Fosworks OMNI Tx-4.1 DCC Quick Start Manual

OMNI Tx-4.1
You no longer need that big transmitter anymore! The programmable OMNI Tx-4.1
handheld transmitter will control your garden railway electric locomotives perfectly
from the palm of your hand. An Omni Rx-4 receiver with be needed to work with the
OMNI Tx-4.1 transmitter in DCC mode, but the Tx4.1 will also operate our standard
r/c Rx2 receivers installed in analogue DC models.
2.4GHz gives perfect glitch free control for up to 800 metres range with no
obstructions.
The Regulator Knob controls speed and direction. Forwards to the right, reverse to
the left. Cruise control is possible by turning off the transmitter while the train is run-
ning. Turn back on to instantly regain control.
FUNCTION Buttons 1.2.3 /
Buttons 1.2.and 3. Operate DCC command functions
On a OMNI Rx4 receiver. These buttons are also used to re-program a receiver.
Functions 4,5,and 6 are operated by holding the
and 9 by holding the red shift button first and functions
down both shift buttons whilst pressing the function button required.
LED's 1 & 2
Indication of battery
and radio status plus
indications during
bind and calibration.
ON/OFF
Slide Switch
Slide down for ON
Inertia
Knob
Use it to match the
DCC sounds for su-
per smooth accelera-
tion and decelera-
tion. Turn to Zero to
switch off as shown
2 x AAA
Battery box lid
If Alkaline batteries are used up to 100 hours of continuous
use is possible
DCC
2.4GHz Handheld Transmitter
4.5.6 / 7.8.9 / 10.11.12
green shift button first, buttons
10,11 and 12
Shift Buttons
Green
Enables F4 to F12 in
combination with green
and red shift buttons.
Regulator
Knob
Turn right for forwards
and left for reverse. The
further you turn, the
faster the loco goes.
Centre Stop.
Whilst moving, if a quick
stop is needed, move
the knob fully to the op-
posite direction for a
controlled E-stop (Max
2 secs from full speed)
Perfect smooth control
to the exact position
shown on the regulator
dial. This knob is also
used when reprogram-
ming the top buttons.
OMNI Tx-4.1
Programmable 2.4GHz Transmitter
For electric models with DCC
decoders and ESC, with Inertia
Or analogue DC models with up to 12 functions
WWW.FOSWORKS.CO.UK
Tel 01254 814675
7,8
Regulator Knob Forwards and backwards with centre stop
by holding
Inertia control for super smooth acceleration and braking
Plus
and Red 2.4GHz Technology by Timpdon Electronics
Requires an OMNI Rx24 or Rx4 receiver with DCC interface module or
Rx-24 receiver circuit diagram for use with a DCC Interface module.
DCC
PO.Box 675,
Blackburn, Lancs.
BB1 9DL
UK
12 function buttons for DCC
With Emergency stop function
OMNI Rx22 or Rx2 with optional MCS switchers
or DC operation
