screw inset on the bottom of the stand. Use a screw no longer than 10 mm. Troubleshooting Trouble connecting to the app? Try the alternative connection process here. -
Page 16: Warranty
Want to connect an additional device to the PowerStand? You can control one PowerStand from multiple devices. If you have already gone through the initial setup process once, on your new device simply swipe down on the main device list page to refresh. You may need to refresh multiple times, and wait up 1-2 minutes. -
Page 17: Tech Specs
Tech Specs PowerStand Dimensions (no cube) 5.5x5x5” (140x128x125 mm) Max Power Draw 7.5 W (1.5 A) Avg Power Draw 2.5 W (0.5 A) Weight 0.9 lb (408 g) Frame Material Attachment Screw M5 Female Wifi Connectivity 2.4 GHz Input DC 5V, 2.1A Max...
