TM
Jet-Pong Home Quick Start Guide
Revision 2 – June 20, 2024
Valley-Dynamo
www.valley-dynamo.com
7115 Belton St.
Richland Hills, TX 76118
U.S.A.
National Sales Email:
sales@valley-dynamo.com
International Sales Email:
international@valley-dynamo.com
Technical Assistance:
techhelp@valley-dynamo.com
Tech Support Hotline (during business hours Central U.S. Time):
1-972-595-5300 (follow prompts for Tech Support)
Spare Parts:
www.valley-dynamoparts.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Valley-Dynamo JET PONG Home
Summary of Contents for Valley-Dynamo JET PONG Home
- Page 1 Jet-Pong Home Quick Start Guide Revision 2 – June 20, 2024 Valley-Dynamo www.valley-dynamo.com 7115 Belton St. Richland Hills, TX 76118 U.S.A. National Sales Email: sales@valley-dynamo.com International Sales Email: international@valley-dynamo.com Technical Assistance: techhelp@valley-dynamo.com Tech Support Hotline (during business hours Central U.S. Time):...
- Page 2 WARRANTY PERIOD 90-day warranty period WARRANTY SERVICE Valley-Dynamo will, at its sole option, repair, upgrade or replace this product in the event of any defect in materials or workmanship during the warranty period. This shall be Valley-Dynamo's sole obligation, and the customer's sole remedy, for any warranty claim.
- Page 3 RMA number, contact Valley-Dynamo referencing the Model number and Serial number of the unit and the nature of the problem. Valley-Dynamo will, at its discretion, send replacement parts and/or issue an RMA for the return of failed parts. To avoid billing issues, request an RMA when the failed part is present or readily available. Credit will be issued only upon receipt and inspection of the RMA.
- Page 4 Set-up Part Listing Quantity per Part number Description Game NI20300890 1/2-13 LEG LEVELER HEX NUT 16 OZ RED SOLO CUP - STANDARD JP-20510030 DISPOSABLE JP-21710170 40mm PING PONG BALL 20515140 C/T LEG LEVELLER NI870007405 CORNER CASTING BOLT 3/8-16 x 3/4" JP-20100130 DEC HEAD BOLT, 1/4-20 X .984 JP-20600060...
- Page 5 Step 2: Level the cabinet using the leg levelers so that the cabinet is leaning 2 degrees towards the players. This will allow balls on the Game top table surface to roll back to the players. Step 3: Remove the cardboard box from inside the cabinet. It has the Extra cups and balls, Hardware, Mending plates, RGB LED remote control and Power Cord inside.
- Page 6 Step 6: Mount the Back Upright Section on the rear of the cabinet, using (6) 3/8” x 2 ½” Steel Dowels, (2) Mending Plates, and (8) 3/8-16 x ¾” Hex Head Bolts. Step 7: Connect the 12V Power (yellow & black wires) and HDMI Cable into the back of the Monitor at the rear.
- Page 7 Step 9: Position the black Ball Return shelf in place so that the grey ribbon cable and 12V cable (black & yellow) remain on top of the shelf. Connect the grey ribbon cable and 12V cable to the Triangle Cup Tray Assembly. Make certain the connectors lock in place. Secure the black ball return shelf using the screw you previously set aside.
- Page 8 You can download the Jet-Pong Home User’s Manual from our website - www.valley-dynamo.com or from www.jet-pong.com. Step 14: To start a game simply press the Green Pushbutton to scroll down a menu of games.
- Page 9 Step 15: Once the game is selected and starts, simply have the Green Player press the Green Flashing button to launch a ball, pick and then toss it into the Red Solo cups. Once the “Shot Clock” times out the Red Flashing button will flash for the Red Player to play and so on. Step 16: Once everything is working install the Ball Shield by removing the Protective Coating and inserting it into the rear slot near the cups.
- Page 10 Step 17: Remove the Protective Coating from the Side Shields. Using a 4mm or 5/32” hex Allen-key install the Side Shields using the screws provided in the box. Do not overtighten. Note: There are extra balls and cups in the game should you need them in the future (Note: do not fill the ball return tube further than the plastic tube fitting near the triangle area).
- Page 11 Home Photo Screen Savers on Rear Scoreboard Display: Jet-Pong Home has screen savers that you can display on the rear Scoreboard when the game is not being played. A total of 8 photos can be displayed every 5 sec. by placing these on a USB stick and inserting it into the mTV-100. Photos for the mTV-100 need to be 1280 x 720 p resolution.
-
Page 12: Replacement Parts List
Replacement Parts List: The following is a Replacement Parts List for both the Coin and Home versions of Jet-Pong. Please use the Valley- Dynamo part numbers on this list when ordering from our parts department: www.valley-dynamoparts.com.
