Electrically adjustable desk for the living area

Advertisement

Quick Links

T8 M / T8 L
Electrically adjustable desk
for the living area
Operating Manual
with Safety Instructions
and EC Declaration of Conformity
T8 M
T8 L
02.2023
GB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T8 M and is the answer not in the manual?

Questions and answers

Summary of Contents for moll T8 M

  • Page 1 T8 M / T8 L Electrically adjustable desk for the living area Operating Manual with Safety Instructions and EC Declaration of Conformity 02.2023 T8 M T8 L...
  • Page 2: Table Of Contents

    Contents General information Safety instructions Scope of delivery Placing the desk Levelling the desk Moving the desk Performing a reset Routing cable in the cable duct 14-15 Locking height adjustment 16-17 Raising the desk top Lowering the desk top Enabling single-hand operation Container-stop / Shelf-stop positions Recommendations on ergonomic adjustment Opening / Closing the drawer...
  • Page 3: General Information

    General information This desk is intended for use in private living areas as writing and working table. The height adjustment enables working both sitting and standing. Recommendations on ergonomic adjustments can be found on page 22. Please keep these operating instructions in a safe place for future reference! It is part of the product and must be handed over when the desk is passed on (important safety instructions).
  • Page 4: Safety Instructions

    Safety instructions Please read the operating instructions thoroughly before commissioning the desk! Caution: The sit-stand desk may be used only for its intended use as a writing and working table for the living area. Danger: Beware of moving parts! There is a risk of crushing when changing the table height! Make sure that there are no people, pets or objects in the danger area and that no one reaches into the hazardous area.
  • Page 5 Safety instructions Caution: This sit-stand desk is not designed for continuous operation. The desk top height can be adjusted without interruption for no longer than the operating time indicated in this manual (1 min on / 9 min off). Caution: This unit may only be operated with a mains voltage of 220-230 V / 50-60 Hz.
  • Page 6 Safety instructions Danger: Using this table is only permitted in dry rooms. Protect the desk frame and in particular all electrical components of the desk from moisture, dripping or splashing water! Danger: Do not open the motor control unit under any circumstances. There is a danger of electric shock.
  • Page 8: Scope Of Delivery

    Cope of delivery T8 M Please check for completeness rear side with power management...
  • Page 9 T8 L Please check for completeness rear side with power management...
  • Page 10: Placing The Desk

    Placing the desk 2 5 m Safety advice To avoid crushing or shearing hazards, the desk with its moving parts must keep a minimum distance of 25 mm to adjacent objects such as furniture, building parts etc. When adjusting the desk top height, the user must make sure that nobody can be injured and no objects can get damaged.
  • Page 11: Levelling The Desk

    Levelling the desk Note The desk must be aligned horizontally with the adjustment plates. Thus, the best stability is achieved.
  • Page 12: Moving The Desk

    Moving the desk Note To move the desk, simply raise the front. Now it can be easily moved back and forth on the integrated castors.
  • Page 13: Performing A Reset

    Performing a reset Important! Before putting the table into operation, it is essential that you perform a reset: Press the "DOWN" button (see p. 19) and the "Safety" button (left side of the table) until the table has reached its lowest position.
  • Page 14: Routing Cable In The Cable Duct

    Routing cables in the cable duct magnetic...
  • Page 15 Mains voltage: 220 - 230 V / 50 - 60 Hz Caution Make sure that the cable length is also sufficient when the desk is in the top position. Route the cable so that no one is likely to trip over it. Danger! Should the power cord become damaged, unplug the desk immediately!
  • Page 16: Locking Height Adjustment

    Locking the height adjustment...
  • Page 17 Note The key switch protects against unauthorized height adjustment of the desk. When the key is removed in the „off“ position, the desk can not be adjusted accidentally or on purpose. Caution Remove key during use. Please do not leave the key in the lock - risk of injury!
  • Page 18: Raising The Desk Top

    Raising the desk When adjusting the desk top height, please make sure that the table movement will not get blocked (e.g. by window sills, chair armrests, file cabinets etc.)and that no persons are located in the hazardous area or will reach into it. Note As delivered, the desk's height adjustment requires two-hand operation for safety reasons.
  • Page 19: Lowering The Desk Top

    Lowering the desk DOWN Note Recommendations on ergonomic height adjustment can be found on page 22. Maximum operation time: After 1 minute of continuous operation, the control unit is automatically disabled for the next 9 minutes! The operation duration is automatically limited to this period. This orevents the desk drive from overheating.
  • Page 20: Enabling Single-Hand Operation

    Enabling single-handed operation The table can be permanently set to single-hand operation so it can be adjusted using the "UP" and "DOWN" keys without pressing the left button. Please disconnect the mains plug from the socket before Remove the plastic cover on the right bottom changing this setting! side of the desk (4 screws, see picture) to get access to the toggle switch.
  • Page 21: Container-Stop / Shelf-Stop Positions

    Container-stop / Shelf-stop positions Container-stop and shelf-stop position These two functions can be used to limit the range of movement of the sit-stand desk (e.g. if a file cabinet is located under the sit-stand table). A container-stop position can be set only in the lower half of the movement range, a shelf-stop position only in the upper half of...
  • Page 22: Recommendations On Ergonomic Adjustment

    Recommendations on ergonomic adjustment The desktop height is continuously adjustable from 56 cm to 118 cm (with height adapter from 66 cm to 128 cm - see page 31) sitting standing ± 10 cm 127 cm ~56 cm ~80 cm 135 cm ~59 cm ~85 cm...
  • Page 23: Opening / Closing The Drawer

    Opening / closing the drawer Opening the drawer press the center of the drawer front and the drawer opens Closing the drawer press the center of the drawer front and close the drawer until it engages with a clicking sound max.
  • Page 24: Power-Management

    Power-Management with integrated power outlets...
  • Page 25 Please make sure that you plug in the connectors and power supplies so that they are not damaged and that no wires get pinched when the drawer is closed.
  • Page 26: Cable Feedthrough

    Cable feedthrough...
  • Page 28: Accessories

    Accessories Cable duct underneath the desk top T8 M...
  • Page 29 Accessories Cable duct underneath the desk top T8 L...
  • Page 30 Accessories Flexlight flexible LED desklight flexible LED desklight...
  • Page 31 Accessories Height adapter to increase the desk top height by 10 cm The desk top height with this adaptor is adjustable from 66 cm to 128 cm USB - Typ A and USB - Typ C...
  • Page 32: Faq

    The height cannot be adjusted: • Is the connection cable correctly plugged into the desk and does the socket have electrical power? • Is the key switch in the correct position (see page 16)? • Has the maximum switch-on time been exceeded (see page 19)? The desk only moves up slowly: •...
  • Page 33: Technical Data

    56 - 118 cm with adaptor (optional) 66 - 128 cm Drawer internal dimensions: T8 M: W 44,0 / D 30 / H 4 cm W 35,5 / D 30 / H 4 cm T8 L: W 44,0 / D 30 / H 4 cm (2x) W 12,5 / D 30 / H 4 cm (2x) Max.
  • Page 34: Ec Declaration Of Conformity
