Summary of Contents for Daymak Wild Goose

  • Page 1 Wild Goose User Manual User Manual...
  • Page 2: Table Of Contents

    Wild Goose Specification CONTENTS ABOUT THE USER MANUAL......................2 FUNCTION SUMMARY & BUTTON DEFINITION ..............3 ..........................3 UNCTION UMMARY ...........................4 IEWING ........................4 ORMAL IEWING BUTTON DEFINITION........................5 INSTALLATION INSTRUCTION .....................5 NORMAL OPERATION ........................6 ON/OFF..............................6 ...........................6 ISPLAY NTERFACE ........................7 RUISE ONTROL ........................7 URN ON...
  • Page 3: About The User Manual

    Outlook and Size Material and Color Wild Goose products are made of black PC material. Under the temperature of -20℃ to 60℃, the shell material can ensure normal usage and good mechanical performance of the products. Real product and dimension figure (unit: mm)
  • Page 4: Function Summary & Button Definition

    Function Summary & Button Definition Function Summary Wild goose provides a wide range of functions and indicators to fit the users’ needs. The indicated contents are as follow: ◆ ODO Display; ◆ Riding Distance Display; ◆ Riding Time Display; ◆ Max Speed Display;...
  • Page 5: Full Viewing Area

    Full Viewing Area Normal Viewing Area...
  • Page 6: Button Definition

    Button Definition Wild Goose has four buttons. They are ON/OFF , SET , UP and DOWN. Installation Instruction Fix display in the handlebar, adjust to the appropriate perspective; install the button in the easy manipulation of the position. With the e-bicycle power is off the corresponding connector of display plug in the controller connector.
  • Page 7: Normal Operation

    Normal Operation ON/OFF Press ON/OFF and start the display , The display will provide power supply for the controller. With display on, more than 3 seconds press ON/OFF to turn off power supply of the e-bicycle. With the display off,the display and controller no longer consume battery power.
  • Page 8: Push Cruise Control

    Push Cruise Control Hold UP for 2 seconds and enter into the mode of power assist walk. The e-bicycle will go on at a uniform speed of 6km/h. It shows“6KM”on the screen. Turn on/off Backlight With the display on, press ON/OFF and turn on the backlight.
  • Page 9: Battery Indicator

    Battery Indicator When the battery capacity is high, the six battery segments are all light. When the battery is in low voltage, the outside edge of the battery frame will flash at 1 Hz. It indicates that the battery is severely low in voltage condition and needs to be recharged immediately.
  • Page 10: User Setting

    User Setting Preparation before Starting Make sure the connector is linked properly to the motor controller on the bike and the power is on. General Setting 1、Distance and Riding Time Clearing ★ Hold UP and DOWN for 12 seconds to clear Total Distance、Riding Distance, Riding time and Max Speed.
  • Page 11: Speed-Limit Setting

    ※ Press UP or DOWN to choose the wheel diameter setting, press SET to exit the setting. 3. Speed-limit Setting Change Max Speed could set the limit riding speed. When speed over this value, controller will cut off the power which supply to motor, to protect the safety of rider.
  • Page 12: Faq

    ※ Press SET to exit the above setting interface. Q: Why the display is not able to start up? A: Checking the connector that between display and controller. Q:How to deal with the error code? A: Fix it to the maintenance place immediately Quality assurance and Warranty scope Warranty: 1、...
  • Page 13: Error Code Definition

    or damage. 6、 Beyond Warranty period. Error code definition Error code Definition Current Abnormality Throttle Abnormality Motor Abnormality Motor Hall Signal Abnormality Brake Abnormality a t l Controller Communication Abnormality Panel Communication Abnormality Table 1...
