This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel.
It has been assumed that basic service procedures inherent to the industry, and more specifically YAMAHA Products, are already
known and understood by the users, and have therefore not been restated.
WARNING:
IMPORTANT:
The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research, engineering, and
service departments of YAMAHA are continually striving to improve YAMAHA products. Modifications are, therefore, inevitable
and specifications are subject to change without notice or obligation to retrofit. Should any discrepancy appear to exist, please
contact the distributor's Service Division.
WARNING:
IMPORTANT:
I CONTENTS
FRONT PANEL .............................................................. 3
REAR PANEL ................................................................ 3
SPECIFICATIONS .......................................................... 3
INTERNAL VIEW ........................................................... 4
DISASSEMBLY PROCEDURES /
1 0 0 8 7 7
PASSIVE CONTROLLER
IMPORTANT NOTICE
Failure to follow appropriate service and safety procedures when servicing this product may result in personal
injury, destruction of expensive components, and failure of the product to perform as specified. For these reasons,
we advise all YAMAHA product owners that any service required should be performed by an authorized
YAMAHA Retailer or the appointed service representative.
The presentation or sale of this manual to any individual or firm does not constitute authorization, certification or
recognition of any applicable technical capabilities, or establish a principle-agent relationship of any form.
Static discharges can destroy expensive components. Discharge any static electricity your body may have
accumulated by grounding yourself to the ground buss in the unit (heavy gauge black wires connect to this buss).
Turn the unit OFF during disassembly and part replacement. Recheck all work before you apply power to the unit.
............... 5~7
YPC-1
SERVICE MANUAL
BLOCK DIAGRAM ......................................................... 7
PRINTED CIRCUIT BOARD .......................................... 8
SCHEMATIC DIAGRAM ................................................ 9
EXPLODED VIEW ........................................................ 10
MECHANICAL PARTS ................................................ 11
P.O.Box 1, Hamamatsu, Japan

Advertisement

loading

Summary of Contents for Yamaha YPC-1

  • Page 1: Table Of Contents

    The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research, engineering, and service departments of YAMAHA are continually striving to improve YAMAHA products. Modifications are, therefore, inevitable and specifications are subject to change without notice or obligation to retrofit.
  • Page 2 無鉛ハンダについて The foil side of all P.C.B.s used for this product and the この製品に使用されている基板のハンダ付けおよびピンジャック wire on the positive (+) side of the pin jack (at 14 points) +側 (14箇所) の配線のハンダ付けには、Sn+Ag+Cu (錫+銀+銅) are soldered with lead-free soldering material which is an の合金である無鉛ハンダが使用されています。...
  • Page 3: Specifications

    ..........±1 dB (-100 dB to 0 dB) Dimensions / (W x H x D) 寸法 ..240 x 75 x 269 mm (9-7/16" x 2-15/16" x 10-9/16") Weight / 重量 ............3.4 kg (7 lbs. 8 oz.) * Specifications are subject to change without notice due to product improvements.
  • Page 4: 分解手順

    (Remove parts in the order as numbered.) 1. ボトムカバーの外し方 (Fig. 1) 1. Removal of Bottom Cover (Fig. 1) a. 軟らかい布を敷き、その上に本機を上下反転して置きます。 a. Spread a soft cloth and place the unit on it upside down. b. Remove 3 screws (1) and 5 screws (2). のネジ3本、 のネジ5本を外します。...
  • Page 5: Block Diagram

    フロントパネル ノブ/D31 Fig. 3 6. Removal of PIN JACK (Fig. 4) 6. ピンジャックの外し方 (Fig. 4) a. Remove the Tube fitted to the positive (+) terminal. a. + (プラス) 端子に付いているチューブを外します。 b. Remove the solder. b. ハンダを外します。 c. Remove the Nut. c. ナットを外します。...
  • Page 6: Printed Circuit Board

    YPC-1 I PRINTED CIRCUIT BOARD (Foil side) AUDIO OUTPUT MAIN (1) P. C. B. (Lead Type Device) AUDIO INPUT VOLUME MAIN (2) P. C. B. (Lead Type Device) INPUT...
  • Page 7: Schematic Diagram

    YPC-1 I SCHEMATIC DIAGRAM MAIN (2) MAIN (1)
  • Page 8: Exploded View

    Included in 12 . に含まれます。 Included in 11 . に含まれます。 The double-faced tape is attached. 両面接着テープ付きです。 Included in SW1 . SW1 に含まれます。 Included in VR1 . VR1 に含まれます。 Use a 1.5 mm hexagon wrench to loosen the screws securing these knobs. 六角レンチ(1.5mm)を使用してツマミ固定 ネジをゆるめます。...
  • Page 9: Mechanical Parts

    V6004800 EMBLEM エンブレム        WC187400 WASHER 3.9-9 ワッシャ 3.9−9   EP600190 BIND HEAD B-TIGHT SCREW 3x8 MFZN2BL バインドBタイトネジ VN413300 BIND HEAD BONDING B-T. SCREW 3x8 MFZN2BL ボンディングBタイトネジ 01 V6012200 FLAT FILLISTER HEAD SCREW 4x12-10 MFC2BL +平Sタイト       EG330360 BIND HEAD SCREW MFZN2BL バインド小ネジ      01 VZ537900 BIND HEAD BONDING B-T.
  • Page 10 YPC-1...
