Fosworks OMNI Tx-4.3DCC Manual

OMNI Tx-4.3
You no longer need that big transmitter anymore! The programmable OMNI Tx-4.3
handheld transmitter will control your garden railway electric locomotives perfectly
from the palm of your hand. An Omni Rx-24 receiver with be needed to work with
the OMNI Tx-4.3 transmitter in DCC mode, but the Tx4.3 will also operate our stand-
ard r/c Rx22 receivers installed in analogue DC models.
2.4GHz gives perfect glitch free control for up to 800 metres range with no
obstructions.
The Regulator Knob controls speed and direction. Forwards to the right, reverse to
the left. Cruise control is possible by turning off the transmitter while the train is run-
ning. Turn back on to instantly regain control.
FUNCTION Buttons 1.2.3 /
Buttons 1.2.and 3. Operate DCC command functions
On a OMNI Rx4 receiver. These buttons are also used to re-program a receiver.
Functions 4,5,and 6 are operated by holding the
and 9 by holding the red shift button first and functions
down both shift buttons whilst pressing the function button required.
Selector
Switch to change be-
tween THREE differ-
ent receivers
LED's 1 & 2
Indication of battery
and radio status plus
indications during bind
and calibration.
ON/OFF
Slide Switch
Slide down for ON
Inertia
Knob
Use it for super
smooth acceleration
and deceleration.
Minimum 1 second.
2 x AAA Battery box
If Alkaline batteries are used up to 100 hours of continuous
use is possible
DCC
2.4GHz Handheld Transmitter
4.5.6 / 7.8.9 / 10.11.12
green shift button first, buttons
10,11 and 12 by holding
Shift Buttons
Green
Enable F4 to F12 in com-
bination with black but-
tons. E.g. F7
by pressing and holding
the RED
pressing BLACK button
F1. Hold both down to
obtain F10, F11 and F12.
Regulator Knob
Turn right for forwards
and left for reverse. The
further you turn, the fast-
er the loco goes.
Centre Stop.
Whilst moving, if a quick
stop is needed, move the
knob fully to the opposite
direction for a controlled
E-stop (Max 2 secs from
full speed)
This knob is also used
when reprogramming the
top buttons.
OMNI
Programmable 2.4GHz Transmitter
For simultaneous control of up to 3
models and 12 functions on each
WWW.FOSWORKS.CO.UK
Tel 01254 814675
7,8
Regulator Knob Forwards and backwards with centre stop
Inertia control for super smooth acceleration and braking
Selector switch allows
Plus
and Red
2.4GHz Technology by Timpdon Electronics
is obtained
Requires an OMNI Rx24 or Rx4 receiver with DCC interface module or
button then
OMNI Rx22 or Rx2 with optional MCS switchers
Rx-24 receiver circuit diagram showing optional use of ESC. Note that stand-
ard Rx24 do not have the ESC connection, Rx24-ESC must be ordered spe-
cially. There are several versions including Drivelock on F8.
Tx-4.3DCC
model.
P.O.Box 675,
Blackburn, Lancs.
BB2 9QJ
UK
three models to be run simultaneously
12 functions for DCC or DC operation
With Emergency stop function
