Summary of Contents for Third Reality 3RSB015BZ
- Page 3 More intelligent control like voice control, app control, create routines, setting schedules/timers and set- ting groups can be achieved by connecting to gateways. Such as compatible Echo devices(which have Zigbee hub bulit-in), SmartThings, Home Assistant, Eero 6 & Eero 6 Pro, Third Reality Hub and Hubitat.
- Page 4 Work with multiple platforms. Smart Blind can also connect with SmartThings, Home Assistant, Eero 6 & Eero 6 Pro, Third Reality Hub and Hubitat. Unique and novel design Smart blind uses bottom drive design, which makes daily operation more convenient and easier to re- place the battery.
- Page 5 LED Status Pairing: fast blinking (twice per second) Indicator Off-line: slow blinking (blink once every three seconds) Low power: double blinking (two Setting short blinks every two seconds) Bottom Sensor Once the Bottom Sensor is triggered when the Smart Blind is turned down, the Smart Blind will stop moving, and the position (where the bottom sensor is triggered) will be...
- Page 6 L Bracket x2 U Bracket x2 AA Battery x6 Battery Cover (AA Battery x2)
- Page 7 THIRDREALITY Smart Blind supports both inside and out- side mount, a pair of L shape brackets and a pair of U brackets, screws and plastic expansion bolts are provided. Please prepare a PH2 screwdriver for the mount; For ma- sonry surface please prepare an electric drill with an M5 drill bit.
- Page 8 According to the diagram, measure and mark the po- sition; For wooden surface use a PH2 screwdriver and the provided screws to secure the bracket. For masonry surface use a M5 drill bit to drill a pilot hole for the provided plastic expansions bolt. Insert the plastic expansion bolt into the pilot hole, then use a PH2 screwdriver to secure the bracket with the provided screw.
- Page 9 For wooden surface use a PH2 screwdriver and the provided screw to secure the bracket. For masonry surface use an M5 drill bit to drill a pilot hole for the provided plastic expansion bolt. Insert the plastic expansion bolt into the pilot hole, then use a PH2 screwdriver to secure the bracket with the provided screw.
- Page 10 Unscrew the screw with the PH2 screwdriver to open the battery cover, install 4 provided AA batter- ies, close and secure the battery cover with the screw.
- Page 11 Outside Mount/Inside Mount Outside Mount: Firstly align the outside of the top rail with the brackets, then push up the smart blind to get it into place. The bracket's button pops up and makes a clicking sound, indicating it is secured. To uninstall the smart blind, push the button of the brackets and then pull down the smart blind.
- Page 12 Set the position where you want the bottom of your Smart Blind to rest. Before setting the bottom position, firstly press UP button on the bottom rail of the Smart Blind or use the remote to let the Smart Blind retract to the top position.
