ENGLISH
INSTRUCTION MANUAL
ET17 Utility Borescope
• HIGH-RESOLUTION
0.22" (5.5 mm) CAMERA
• HIGH-RESOLUTION
4.3" (109 mm) SCREEN
• IP67- Rated 9.8' (3 m) PVC
GOOSENECK WITH 6 LED LIGHTS
ET18 Plumber's Borescope
• HIGH-RESOLUTION
0.22" (5.5 mm) CAMERA
• HIGH-RESOLUTION
4.3" (109 mm) SCREEN
• IP67- Rated 4.9' (1.5 m) ARMORED
GOOSENECK WITH 6 LED LIGHTS
ET19 Pro Borescope
• HIGH-RESOLUTION
0.22" (5.5 mm) CAMERA
• HIGH-RESOLUTION
4.3" (109 mm) SCREEN
• IP67- Rated 9.8' (3 m) ARMORED
GOOSENECK WITH 6 LED LIGHTS
• WI-FI CAPABILITY FOR SAVING/
SHARING IMAGES/VIDEOS
ESPAÑOL
pg. 7
FRANÇAIS
pg. 13
ET17
ET18
ET19
Advertisement
Table of Contents
Related Manuals for Klein Tools ET17
Summary of Contents for Klein Tools ET17
- Page 1 ET17 ENGLISH ET18 INSTRUCTION MANUAL ET19 ET17 Utility Borescope • HIGH-RESOLUTION 0.22" (5.5 mm) CAMERA • HIGH-RESOLUTION 4.3" (109 mm) SCREEN • IP67- Rated 9.8' (3 m) PVC GOOSENECK WITH 6 LED LIGHTS ET18 Plumber’s Borescope • HIGH-RESOLUTION 0.22" (5.5 mm) CAMERA •...
-
Page 2: General Specifications
ET19 Pro Borescope are professional-grade instruments equipped with a 0.22" (5.5 mm) camera encircled by 6 powerful LEDs. The ET17 is equipped with a 9.8' (3 m) PVC gooseneck, the ET18 features a 4.9' (1.5 m) armored gooseneck, and the ET19 boasts a 9.8' (3 m) armored gooseneck with a dual lens. -
Page 3: Symbols On Instrument
WARNINGS KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. To ensure safe operation and service of the instrument, follow these instructions. Failure to observe these warnings can result in serious personal injury, re, or electrical shock. • The borescope, including the camera end, is NOT insulated. Avoid probing areas where energized conductive elements may be present. - Page 4 ENGLISH ET19 COMPLIANCE This device complies with part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received,including interference that may cause undesired operation.
-
Page 5: Ic Radiation Exposure Statement
UKCA DECLARATION OF CONFORMITY Hereby, Klein Tools declares that this product is in compliance with the relevant statutory requirements. The complete declaration of conformity can be found on this product’s page at www.kleintools.com. -
Page 6: Feature Details
ENGLISH FEATURE DETAILS 20 20 20 1. 4.3" LCD Screen 17. ET17 Gooseneck Camera 9.8' (3 m) (Cat. No. 69462) 2. Capture Image / Record Button Rotate Image Button 18. ET18 Gooseneck Camera 4.9' (1.5 m) (Cat. No. 69464) 4. Image / Video Button 5. -
Page 7: Digital Zoom
OPERATING INSTRUCTIONS CHARGING NOTE: Fully charge before first use. Open the Port Cover from the small end with the battery symbol to access the charging port. Connect the USB-C side of the included USB cable to the USB-C Charging Port , and connect the other end into a USB-A computer port, AC adapter, or other USB power supply (not included.) The Charging Indicator... - Page 8 ENGLISH OPERATING INSTRUCTIONS MENU NOTE: While in Menu mode, press the Menu Button to return to live view. Press the Menu Button then use the Up and Down Buttons to navigate to the following items: Gallery: Press the Menu Button then use the Up and Down Buttons...
- Page 9 OPERATING INSTRUCTIONS Use the Up and Down Buttons to select Date + Time. Press the Enter Button to enter Set Date + Time settings. Use Up and Down Buttons to navigate to the desired field and press the Enter Button to select.
