- Page 1 Part No. 060925-00, Rev. A July 2024 OmniSwitch 6900 Hardware Users Guide www.al-enterprise.com...
- Page 2 This user guide documents OmniSwitch 6900 hardware, including chassis and associated components. The specifications described in this guide are subject to change without notice. The Alcatel-Lucent name and logo are trademarks of Nokia used under license by ALE. To view other trademarks used by affiliated companies of ALE Holding, visit: www.al-enterprise.com/en/legal/...
-
Page 3: Table Of Contents
How is the Information Organized? ................viii Documentation Roadmap ....................viii Related Documentation ...................... x Technical Support ......................xi ......................1-1 Chapter 1 OmniSwitch 6900 OmniSwitch 6900 Availability Features ................. 1-2 Power Supply Redundancy ..................1-2 Hot-Swapping ......................1-2 Hardware Monitoring ....................1-2 ......................2-1 Chapter 2 Getting Started Installing the Hardware ....................2-1... - Page 4 OS6900-X24C2 Chassis Specifications ............3-20 Chassis Status LEDs ....................3-21 Mounting the Switch ..................... 3-22 General Mounting Recommendations ..............3-22 Airflow Recommendations ..................3-23 Front-to-Rear Airflow ..................3-24 Rear-to-Front Airflow ..................3-24 Airflow Mismatch ................... 3-25 Blank Cover Panels ....................3-26 OmniSwitch 6900 Hardware Users Guide July 2024...
- Page 5 Taiwan RoHS: Hazardous Substance Table ............. A-3 California Proposition 65 Warning ..............A-3 Standards Compliance ....................A-4 FCC Class A, Part 15 ....................A-5 Canada Class A Statement ..................A-5 JATE ........................A-5 OmniSwitch 6900 Hardware Users Guide July 2024...
- Page 6 Advertencia sobre una apropiada conexión a tierra ........A-12 Leer “información importante de seguridad” ..........A-12 Advertencia de acceso restringido ..............A-12 Advertencia de pulsera antiestática ..............A-12 Clase de seguridad ..................A-12 Advertencia de fuentes de poder ..............A-12 OmniSwitch 6900 Hardware Users Guide July 2024...
-
Page 7: About This Guide
About This Guide This OmniSwitch 6900 Hardware Users Guide describes OmniSwitch 6900 switch components and basic switch hardware procedures. Supported Platforms The information in this guide applies only to OmniSwitch 6900 switches. Who Should Read this Manual? The audience for this users guide is network administrators and IT support personnel who need to configure, maintain, and monitor switches and routers in a live network. -
Page 8: What Is Not In This Manual
Once you have your switch up and running, you will want to begin investigating basic aspects of its hardware and software. Information about switch hardware is provided in the OmniSwitch 6900 Hardware Users Guide. This guide provide specifications, illustrations, and descriptions of all hardware components. - Page 9 CLI-to-MIB variable mapping information for all CLI commands supported by the switch. This guide can be consulted anytime during the configuration process to find detailed and specific information on each CLI command. OmniSwitch 6900 Hardware Users Guide July 2024...
-
Page 10: Related Documentation
Related Documentation The following are the titles and descriptions of all the OmniSwitch 6900 user manuals: OmniSwitch 6900 Hardware Users Guide • Complete technical specifications and procedures for all OmniSwitch 6900 chassis, power supplies, fans, and Network Interface (NI) modules. -
Page 11: Technical Support
Lucent Enterprise product’s features and functionality and on-site hardware replacement through our global network of highly qualified service delivery partners. With 24-hour access to Alcatel-Lucent Enterprise’s Service and Support web page, you’ll be able to view and update any case (open or closed) that you have reported to Alcatel-Lucent Enterprise’s technical support, open a new case or access helpful release notes, technical bulletins, and manuals. -
Page 12: Chapter 1 Omniswitch 6900
1 OmniSwitch 6900 The OmniSwitch 6900 (OS6900) is a family of aggregation switches that can also be installed as top-of- rack boxes in data centers. Refer to the information below for model number and component type. Model Number Description OS6900-V72... -
Page 13: Omniswitch 6900 Availability Features
Automatic monitoring refers to the switch’s built-in sensors that automatically monitor operations. If an error is detected (e.g., over-threshold temperature), the switch immediately sends a trap to the user. The trap is displayed on the console in the form of a text error message. page 1-2 OmniSwitch 6900 Hardware Users Guide July 2024... - Page 14 The user enters “show” commands that output information to the console. The Show commands for all the features are described in detail in the OmniSwitch CLI Reference Guide. OmniSwitch 6900 Hardware Users Guide July 2024 page 1-3...
-
Page 15: Chapter 2 Getting Started
Each switch requires one grounded electrical outlet for each power supply installed in the chassis. • OmniSwitch 6900 switches offer both AC and DC power supply support. For switches using AC power connections, each supplied AC power cord is 2 meters (approx. 6.5 feet). -
Page 16: Electrical Surge Warning
It is recommended that installers momentarily ground all copper Ethernet cables (especially in new cable runs) to a suitable and safe earth ground before connect- ing them to the port. page 2-2 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 17: Unpacking And Installing The Switch
To protect your switch components from damage, read all unpacking recommendations and instructions carefully before beginning. Unpack your OmniSwitch 6900 chassis as close as possible to the location where it will be installed. Items Included Your OmniSwitch 6900 includes the following items: OmniSwitch chassis with power supplies, per order •... -
Page 18: Airflow Considerations
Sides. 2 inches minimum at left and right sides. Front. 6 inches minimum at front of chassis. Chassis Top View Note. Clearance is not required at the top and bottom of the chassis. page 2-4 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 19: Mounting The Switch
For information on modifying these settings, refer to the OmniSwitch AOS Switch Management Guide. Ethernet Management Port (EMP) Cable Requirements The OmniSwitch 6900 provides an Ethernet Management Port (EMP) on the front or rear panel of the chassis (depending on OS6900 model) for out-of-band management. There are specific cable type require- ments (i.e., straight-through or crossover) based on the device to which the EMP is connecting. - Page 20 Connections and Cabling Getting Started For more on configuring Ethernet ports, refer to the OmniSwitch AOS Network Configuration Guide. page 2-6 OmniSwitch 6900 Hardware Users Guide July 2024...
-
Page 21: Booting The Switch
Command Line Interface (CLI) and configure basic information. Continue to “Your First Login Session” on page 2-8. OmniSwitch 6900 Hardware Users Guide July 2024 page 2-7... -
Page 22: Your First Login Session
The default welcome banner, which includes information such as the current software version and system date, is displayed followed by the CLI command prompt: Welcome to the Alcatel-Lucent Enterprise OS6900-V72 8.9.R04, February 16, 2024. Copyright (c) 1994-2014 Alcatel-Lucent. All Rights Reserved. -
Page 23: Setting Ip Address Information For The Emp
(i.e. TELNET, FTP, HTTP, SSH or SNMP) until you have unlocked these remote session types. See “Unlocking Session Types” on page 2-10 for more information. OmniSwitch 6900 Hardware Users Guide July 2024 page 2-9... -
Page 24: Unlocking Session Types
Your First Login Session Getting Started Unlocking Session Types Security is a key feature on OmniSwitch 6900 switches. As described on page 2-8, when you access the switch for the first time, you must use a direct console port connection. All other session types (Telnet, FTP, WebView, and SNMP) are locked out until they are manually unlocked by the user. -
Page 25: Setting The System Time Zone
However, if no labeling system has been implemented or if you need to determine a switch’s location from a remote site, entering a system location can be very useful. To specify a system location, use the system location command. OmniSwitch 6900 Hardware Users Guide July 2024 page 2-11... -
Page 26: Viewing Your Changes
To view your current changes, enter show system at the CLI prompt. Saving Your Changes Once you have configured this basic switch information, save your changes by entering write memory at the CLI command prompt. page 2-12 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 27: Chapter 3 Chassis And Power Supplies
3 Chassis and Power Supplies This chapter includes detailed information on the OmniSwitch 6900 chassis, as well as fan tray and power supply components. Topics include: Technical specifications, page 3-4, page 3-7, page 3-10 page 3-14. • Switch mounting information, page 3-22. -
Page 28: Omniswitch 6900 Chassis
OmniSwitch 6900 Chassis Chassis and Power Supplies OmniSwitch 6900 Chassis page 3-2 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 29: Os6900-V72 Front Panel
- Port Groups (1-4, 5-8, 9-12, 13-16, 17-20, 21-24, 25-28, 29-32, 33-36, 37-40, 41-44, 45-48) *Refer to page 3-35 for detailed information on port LED behavior. OS6900-V72 Rear Panel Item Description Power Supply Bays Fan Trays (6 individual trays) OmniSwitch 6900 Hardware Users Guide July 2024 page 3-3... -
Page 30: Os6900-V72 Chassis Specifications
(threshold or danger). Ambient temperature refers to the approximate room temperature. The ambient temperature will typically be lower than the chassis temperature. Due to different airflow characteristics, chassis temperatures will vary by model. page 3-4 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 31: Os6900-C32 Front Panel
RJ45 10/100/1000 Ethernet Management Port (EMP) Reset Button (Used to reboot system) *Refer to page 3-35 for detailed information on port LED behavior. OS6900-C32 Rear Panel Item Description Power Supply Bays Fan Trays (6 individual trays) OmniSwitch 6900 Hardware Users Guide July 2024 page 3-5... -
Page 32: Os6900-C32 Chassis Specifications
(threshold or danger). Ambient temperature refers to the approximate room temperature. The ambient temperature will typically be lower than the chassis temperature. Due to different airflow characteristics, chassis temperatures will vary by model. page 3-6 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 33: Os6900-C32E Front Panel
Console Port Reset Button (Used to reboot system) *Refer to page 3-35 for detailed information on port LED behavior. OS6900-C32E Rear Panel Item Description Power Supply Bays Fan Trays (6 individual trays) OmniSwitch 6900 Hardware Users Guide July 2024 page 3-7... -
Page 34: Os6900-C32E Chassis Specifications
(threshold or danger). Ambient temperature refers to the approximate room temperature. The ambient temperature will typically be lower than the chassis temperature. Due to different airflow characteristics, chassis temperatures will vary by model. page 3-8 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 35: Os6900-T48C6 Front Panel
*Refer to page 3-35 for detailed information on port LED behavior. OS6900-T48C6 Rear Panel Item Description Power Supply Bays Fan Trays (5 individual trays) OmniSwitch 6900 Hardware Users Guide July 2024 page 3-9... -
Page 36: Os6900-T48C6 Chassis Specifications
(threshold or danger). Ambient temperature refers to the approximate room temperature. The ambient temperature will typically be lower than the chassis temperature. Due to different airflow characteristics, chassis temperatures will vary by model. page 3-10 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 37: Os6900-X48C6 Front Panel
*Refer to page 3-35 for detailed information on port LED behavior. OS6900-X48C6 Rear Panel Item Description Power Supply Bays Fan Trays (5 individual trays) OmniSwitch 6900 Hardware Users Guide July 2024 page 3-11... -
Page 38: Os6900-X48C6 Chassis Specifications
(threshold or danger). Ambient temperature refers to the approximate room temperature. The ambient temperature will typically be lower than the chassis temperature. Due to different airflow characteristics, chassis temperatures will vary by model. page 3-12 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 39: Os6900-X48C4E Front Panel
- Port Group 1 (41,42,43,44) - Port Group 2 (45,46,47,48) *Refer to page 3-35 for detailed information on port LED behavior. OS6900-X48C4E Rear Panel Item Description Power Supply Bays Fan Trays (6 individual trays) OmniSwitch 6900 Hardware Users Guide July 2024 page 3-13... -
Page 40: Os6900-X48C4E Chassis Specifications
(threshold or danger). Ambient temperature refers to the approximate room temperature. The ambient temperature will typically be lower than the chassis temperature. Due to different airflow characteristics, chassis temperatures will vary by model. page 3-14 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 41: Os6900-V48C8 Front Panel
10G speeds is supported. Group Ports 1,2,3,6 4,5,7,9 8,10,11,12 13,14,15,18 16,17,19,21 20,22,23,24 Group Ports 25,26,27,30 28,29,31,33 32,34,35,36 37,38,39,42 40,41,43,45 44,46,47,48 Port Group Numbering Table Front Panel Ports 1-48 Representation OmniSwitch 6900 Hardware Users Guide July 2024 page 3-15... -
Page 42: Os6900-V48C8 Rear Panel
(threshold or danger). Ambient temperature refers to the approximate room temperature. The ambient temperature will typically be lower than the chassis temperature. Due to different airflow characteristics, chassis temperatures will vary by model. page 3-16 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 43: Os6900-T24C2 Front Panel
RJ45 10/100/1000 Ethernet Management Port (EMP) System Status LEDs* 10GBASE-T (Ports 1-24 - 100M/1G/10G) SFP+ (Ports 25-26 - 1G/10G) QSFP28 (Ports 27-28 - 4X10G/40G/4X25G/100G) *Refer to page 3-35 for detailed information on port LED behavior. OmniSwitch 6900 Hardware Users Guide July 2024 page 3-17... -
Page 44: Os6900-T24C2 Rear Panel
(threshold or danger). Ambient temperature refers to the approximate room temperature. The ambient temperature will typically be lower than the chassis temperature. Due to different airflow characteristics, chassis temperatures will vary by model. page 3-18 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 45: Os6900-X24C2 Front Panel
RJ45 10/100/1000 Ethernet Management Port (EMP) System Status LEDs* SFP+ (Ports 1-24 - 1G/10G) SFP+ (Ports 25-26 - 1G/10G) QSFP28 (Ports 27-28 - 4X10G/40G/4X25G/100G) *Refer to page 3-35 for detailed information on port LED behavior. OmniSwitch 6900 Hardware Users Guide July 2024 page 3-19... -
Page 46: Os6900-X24C2 Rear Panel
(threshold or danger). Ambient temperature refers to the approximate room temperature. The ambient temperature will typically be lower than the chassis temperature. Due to different airflow characteristics, chassis temperatures will vary by model. page 3-20 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 47: Chassis Status Leds
LEDs 1 - 4 White 4X25G LEDs 1 - 4 Green 4X10G QSFP28 Ports LED 1 - Green 100G LED 1 - Blue LEDs 1 - 4 Amber 4X25G LEDs 1 - 4 Purple 4X10G OmniSwitch 6900 Hardware Users Guide July 2024 page 3-21... -
Page 48: Mounting The Switch
Reliable Earthing. Reliable earthing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch (e.g., use of power strips). page 3-22 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 49: Airflow Recommendations
Sides. 2 inches minimum at left and right sides. Front. 6 inches minimum at front of chassis. Chassis Top View Note. Clearance is not required at the top and bottom of the chassis. OmniSwitch 6900 Hardware Users Guide July 2024 page 3-23... -
Page 50: Front-To-Rear Airflow
Chassis and Power Supplies Front-to-Rear Airflow The OmniSwitch 6900 fan tray and power supplies are located at the rear of the switch and draw air through the intake vents located at the top-front of the chassis. The air is directed straight through the chassis’... -
Page 51: Airflow Mismatch
3-21, warnings displayed, switch will reboot when it reaches temperature danger threshold. Color Coding To help users avoid mismatched fan trays and power supplies, rear-to-front components are marked with purple color coding. (Front-to-rear components use standard product colors.) OmniSwitch 6900 Hardware Users Guide July 2024 page 3-25... -
Page 52: Blank Cover Panels
Note. Because they regulate airflow and help protect internal chassis components, blank cover panels should be installed over empty module slots and power supply bays at all times. Blank Panels and Chassis Airflow page 3-26 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 53: Rack-Mounting
One person should lift and position the chassis until the rack-mount flanges are flush with the rack post. Align the holes in the flanges with the rack holes marked in step 1. OmniSwitch 6900 Hardware Users Guide July 2024 page 3-27... - Page 54 Failure to properly mount the switch may result in the chassis sagging in the rack or damage to the switch and its components. Refer to the following sections for more information. page 3-28 OmniSwitch 6900 Hardware Users Guide July 2024...
-
Page 55: Mid-Mounting The Chassis In The Rack
One person should lift and position the chassis until the mid-mount flanges are flush with the rack post. Align the holes in the flanges with the rack holes marked in step 3. OmniSwitch 6900 Hardware Users Guide July 2024 page 3-29... - Page 56 Once the holes are aligned, the second person should insert a screw through the bottom hole on each flange. Tighten both screws until they are secure. Once the flanges are aligned, install the remaining screws. Be sure that all screws are securely tightened. page 3-30 OmniSwitch 6900 Hardware Users Guide July 2024...
-
Page 57: Standalone (Non-Rack Mounted) Installations
Weight Considerations Depending on model type, an empty OmniSwitch 6900 chassis weighs up to 7.78 kg (17.15 lbs). When fully populated with fan tray, power supplies and plug-in modules, the OmniSwitch 6900 can weigh up to 10.86 kg (23.95 lbs). -
Page 58: Power Supplies
Chassis and Power Supplies Power Supplies OmniSwitch 6900 power supplies are located at the rear of the switch chassis. Two slots are provided. If a second power supply is installed, it will assume a standby role. Please note that the OS6900 does not provide an on/off switch. Connecting an installed power supply to a power source will boot the switch. -
Page 59: Os6900-V72/C32/C32E/X48C4E/V48C8 Ac Power Supply
AC Power Supply LED States LED State Description Solid Green The power supply is operating normally and providing power to the chassis Solid Red Power supply failure No AC power. OmniSwitch 6900 Hardware Users Guide July 2024 page 3-33... -
Page 60: Os6900-T48C6/X48C6/T24C2/X24C2 Ac Power Supply
AC Power Supply LED States LED State Description Solid Green The power supply is operating normally and providing power to the chassis Solid Red Power supply failure No AC power. page 3-34 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 61: Os6900-V72/C32/C32E/X48C4E/V48C8 Dc Power Supply
DC Power Supply LED States LED State Description Solid Green The power supply is operating normally and providing power to the chassis Solid Red Power supply failure No DC power. OmniSwitch 6900 Hardware Users Guide July 2024 page 3-35... -
Page 62: Os6900-T48C6/X48C6/T24C2/X24C2 Dc Power Supply
DC Power Supply Cord (IEC 60945) This cable is required for the OS6900-X48C6 when used with the OS6900X-BPD-F power supply in installations that require IEC 60945 certification. OS-DNV-DC-PWR - IEC 60945 Certified Cable (Two Ferrite Cores) page 3-36 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 63: Dc Power Supply Connections
-48VDC power. Observe proper polarity when connecting to a fuse panel. The cable wire leads must be connected as follows: Green/yellow - ground • Black - return • Red - -48VDC • OmniSwitch 6900 Hardware Users Guide July 2024 page 3-37... -
Page 64: Installing Power Supplies
3. Plug the power cord into power supply socket. OS6900 Power Supply Install (X48C6/T48C6 shown) Note. The chassis does not provide an on/off switch. Connecting a the power supplies to a power source will boot the switch. page 3-38 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 65: Removing Power Supplies
3. Install replacement power supply. OS6900 Power Supply Removal (X48C6/T48C6 shown) Note. If you are not replacing the power supply, be sure to install a blank cover panel over the empty power supply bay. OmniSwitch 6900 Hardware Users Guide July 2024 page 3-39... -
Page 66: Chassis Fan Tray
Chassis and Power Supplies Chassis Fan Tray The OmniSwitch 6900 chassis houses multiple fan trays. The fans are the main temperature control components for the switch, providing cooling airflow for all chassis components. This airflow is a crucial factor in the switch’s overall operability. Refer to “Airflow Recommendations”... - Page 67 Chassis and Power Supplies Chassis Fan Tray Airflow Fans are available in either a front-to-rear or rear-to-front model. Note: Do not attempt to install incompatible fan models in a chassis. OmniSwitch 6900 Hardware Users Guide July 2024 page 3-41...
-
Page 68: Replacing The Fan Tray
3. Install new fan tray and tighten captive screw. OS6900 Fan Tray Replacement- (V72/C32/C32E/X48C4E/V48C8 shown) Important. The switch should not run without a fan tray more than 60 seconds to prevent over heating page 3-42 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 69: Grounding The Chassis
Use this connector to supplement the ground provided by the AC power cord. To do so, install a Panduit Grounding Lug (type LCD8-10A-L) using 8AWG copper conductors to the paint-free area. Torque to between 30-60 inch pounds Refer to the rear chassis views on page 3-2 for location details. OmniSwitch 6900 Hardware Users Guide July 2024 page 3-43... -
Page 70: Monitoring Chassis Components
To check the switch’s current temperature status, use the show temperature command: -> show temperature For more information about this command, see the “Chassis Management and Monitoring Commands” chapter in the OmniSwitch AOS Release 8 CLI Reference Guide page 3-44 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 71: Temperature Errors
To check the switch’s current fan tray status, use the show fan command. For example: -> show fan For more information about this command, see the “Chassis Management and Monitoring Commands” chapter in the OmniSwitch CLI Reference Guide. OmniSwitch 6900 Hardware Users Guide July 2024 page 3-45... -
Page 72: Pinouts
Pinouts Chassis and Power Supplies Pinouts OmniSwitch 6900 RS-232 console ports use either an RJ-45 connector or a USB connector. (Refer to diagrams below.) Three signals are used: Transmit Data (TXD), Receive Data (RXD) and Signal Ground (GND). The data sent out from the console port to the receiving device. -
Page 73: Rj-45 Console Port - Connector Pinout
10/100 Ethernet Port – RJ-45 Pinout Pin Number Description not used not used not used not used Gigabit Ethernet Port – RJ-45 Pinout Pin Number Description BI_DA+ BI_DA- BI_DB+ BI_DC+ BI_DC- BI_DB- BI_DD+ BI_DD- OmniSwitch 6900 Hardware Users Guide July 2024 page 3-47... -
Page 74: Appendix A Regulatory Compliance And Safety Information
A Regulatory Compliance and Safety Information This appendix provides information on regulatory agency compliance and safety for OmniSwitch 6900 switches. Declaration of Conformity: CE Mark This equipment is in compliance with the essential requirements and other provisions of Directive 2004/108/EC (EMC), 2006/95/EC (LVD), 91/263/EEC (Telecom Terminal Equipment, if applicable), 1999/5/EC (R&TTE, if applicable). -
Page 75: China Rohs: Hazardous Substance Table
Declaration of Conformity: CE Mark Regulatory Compliance and Safety Information China RoHS: Hazardous Substance Table page A-2 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 76: Taiwan Rohs: Hazardous Substance Table
State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. Products are packaged using one or more of the following packaging materials: Corrugated Cardboard Corrugated Fiberboard Low-Density Polyethylene OmniSwitch 6900 Hardware Users Guide July 2024 page A-3... -
Page 77: Standards Compliance
The product bears the CE mark. In addition it is in compliance with the following other safety and EMC standards: All hardware switching modules used in an OmniSwitch 6900 switch comply with Class A standards. Modules with copper connectors meet Class A requirements using unshielded (UTP) cables. -
Page 78: Canada Class A Statement
RÈglement sur le brouillage radioèlectrique ètabli par le ministère des Communications du Canada. JATE This equipment meets the requirements of the Japan Approvals Institute of Telecommunications Equipment (JATE). OmniSwitch 6900 Hardware Users Guide July 2024 page A-5... -
Page 79: Cispr22 Class A Warning
Warning: To avoid electromagnetic interference, this product should not be installed or used in residential environments. 警告：為避免電磁干擾，本產品不應安裝或使用於住宅環境 Class 1M Laser Warning CLASS 1M LASER RADIATION WHEN OPEN. DO NOT VIEW DIRECTLY WITH OPTICAL INSTRUMENTS. page A-6 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 80: Network Cable Installation Warning
Deutsch: Dieses Gerät soll nur von Personal installiert oder gewartet werden, welches in elektrischen und mechanischen Grundlagen ausgebildet ist. Español: Estos equipos deben ser instalados y atendidos exclusivamente por personal adecuadamente formado y capacitado en técnicas eléctricas y mecánicas. OmniSwitch 6900 Hardware Users Guide July 2024 page A-7... -
Page 81: Invisible Laser Radiation Warning
Netzverbindungen getrennt sind bevor das Gerät gewartet oder bewegt wird. Español: Antes de empezar a trabajar con un sistema, asegurese que el interruptor está cerrado y el cable eléctrico desconectado. page A-8 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 82: Proper Earthing Requirement Warning
Erde angeschlossen werden. Español: Para EMC/EMI, cada fuente de alimentación de CC/CC requiere que el cable de tierra esté conectado desde cada fuente de alimentación de CC/CC a la conexión a tierra. OmniSwitch 6900 Hardware Users Guide July 2024 page A-9... -
Page 83: Read Important Safety Information Warning
Español: Debido a las descargas electrostáticas (ESD) puede dañar los componentes del interruptor, debe seguir los procedimientos adecuados para eliminar la EDS de su persona y sus alrededores antes de manipular los componentes del interruptor. page A-10 OmniSwitch 6900 Hardware Users Guide July 2024... -
Page 84: Instrucciones De Seguridad En Español
Su interruptor esta equipado por fuentes de alimentación múltiples. Para reducir el riesgo de choque eléctrico, asegúrese desconectar todas las conexiones de alimentación antes de mantener o de mover la unidad. OmniSwitch 6900 Hardware Users Guide July 2024 page A-11... -
Page 85: Advertencia Sobre Una Apropiada Conexión A Tierra
Cumple con 21CFR 1040.10 y 1040.11 ó sus equivalentes. Advertencia de fuentes de poder Las unidades OmniSwitch 6900 pueden estar equipadas con tres cordones para fuente de poder. Para reducir el riesgo de un choque electrico, desconecte todos los cordones de fuente de poder antes de dar servicio a la unidad.
