Third Reality Smart Blind Lite User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Smart Blind Lite
User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the Smart Blind Lite and is the answer not in the manual?

Questions and answers

Related Manuals for Third Reality Smart Blind Lite

Summary of Contents for Third Reality Smart Blind Lite

  • Page 1 Smart Blind Lite User Manual...
  • Page 2 Local Using of Smart Blind Lite...
  • Page 3 The Smart Blind Lite has a thoughtful design on the bottom which can automatically detect the window sill and then stop. Smart Blind Lite is designed to run on Alka- line Batteries power and the drive units is at the bottom of blind, let the battery replacement becomes more conve- nient.
  • Page 4 No worry about batteries is dead, but it is hard to find replacement batteries. Functions provided by Alexa App Smart Blind Lite works with Alexa and it has multiple functions, including schedule, group and routine. Set your blind on or open according to the sunset or sun-...
  • Page 5 Down: extend Stop/Reset Bottom Sensor When the Smart Blind Lite is extending, if the Bottom Sensor hits any surface(like the window sill or your finger) , it will stop at this position. The Bottom Sensor is also used to set the bottom position.(See P9)
  • Page 6 For masonry surface please prepare an electric drill with an M5 drill bit. Make sure the THIRD- REALITY logo of the Smart Blind Lite and the button of the L brackets face in when installed. Choose inside or outside mount as needed. Make sure your window recess meets the minimum depth requirement of 2"...
  • Page 7 According to the diagram, measure and mark the po- sition; For wooden surface use a PH2 screwdriver and the provided screws to secure the bracket. For masonry surface use a M5 drill bit to drill a pilot hole for the provided plastic expansions bolt. Insert the plastic expansion bolt into the pilot hole, then use a PH2 screwdriver to secure the bracket with the provided screw.
  • Page 8 For wooden surface use a PH2 screwdriver and the provided screw to secure the bracket. For masonry surface use an M5 drill bit to drill a pilot hole for the provided plastic expansion bolt. Insert the plastic expansion bolt into the pilot hole, then use a PH2 screwdriver to secure the bracket with the provided screw.
  • Page 9 Unscrew with the PH2 screwdriver to open the bat- tery cover, install AA batteries, close and secure the battery cover with the screw.
  • Page 10 Outside Mount/Inside Mount Firstly align the outside of the top rail with the brack- ets, then push up the Smart Blind Lite to get it into place. The bracket's button pops up and makes a clicking sound, indicating it is secured. To uninstall the Smart Blind Lite, push the button of the brackets and then pull down the Smart Blind Lite.
  • Page 11 Set the position where you want the bottom of your Smart Blind Lite to rest Press the UP button and let the Smart Blind Lite re- tract to the highest position, now the Smart Blind Lite returns to the original zero percent. Pess the...
  • Page 12 Local Using of Smart Blind Lite The height of our ThirdReality Smart Blind Lite support 72 inches at maximum. You can use the remote (sold separately) or 3 control but- tons on the bottom rail to control the Smart Blind Lite.

  • Page 14: Voice Control

    Using Smart Blind Lite The height of our ThirdReality Smart Blind Lite support 72 inches at maximum. Voice Control "Alexa, turn on / off first blind." "Alexa, set / turn on / turn off / turn up / turn down / open / close first blind to 50%."...
  • Page 18 Using Smart Blind Lite After adding the Smart Blind Lite to your Third Reality Smart Hub, enable Third Reality Skill and tap "DISCOVER DEVICES" in your Alexa App, now you can use the voice as- sistant or to create routines in your Alexa App to control...
  • Page 20 " button of blinds for more than 5 seconds until the LED light flashes rapid- ly in red, indicating that the Smart Blind Lite is in pairing mode. Every time you factory reset the Smart Blind Lite, your preset bottom position will be reset to default(72"), you need to reset your desired...
  • Page 21 How to change the bottom position of the Smart Blind Lite Press the UP button and let the Smart Blind Lite re- tract to the highest position, now the Smart Blind Lite returns to the original zero percent. Pess the...
  • Page 22 How to stop the Smart Blind Lite when it's ex- tending/retracting? You can stop the Smart Blind Lite from extending / re- tracting with a stop command of pressing the Stop button on the bottom rail or the remote, or in your Third Reality App.
  • Page 23 This device complies with part 15 of the FCC rules. Opera- tion is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’...

  • Page 24: Limited Warranty

    NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’ s authority to operate the equipment. RF Exposure This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
