Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read
the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment.
MANUAL 10076R5
INSTALLATION & OPERATION
MANUAL
Direct Steam Counter Tilting Kettles
DC-6 DC-10 DC-12 DC-20
CROWN FOOD SERVICE EQUIPMENT
A Middleby Compan
70 Oakdale Road, Downsview (Toronto) Ontario, Canada, M3N 1V9
Telephone: 919-762-1000
WARNING
y
www.crownsteamgroup.com
Printed in Canada
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this
manual for the life of the equipment:
Model #: ___________________________
Serial #: ___________________________
Date Purchased: ____________________
Advertisement
Table of Contents
Related Manuals for Middleby Crown DC-6
Summary of Contents for Middleby Crown DC-6
- Page 1 Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment. CROWN FOOD SERVICE EQUIPMENT A Middleby Compan 70 Oakdale Road, Downsview (Toronto) Ontario, Canada, M3N 1V9 Telephone: 919-762-1000 www.crownsteamgroup.com...
- Page 2 INSTALLATION AND OPERATION MANUAL, DIRECT STEAM COUNTER TILTING KETTLES, MODELS: DC-6, DC-10, DC-12, DC-20 IMPORTANT NOTES FOR INSTALLATION AND OPERATION It is recommended that this manual be read thoroughly and that all instructions be followed carefully. This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
-
Page 3: Table Of Contents
INSTALLATION AND OPERATION MANUAL, DIRECT STEAM COUNTER TILTING KETTLES, MODELS: DC-6, DC-10, DC-12, DC-20 TABLE OF CONTENTS DESCRIPTION PAGE 1.0 Service Connections ........... . . 4 2.0 Introduction . -
Page 4: Service Connections
INSTALLATION AND OPERATION MANUAL, DIRECT STEAM COUNTER TILTING KETTLES, MODELS: DC-6, DC-10, DC-12, DC-20 1.0 SERVICE CONNECTIONS Part No. 10076R5 2018-10-30... -
Page 5: Introduction
INSTALLATION AND OPERATION MANUAL, DIRECT STEAM COUNTER TILTING KETTLES, MODELS: DC-6, DC-10, DC-12, DC-20 2.0 INTRODUCTION DESCRIPTION All direct connected steam jacketed kettles pertaining to this manual are direct steam operated pressure vessels of a double-wall stainless steel construction forming a steam chamber (jacket) enveloping the lower two thirds of the kettle bowl surface. -
Page 6: Installation Instructions
INSTALLATION AND OPERATION MANUAL, DIRECT STEAM COUNTER TILTING KETTLES, MODELS: DC-6, DC-10, DC-12, DC-20 3.0 INSTALLATION INSTRUCTIONS These kettles must be installed on a suitable table or counter top. On counter top make 7/8" holes at 13 - 3/4" centres for kettle legs on models DC-6, DC-10, and DC-12, 23-1/2"... -
Page 7: Operating Procedures
INSTALLATION AND OPERATION MANUAL, DIRECT STEAM COUNTER TILTING KETTLES, MODELS: DC-6, DC-10, DC-12, DC-20 4.0 OPERATING PROCEDURES WARNING: The kettle and its parts are hot. Use care when operating, cleaning and servicing the appliance. 1. Fill kettle with product to desired level. 2. -
Page 8: Cleaning Procedures
INSTALLATION AND OPERATION MANUAL, DIRECT STEAM COUNTER TILTING KETTLES, MODELS: DC-6, DC-10, DC-12, DC-20 5.0 CLEANING PROCEDURES Your kettle should be cleaned immediately after each use. a) Ensure that steam supply is OFF. b) Pre-rinse inside of kettle thoroughly and tilt to remove any food particles. c) Using a nylon brush, clean kettle with a mild detergent and warm water rinse. -
Page 9: Preventive Maintenance
INSTALLATION AND OPERATION MANUAL, DIRECT STEAM COUNTER TILTING KETTLES, MODELS: DC-6, DC-10, DC-12, DC-20 6.0 PREVENTIVE MAINTENANCE No preventive maintenance is required other than adhering to the Cleaning Procedure instructions. SAFETY VALVE MAINTENANCE AND TESTING CAUTION! Under normal operating conditions a “try lever test” should be performed every two months.
