INSTALLATION
AND
OPERATING
INSTRUCTIONS
WARNING: If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury or loss of life.
- - Do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.
- - WHAT TO DO IF YOU SMELL GAS
-
Do not try to light any appliance.
-
Do not touch any electrical switch; do not use any phone in your building.
-
Immediately call your gas supplier from a neighbour's phone. Follow the gas
supplier's instructions.
-
If you cannot reach your gas supplier, call the fire department.
- - Installation and service must be performed by a qualified installer, service
agency or the gas supplier.
IMPORTANT: THESE INSTRUCTIONS ARE TO REMAIN WITH THE HOMEOWNER
060199-20
VENTED ROOM HEATER
FIREPLACE INSERT
MIR-INSG
SERIES G
5055.63
Advertisement
Table of Contents
Related Manuals for Warnock Hersey Pacific Energy Mirage G Series
Summary of Contents for Warnock Hersey Pacific Energy Mirage G Series
- Page 1 INSTALLATION OPERATING INSTRUCTIONS SERIES G VENTED ROOM HEATER FIREPLACE INSERT WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. - - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
-
Page 2: Table Of Contents
Caution ....................3 Safety ....................3 Maintenance ..................3 Installation ................... 4 Clearances ................... 5 Venting ....................6 Gas Supply ................... 6 Burner Installation ................7 Vent Safety Shutoff System ..............8 Draft Inspection ................... 8 Log Set ....................9 Glowing Embers ................. -
Page 3: Caution
Caution Maintenance FOR YOUR SAFETY - Do not install or operate your Pacific Caution: Turn off gas and electrical power supply and allow Energy Mirage Gas Insert without first reading and under- ample time for unit to cool before servicing appliance. It is standing this manual. -
Page 4: Installation
Installation Fig. # 3 Caution: A gas appliance must NOT be connected to a chimney flue servicing a separate solid fuel burning appliance. This appliance MUST be properly connected to a venting system. This heater is equipped with a vent safety shutoff system designed to protect against improper venting of com- bustion products. -
Page 5: Clearances
Clearances Fig. # 5 The Mirage Gas Insert is designed to be installed into a masonry or a factory built zero clearance fireplace, or built in with the optional Mirage Zero-Clearance Kit. The masonry fireplace must be built according to the requirements of the standards for chimneys, fireplaces, vents and solid fuel burning appliances, NFPA 211 (Latest Edition) or applicable National, Provincial, State or local codes. -
Page 6: Venting
Venting Fig. # 7 Caution: Use only a flue liner system approved by the local gas authority and install in accordance with the manufactur- ers instructions. Consult local and/or national building codes before altering fireplace. The chimney must be relined with a minimum 4" flue liner (Fig. -
Page 7: Burner Installation
1) Fold down the bottom louver, if installed, to access the over- center latches. Disengage the latches by pulling each lever Fig. # 8 down and forward. 2) Grasp the sides of the frame and swing the bottom out to clear. -
Page 8: Vent Safety Shutoff System
Vent Safety Shutoff System Draft Inspection Installation This appliance must be connected to a venting system with adequate draft to ensure safe and proper operation. This appliance is equipped with a vent safety shutoff system. The switch assembly is shipped with the burner. To inspect vent operation: A few minutes after the appliance is lit, insert a smoke stick 1) Unravel wire, feed through front grommeted hole located... -
Page 9: Log Set
Log Set Fig. # 14 Rear Log The ceramic logs are durable and long lasting when installed properly. However, they are delicate and may be damaged easily if not handled with care. Unpack and inspect log set. There should be a total of 4 logs as shown in Fig. # 14. All gas and venting connections should be made before installing log set. -
Page 10: Glowing Embers
Glowing Embers Fig. # 17 Glowing embers are supplied to enhance the front flame. The embers should be placed randomly in the tray immediately behind the front burner (Fig. # 17). Placing pieces directly into tray will produce the best results. Levelling Legs Levelling legs are provided with the appliance as a convenient means for levelling the appliance when... -
Page 11: Surround Assembly
Surround Assembly Fig. # 20 Fig. # 21 1) Lay Parts A, B, and C face down on a flat, non-marking surface (Fig. #19). Fasten together with spring clips or 1/4" x 1/2" bolts through holes at points "D" (Fig. #22). 2) Lift the surround assembly to the upright position and make sure the front face is even at the joint. - Page 12 FOR YOUR SAFETY READ BEFORE LIGHTING phone in your building. WARNING: If you do not follow these - Immediately call your gas supplier from a neigh- instructions exactly, a fire or explosion bour's phone. Follow the gas supplier's instruc- may result causing property damage, tions.
-
Page 13: First Fire
First Fire Primary Air Adjustment When lit for the first time, the appliance will emit a slight odor This appliance is provided with primary air adjustment, which for a couple of hours. This is due to the curing of paints, affects flame heights and flame quality of the front and back sealants and lubricants used in the manufacturing process. -
Page 14: Louver Installation
Louver Installation Fig. #28 Unpack and inspect all parts. A flathead or a #2 Robertson screwdriver is required to install the louvers. 1) Fasten top louver to the top casing with the screws provided (see Fig. #27). 2) Fasten bottom louver to the hinge brackets at the bottom of the appliance (see Fig. -
Page 15: Optional Blower
Optional Blower Fig. # 30 BLOWER SNAP DISC Electrical Supply: ROCKER SWITCH SWITCH Circulating air blower electrical rating: 115V, 60 Hz, 80 watts. For your protec- 115 VOLTS tion against shock hazard, use only a 60 Hz properly grounded outlet that will ac- 0.5 AMPERES cept a three-pronged plug. - Page 16 Fig. # 33 4) Run the power cord to the outside of the appliance through the 1-1/2" grommet lo- cated on the right side of the firebox support and casing side. 5) Fasten the thermo-switch through the two holes in the rear of the firebox with the two #8 - 1/2"...
-
Page 17: Replacement Parts
Replacement Parts Fig. # 36 (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. 1 ... MAIN BODY ........MINB.1900 17 ..LOUVER ASSEMBLY, TOP ..MIND.1883_ _ 2 ... BURNER ASSEMBLY .... MINB.NAT/PRO 18 .. - Page 19 LISTED VENTED ROOM HEATER / RADIATEUR VENTILE VENTED CIRCULATOR OPTIONAL FAN / CIRCULATEUR VENTILE VENTILATEUR OPTIONNELLES REPORT NO. 476-1004 CERTIFIED FOR CANADA AND U.S.A. / CERTIFI… POUR CANADA ET U.S.A. (APR. 94) ANS Z21.11.1-1991 Vented Heaters, CAN 1-2. 1 -M86 Gas-Fired Vented Room Heaters, CAN/CGA-2.17 -M91 Gas-Fired Appliances For Use At High Altitudes MIRAGE - INSERT...
- Page 20 Pacific Energy Fireplace Products Ltd. Box 1060, Duncan, BC V9L 3Y2 Phone: 250-748-1184 Web site: http://www.pacificenergy.bc.ca Printed in Canada...
