- Page 1 4 Wires Residential Audio AUDIO & VIDEO TERMINALS for TL door phone systems- 4 WIRES-RESIDENTIAL User manual 3.5" Video 7" Video extra 7" Video...
-
Page 2: Table Of Contents
Contents Safety instructions Settings of the audio-video terminals Description of the audio-video terminals Programming the audio-video terminals Functions of the audio-video terminals Use of the outdoor panels Recommended cables. Installation. Maintenance of the door phone components Use of the audio-video terminals Warranty Safety instructions Any intervention on the installation must be performed by AUTHORIZED PERSONNEL! - Page 3 Functions of the 4 WIRES / RESIDENTIAL terminals Main functions Call, answer and hands-free talk (full-duplex talk). Audio-video monitoring. Video image display during the call, talk, monitoring and access Access command during call, talk and monitoring Additional command – AUX key for an auxiliary automation Additionally, only for the extra video terminals Picture taking during call, talk and monitoring Picture memory of up to 100 images.
- Page 4 Installation of the smart+ Audio / 3.5" Video Terminal - 4 WIRES Fasten the back case on the wall H=135cm Fasten the connectors on the back case Line IN Line OUT Main Additional terminal terminal Line IN Line OUT Make the connections in the connector fastened on the back case.
- Page 5 Installation of the smart+/ extra 7" Video Terminal - 4 WIRES Fasten the back case on the wall H=135cm Make the connections in the connector Fasten the connectors on the back case fastened on the back case. Line IN Line OUT Line IN Line OUT Main...
- Page 6 Installation of the audio-video terminals - RESIDENTIAL For distances between 150 lm and 1000 lm it is mandatory to use the twisted pair cable type: UTP cat5e (AWG24) / FTP cat5e (AWG24) or: UTP cat6 (AWG23) / FTP cat6a (AWG23). The TL smart+ or extra AUDIO-VIDEO TERMINAL can be connected to the RESIDENTIAL installation in one of the following ways: a.
-
Page 7: Use Of The Audio-Video Terminals
Use of the audio-video terminals smart+ Use of the terminals smart+ 3.5” video Call answer, audio-video monitoring (setting mode: ringtone selection) smart+ audio Access command (setting mode: call duration) Volume adjustment during talk, Mute (setting mode: call sound volume) Auxiliary command (auto gate, garage door, outdoor lighting etc.) smart+ 7”... - Page 8 The image closes and the keys remain backlighted for 10 more sec. Volume adjustment during TALK: Successively press the speaker key - . The maximum level (7) is signaled with two beeps (2 x [ ]). After the maximum level is reached, the adjustment recommences at level 1. BEEP 5.
- Page 9 extra Use of the terminal video extra 7” Picture taking Scroll up 100 stored pictures Menu / ok Scroll down Intercommunication Call answer, Access command Volume adjustment Auxiliary command audio-video monitoring during talk, Mute (auto gate, garage door, (setting mode: (setting mode: (setting mode: outdoor lighting etc.)
-
Page 10: Settings Of The Audio-Video Terminals
Settings of the audio-video terminals 1. CALL RINGTONE 2. CALL DURATION 3. CALL RINGTONE VOLUME Long touch keys simultaneously. The terminal enters settings mode and issues a long warning beep. You have 2 min. available for settings 1, 2 and 3. CALL RINGTONE The first ringtone. -
Page 11: Use Of The Outdoor Panels
Use of the outdoor panels IR LED (night lighting) Orientable video camera Name 5 Electronic display Name 4 Name 4 Name 3 Touch key Name 4 Touch keyboard with the name Name 1 Name 3 of the family Name 2 Name 1 RFID reader 1 Fam. -
Page 12: Maintenance Of The Door Phone Components
Maintenance of the door phone components The Touch Line audio-video terminals must be kept away from water, lime or any liquid substances, blows, fumes, powders, dust etc. In case of renovation activities, the entire surface of the terminals will be protected with plastic foil. The Touch Line outdoor panels must be kept away from corrosive substances, lime and blows. - Page 14 ELECTRA is a trademark of ELECTRA Group - No. 008958332 EUIPO - Alicante, Spain ELECTRA products are registered as Industrial Models at EUIPO - Alicante, Spain The products are The products contain UL-compliant The products are manufactured under CE certified.
