- Page 1 ET500 Instruction Manual ENGLISH ENGLISH • VIDeo/aUDIo & pHoto RECoRDING • BrIGHt leD WorklIGHt • Ip67 GooSeneck caMera • Screen rotatIon • tV-oUt & SD carD • fIle playBack 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431...
- Page 2 ET500 Instruction Manual ENGLISH ENGLISH • VIDeo/aUDIo & pHoto RECORDING • BrIGHt leD WorklIGHt • Ip67 GooSeneck caMera • Screen rotatIon • tV-oUt & SD carD • fIle playBack...
-
Page 3: General Specifications
Video Borescope Instruction Manual General SpecIfIcatIonS The Klein Tools ET500 Video Borescope is an extendable video camera used to view inaccessible areas. It features video, audio, and photo recording, file playback, a durable camera snake with an adjustable intensity LED worklight, and video output capabilities. -
Page 4: Package Contents
WARNING SYMBOLS: Always wear approved eye protection. Do NOT use on energized circuits. Do NOT probe moving machinery. packaGe contentS Main Unit Gooseneck camera 17mm 18650 Series 3.7V 2000mah rechargeable li-Ion Battery Mirror camera attachment Hook camera attachment Magnet camera attachment USB power adapter/charger USB Data/charger cable rca composite a/V to 3.5mm Mini a/V cable... -
Page 5: Feature Layout
ENGLISH featUre layoUt... - Page 6 featUre layoUt lcD Screen: 3.2" TFT LCD screen. power Button: Press and hold for 3 seconds to turn the instrument on and off. Bright plus Button: Increases the brightness of the camera-mounted LEDs up to 10. Deletes photos or videos in the file explorer mode. Bright Minus Button: Decreases the brightness of the camera-mounted LEDs down to 0 (off).
-
Page 7: Powering On/Off
ENGLISH SetUp CHARGING The rechargable lithium-ion battery should be charged before operating the borescope for the first time. The battery can be charged via a standard 120V wall outlet or through a computer USB port. An exhausted battery will take up to 5 hours to charge. -
Page 8: Live Video Mode
lIVe VIDeo MoDe On startup, the borescope will enter the live output mode. The screen will show the live output of the gooseneck camera along with the LED brightness, date and time, and amount of video/photo storage remaining. leD BrIGHtneSS The borescope gooseneck camera head has several LEDs used to light your work area. - Page 9 ENGLISH MenU MoDe (SySteM SetUp) In Menu Mode you can configure system settings, browse media, or work with storage. enterInG/eXItInG MenU MoDe From Live Video Mode, press and release the OK button to enter Menu Mode. To exit the Menu Mode, press the ESC button at the top level menu. top leVel MenU Viewer: Browse photos or playback videos.
- Page 10 Video player full Screen Left/Right Start the previous or next video in the menu. Toggle between play and pause. Go back to Video Player Menu. picture View Menu Left/Right Highlight/preview a photo. View the highlighted photo full screen. Go back to Viewer Top Menu. Delete the highlighted photo.
-
Page 11: Time Set
ENGLISH tV out Menu Left/Right Highlight output device. Select an output device. Go back to top level menu. SettInGS Control the look of the videos and photos by adjusting these settings. Video Settings Menu Left/Right Highlight video setting. Top Trigger Increase a setting's value. - Page 12 LANGUAGE Set the language used in the system menu and on-screen labels. time Set Menu Left/Right Highlight a language setting. Select the highlighted language setting. Go back to top level menu. 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com...
-
Page 13: Computer Setup
ENGLISH coMpUter SetUp The borescope can be used in conjunction with a personal computer to extend its functionality. copying Media There are two ways to copy photos and videos from the borescope to a computer. If you are using an SD card and your computer has an SD card adapter, you can remove the SD card from the borescope and insert it into the computer. - Page 14 The borescope creates a "PICTURE" and a "VIDEO" folder to store media. From here, you can access the photos or videos directly from the removable disk, or you can copy them to your hard drive by right clicking a folder or fi le and selecting "Copy". Browse to the destination folder, right click on it and select "Paste".
-
Page 15: Battery Replacement
Battery replaceMent pull back orange handle cover from the indented sides near the top. Disconnect battery cable and recycle exhausted battery. acquire a "18650" Lithium Ion 3.7V 2000mAh battery. connect battery cable to new battery observing polarity and place into battery compartment.
