tofino X
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tofino X and is the answer not in the manual?

Questions and answers

Related Manuals for Daymak Tofino X

Summary of Contents for Daymak Tofino X

  • Page 1 X User Manual...

  • Page 2: Safety

    Safety When operating the Tofino X 36V please make sure you adhere to the following: • Always wear a helmet when riding the Tofino X 36V. • Always check your mirrors and blind spots when operating the vehicle. • Turn on headlights when in need of additional visibility.

  • Page 3: About Daymak

    Daymak warranties, services, and stocks parts for everything it sells. We support our products. Please feel free to visit our website. You’ll find the latest in cool transportation...

  • Page 4: Introduction

    Liability Daymak does not assume any liability for damages, loss of profits, or claims from third parties due to improper use of this product. Daymak does not assume any liability for damages due to problems with the product resulting from service by a third party that is not certified by Daymak.

  • Page 5: Table Of Contents

    • INTRODUCTION • PART DIAGRAMS • RIDING INSTRUCTIONS • THE BATTERY • CHARGING YOUR E-BIKE • UNDERSTANDING YOUR VOLTAGE • CHARGING THE TOFINO X 36V • OPERATION • SEAT • TIRES • DISPLAY AND FUNCTIONS • DISPLAY • DISPLAY ADVANCED •...

  • Page 6: Part Diagrams

    Part Diagrams Diagram 1: Tofino X 36V This diagram illustrates the various parts of your bicycle. Please note that many of these parts are not user-serviceable and should be repaired only by trained professionals. This is especially true of the electrical systems and the mechanical components.

  • Page 7: Riding Instructions

    Riding Instructions This guide assumes that you already know how to ride a standard bicycle. Before you try to ride an electric bicycle, you should be very familiar with controlling and balancing a normal bicycle. Caution If you do not have cycling experience, an e-bike is too dangerous to ride. Do not begin learning to ride a bicycle using an e-bike.
  • Page 8 Items to Carry with the Electric Bike It is a good idea to carry the following items with you at all times when you ride your e-bike. • The charger, to charge the bike in case the battery power runs out. •...
  • Page 9 Warning When you activate the e-bike, the electrical system becomes live. Do not try to affect changes to the E-Bike (such as removing the battery or repairing electrical components) while the E-Bike is activated. Turn the E-Bike off and remove the key before you attempt to access any of the electrical components.
  • Page 10 Lights The headlight and tail light are useful features when you are riding at night or in dark areas. They radically improve your safety in mixed traffic. The lights on your e-bike consume some electricity. Keeping them on may reduce the maximum distance you can travel on one charge by about 5 %.
  • Page 11 Riding in Cold Weather Your e-bike is designed to operate year-round. However, in very cold conditions or when there is a lot of snow or slush on the ground, it is possible for the motor in the e-bike to get wet or for the brakes to function less effectively, just as it can happen in wet weather.

  • Page 12: The Battery

    The Battery This section details what you need to know about the battery that powers your e-bike. Always remember to treat your e-bike’s electrical systems with respect. Battery Power The dashboard has a battery charge indicator. When the e-bike is activated, the guage will jump and indicate the currently available battery power.

  • Page 13: Charging Your E-Bike

    If your charger’s LED status light does not change from red to green over an extended period of time, for perhaps more than 6 hours, and the battery is very hot, the battery or charger may need replacing. Stop charging and bring both to your Daymak dealer immediately. Do not charge the battery.

  • Page 14: Understanding Your Voltage

    Underneath each reading on the above chart shows a number and an “S” this represents how many series are in your battery pack. To know the exact series of your battery contact your local Daymak dealer.

  • Page 15: Charging The Tofino X 36V

    Charging the Tofino X 36V First take the charger that came with your Tofino X 36V and plug it into the the wall. Once you have done that locate the charging port of the Tofino X 36V located on the right side of the frame.
  • Page 16 Contact your local Daymak dealer to purchase a new battery. When replacing your battery, dispose of it at a proper municipal battery recycling facility.

  • Page 17: Operation

    The key can be turned on and off. Mirror The Tofino X comes with a mirror to provide you extra visibility for anyone travelling behind you. Once on the handlebar bend the mirror to the position that provides the most...

  • Page 18: Seat

    Seat The Tofino X 36V comes with a quick release latch that allows you to easily adjust the height of the seat. It also comes with an optional back rest for additional support To adjust the seat height take the lever see below)at pry it away from the seat post.

  • Page 19: Display And Functions

    Display and functions The Tofino X 36V has a bunch of functions on both handlebars. Below you will find what each one does! On the Right Handlebar 1) Shift Down - Press this lever up to change your manual gears to shift down.

  • Page 20: Display

    Display Below you will find the display of the Tofino X. These are what each function does or displays. 1) Power button - Press and hold this button to turn on and off the unit. Press it quickly to switch the display from Odometer / Trip Meter / Voltage...

  • Page 21: Display Advanced

    Display advanced To access the advanced settings of your display press and hold the S+ and S- buttons. To exit this menu press and hold S+ and S- buttons again. To switch between menus quick press the power button. To change the setting on any P Menu press S+ or S- to go up or down respectively.
  • Page 22 P10: Power Modes: This determines if the Throttle works, Pedal Assist Works, or Both. 0 = Pedal Assist only Works / 1 = Throttle Only works / 2 = Pedal Assist and Throttle Works P11: Pedal Assist Sensitivity: Determines how much pedaling has to be done before the PAS kicks in.

  • Page 23: Technical Data

    This section provides you with the technical specifications for your e-bike. The Motor and Wheel Assembly The Tofino X 36V has a 350 Watt magnetic DC brushless motor on the rear wheel hub. This type of motor has excellent low-end torque and high efficiency when working within its range.

  • Page 24: Vehicle Identification Number (Vin)

    This is also required for registering your warranty on the warranty section of Daymak.com. To find the VIN on your Tofino X 36V look on neck of the bike just above where the forks are and below the Daymak...

  • Page 25: Maintenance And Troubleshooting

    Maintenance and Troubleshooting This section outlines problems you may have and solutions you may be able to use. Many of the parts in this product are not user-serviceable and should be repaired by trained professionals. This is especially true of the electrical systems and the mechanical components.
  • Page 26 Daymak dealer. The Motor Do not service the motor yourself. Bring the e-bike to your Daymak dealer for service. The motor in your e-bike is a highly complex and fine-tuned mechanism. Repairing it requires significant expertise. We suggest maintenance every 100 running hours or so.

  • Page 27: Ebike Maintenance

    Ebike Maintenance Cleaning Cleaning is extremely important. This will ensure your e-bike will serve you for a long time. In the long run, it will save you money and a lot of time waiting for the bike to be repaired. You should clean your ebike weekly.
  • Page 28 Schedule The frequency of maintenance depends on how much you ride and under which conditions. Recreational riders needs far less maintenance then off-road riders. The harder you ride, the more you have to take care of your bike if you want it to last. There are various time intervals for proper maintenance.

  • Page 29: Specifications

    Specifications Name Tofino X Motor 350W Voltage Amp Hour 7.8AH Watt Hours 281WH Battery Life 1000 cycles Battery Lithium Ion Removable Battery Charger 42V 2.0A Charge Time 2 - 4 Hours Lights Max Load 275 lbs. Assembled Weight 43 lbs.
  • Page 30 Name Tofino X Rear Brakes Disc Brakes Front Brakes Disc Brakes Ignition Key Ignition Front Shocks Rear Shocks Controller Standard Pedal Assist 5 Levels Speed Levels 6 Speed Shimano Throttle Push Throttle Cruise Control Display Back Lit LED Frame Size 21"...
  • Page 32 Thank you for choosing Daymak...
