INSTRUCTION MANUAL
Oil Free Compressor and Air Supply System
Model No.
Tech support
Rocker 320 / 420
Rocker 440

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 320 and is the answer not in the manual?

Questions and answers

Related Manuals for Rocker 320

Summary of Contents for Rocker 320

  • Page 1 INSTRUCTION MANUAL Oil Free Compressor and Air Supply System Model No. Tech support Rocker 320 / 420 Rocker 440...

  • Page 2: Table Of Contents

    Table Of Contents Important Notice Unpacking Main Part Diagram (1) Compressor (2) Air Supply System Operation (1) Oil Free Compressor - Rocker 320 / 420 (2) Air Supply System - Rocker 440 Maintenance...

  • Page 3: Important Notice

    1. Important Notice This instrument is designed for laboratory usage only. Please read this manual carefully before installing and operating. The instrument shall not be modi ed in any way. Any modi cation will void the warranty and may result in potential hazard. We are not responsible for any injury or damage caused by any non-intended purposes and modifying the instrument without authorization.

  • Page 4: Unpacking

    If there is any problem, please keep the serial number along with packing case and contact your local distributor immediately for assistance. 3. Main Part Diagram (1). Compressor Rocker 320 Rocker 420 Position Designation Position...

  • Page 5: Air Supply System

    (2). Air Supply System Rocker 440 The Rocker 440 system consists of a compressor Rocker 420, air tank (7), pressure regulator (2) and moisture trap (4). Air is pumped into air tank by Rocker 420, then goes through pressure regulator / moisture trap.

  • Page 6: Operation

    4. Operation Operation (1). Oil Free Compressor - Rocker 320 / 420 A. Press power switch (1) to activate the compressor after making sure all tubing are well connected. B. To setup pressure by adjusting the pressure regulator (6). C. Check liquid level of moisture trap (5) daily and drain the liquid by drain valve (6).
  • Page 7 Moisture trap/ Pressure regulator for Rocker 440 167300-07 Filter cartridge for Rocker 320 / 420 167440-07 Filter cartridge for Rocker 440 167300-42 Mu er (air inlet) for Rocker 320 / 420 / 440 167320-62-2 Rocker 320 repair kit 167420-62-2 Rocker 420 repair kit 167440-62-2...
  • Page 8 Rocker Scienti c Co., Ltd. Tel: +886-2-26033311 Fax: +886-2-26036622 E-mail:export@rocker.com.tw https://www.rocker.com.tw...
