Installation & Operation Manual

Self-Generating Steam Jacketed

EC-6TW-L, EC-10TW-L and EC-12TW-L

Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury

or death. Read the installation, operating and maintenance instructions thoroughly before installing or

Manual 10305 Rev 1 (08/22)

$21.00

Counter Tilting Kettle

Model EC-6TW-L

servicing this equipment.

CROWN FOOD SERVICE EQUIPMENT

70 Oakdale Road, Downsview (Toronto) Ontario, Canada, M3N 1V9

Telephone: 919-762-1000

WARNING

A Middleby Company

www.crownsteamgroup.com

IMPORTANT FOR FUTURE REFERENCE

Please complete this information and retain this

manual for the life of the equipment:

Model #: ___________________________

Serial #: ___________________________

Date Purchased: _____________________

Self-Generating Steam Jacketed

Counter Tilting Kettle

ANUAL

ECTION

Table of Contents

Need help?

Do you have a question about the CROWN EC-6TW-L and is the answer not in the manual?

Questions and answers

Summary of Contents for Middleby CROWN EC-6TW-L

Page 1 Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment. CROWN FOOD SERVICE EQUIPMENT A Middleby Company 70 Oakdale Road, Downsview (Toronto) Ontario, Canada, M3N 1V9 Telephone: 919-762-1000 www.crownsteamgroup.com...
Page 2: Safety
Specifications Self-Generating Steam Jacketed Counter Tilting Kettle SAFETY PRECAUTIONS Before installing and operating this equipment, be sure everyone involved in its operation is fully trained and aware of precautions. Accidents and problems can be caused by failure to follow fundamental rules and precautions. The following symbols, found throughout this manual, alert you to potentially dangerous conditions to the operator, service personnel, or to the equipment.
Page 3: Table Of Contents
Self-Generating Steam Jacketed Counter Tilting Kettle Table of Contents RETAIN THIS MANUAL FOR FUTURE REFERENCE. Table of Contents Safety ............................ 2 Service Connections ......................4 Introduction ........................... 5 Installation ..........................6 Operation ..........................7 Cleaning ..........................8 Troubleshooting ........................9 Appendix A, Material Safety Data Sheet ................
Page 4: Service Connections
Service C Self-Generating Steam Jacketed Counter Tilting Kettle onnections Service Connections SERVICE CONNECTIONS - ELECTRICAL CONNECTIONS: to be specified on data plate - COLD WATER: 3/8” O.D. tubing to faucet (OPTIONAL) - HOT WATER: 3/8” O.D. tubing to faucet (OPTIONAL) DIMENSIONS Model Capacity...
Page 5: Introduction
Self-Generating Steam Jacketed Counter Tilting Kettle Introduction Introduction Description Models EC-6TW-L (6 gallon capacity) and EC-10TW-L (10 gallon capacity) and EC-12TW-L (12 gallon capacity) electrically powered, self-contained, countertop, tilting kettles. Each model has a jacket of double-wall construction forming a sealed reservoir around the lower two-thirds of the kettle. The reservoir is charged with distilled water.
Page 6: Installation
Self-Generating Steam Jacketed Counter Tilting Kettle NSTALLATION Installation NPACKING IMMEDIATELY INSPECT FOR SHIPPING DAMAGE Immediately after unpacking the steamer, check for possible shipping damage. If the steamer is found to be damaged, save the packaging material and contact the carrier within 15 days of delivery. Installation Instructions 1.
Page 7: Operation
Self-Generating Steam Jacketed Counter Tilting Kettle PERATION Operation Operating Instructions 1. Ensure that the external electrical shut-off to the kettle is on. 2. Check pressure gauge for correct cold kettle reading. Reading should be in the green vacuum zone. If reading is not in the vacuum zone, follow VENTING INSTRUCTION prior to using the kettle.
Page 8: Cleaning
Cleaning Self-Generating Steam Jacketed Counter Tilting Kettle Cleaning WARNING Disconnect the power supply to the appliance before cleaning or servicing. WARNING Never spray water into electric controls or components! CAUTION The equipment and its parts are hot. Use care when operating, cleaning and servicing. CAUTION Do not use cleaning agents that are corrosive.
Page 9: Troubleshooting
Self-Generating Steam Jacketed Counter Tilting Kettle Troubleshooting Troubleshooting General Maintenance No general maintenance is required other than adhering to the Cleaning Procedure Instructions. Low Water Level Proper water level must be maintained within the jacket for the kettle to operate. Depletion of water may occur from excessive opening of, or leakage through the safety relief valve.
Page 10: Appendix A, Material Safety Data Sheet
Material Safety Data Sheets Self-Generating Steam Jacketed Counter Tilting Kettle Appendix ‘A’ PAGE OF 20 INSTALLATION & OPERATION MANUAL 10305 REV 1 (08/22)
Page 11 Self-Generating Steam Jacketed Counter Tilting Kettle Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10305 REV 1 (08/22) PAGE OF20...
Page 12 Material Safety Data Sheets Self-Generating Steam Jacketed Counter Tilting Kettle PAGE OF 20 INSTALLATION & OPERATION MANUAL 10305 REV 1 (08/22)
Page 13 Self-Generating Steam Jacketed Counter Tilting Kettle Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10305 REV 1 (08/22) PAGE OF20...
Page 14 Material Safety Data Sheets Self-Generating Steam Jacketed Counter Tilting Kettle PAGE OF 20 INSTALLATION & OPERATION MANUAL 10305 REV 1 (08/22)
Page 15 Self-Generating Steam Jacketed Counter Tilting Kettle Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10305 REV 1 (08/22) PAGE OF20...
Page 16 Material Safety Data Sheets Self-Generating Steam Jacketed Counter Tilting Kettle PAGE OF 20 INSTALLATION & OPERATION MANUAL 10305 REV 1 (08/22)
Page 17 Self-Generating Steam Jacketed Counter Tilting Kettle Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10305 REV 1 (08/22) PAGE OF20...
Page 18 Material Safety Data Sheets Self-Generating Steam Jacketed Counter Tilting Kettle PAGE OF 20 INSTALLATION & OPERATION MANUAL 10305 REV 1 (08/22)
Page 19 Self-Generating Steam Jacketed Counter Tilting Kettle Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10305 REV 1 (08/22) PAGE OF20...
Page 20 When service is needed, contact a Crown Authorized Service Agency, or your dealer. To avoid confusion, always refer to the model number, serial number, and type of your appliance. CROWN FOOD SERVICE EQUIPMENT A Middleby Company 70 Oakdale Road, Downsview (Toronto) Ontario, Canada, M3N 1V9 Telephone: 919-762-1000 www.crownsteamgroup.com...
