- Page 1 wires Residential AUDIO TERMINALS for TL door phone systems- 4 WIRES-RESIDENTIAL User manual mini Audio...
- Page 2 Contents Settings of the mini terminal Safety instructions Description of the Programming the terminals mini terminal Functions of the Use of the outdoor panels mini terminal Maintenance of the door Recommended cables. phone components Installation Use of the Warranty mini terminal Safety instructions Any intervention on the installation must be performed by AUTHORIZED PERSONNEL!
- Page 3 Recommended cables. Installation. 4 Wires 4 wires x 0.5 mm (type H03VV-F4G 0.5) for maximum 75 lm 25-30mm 25-30mm Residential UTP cat5e (AWG24) / FTP cat5e (AWG24) UTP cat6 (AWG23) / FTP cat6a (AWG23). 25-30mm Installation of the mini Terminal Fasten the back case on the wall H=135cm 4 Wire-Installation Make the connections in the connector fastened on the...
- Page 4 Residential-Installation Make the connections in the connector fastened on the back of the front case. Connection diagram for the mini terminal AUDIO TERMINAL Additional ATm.0S302 terminal SCU/VCB 1. Place the front case with the fastened connectors over the back case. 2.
- Page 5 1. CALL: When called from the outdoor panel, the terminal rings – 3 x Ding-dong. The LED is blinking red. 2. RINGING VOLUME ADJUSTMENT: The terminal has 2 volume levels and they can be adjusted by short successive touches of the key.
- Page 6 Repeat the procedure for the next addresses, until 20. NOTE: After pressing the key n times, wait a few seconds for the acoustic confirmation of the terminal for address n. The terminal will issue n beeps for address n programmed in the terminal. 3.
- Page 7 Successively touch the key until the name of the family and the apartment numbers show up on 1 : N a m e 1 the display: N a m e 2 N a m e 3 p a g e N e x t If the resident answers, talk mode is initiated.
- Page 8 ELECTRA is a trademark of ELECTRA Group - No. 008958332 EUIPO - Alicante, Spain ELECTRA products are registered as Industrial Models at EUIPO - Alicante, Spain The products are The products contain UL-compliant The products are manufactured under CE certified.
