NANLITE FC-300B User Manual

Led bi-color spot light
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FC-300B
LED Bi-color Spot Light
USER MANUAL
Guangdong NanGuang Photo&Video Systems Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FC-300B and is the answer not in the manual?

Questions and answers

Related Manuals for NANLITE FC-300B

Summary of Contents for NANLITE FC-300B

  • Page 1 FC-300B LED Bi-color Spot Light USER MANUAL Guangdong NanGuang Photo&Video Systems Co., Ltd.
  • Page 2 Thank you for purchasing Nanlite product--FC-300B! FC-300B is a LED bi-color spot light designed for content creators and photographers. With stylish and compact fixture body, FC-300B has remarkable performance: 350W rated power, 2700K-6500K CCT adjustment, 4 fan modes, 12 built-in effects, and combined with different control options including on-board, remote control, Nanlink App and DMX/RDM.
  • Page 3 FC-300B LED Bi-color Spot Light Product Diagram FC-300B Technical Data Rated Power: 350W Input: DC 48V/6.6A Max AC 100-240V 50/60Hz Color Temperature: 2700K-6500K CRI: Average 96 TLCI: Average 98 WWW.NANLITE.COM...
  • Page 4 10. Reflector 2. USB Port 3. Display Screen 11. Umbrella Mount 4. Right Knob 5. Left Knob 6. Button 12. Adjustable Handle 7. DMX In/Out 8. Fixture Body Input Socket 13. Yoke 9. Power Switch 14. Bracket Fixing Knob WWW.NANLITE.COM...
  • Page 5 15. Lock Catch WWW.NANLITE.COM...
  • Page 6 13. Yoke: For mounting the fixture on the light stand and adjusting the direction of illumination. 14. Bracket Fixing Knob: For locking the light fixture on the stand, and for pan adjustment of fixture. 15. Lock Catch: To lock or release the reflector or other accessories. WWW.NANLITE.COM...
  • Page 7 Includes FC-300B×1 Power Supply × 1 AC Power Cable × 1 Carry Case × 1 Reflector × 1 User Manual × 1 FC-300B LED Bi-color Spot Light USER MANUAL Guangdong NanGuang Photo&Video Systems Co., Ltd. WWW.NANLITE.COM...
  • Page 8 2. Installation of Umbrella Loosen the adjustable handle. Insert the umbrella into the Tighten the adjustable handle to umbrella mount. lock the umbrella. WWW.NANLITE.COM...
  • Page 9 Remote Control FC-300B supports DMX, RDM and 2.4G remote control, and it also has built-in Bluetooth module. · ▲ The address needs to be set before operating the remote control via DMX, RDM and 2.4G. 1. ADDRESS/DMX Setting, including ADDRESS, DMX MODE, DMX REDUCED CHANNELS, DMX DIMMING CURVE and DMX SMOOTHING.
  • Page 10 CH: 512 ADDRESS DMX MODE ADDRESS DMX REDUCED CHANNELS DMX DIMMING CURVE DMX SMOOTHING SMART SMART PRESS “MENU” TO RETURN PRESS “MENU” TO RETURN Rotate the right knob to ADDRESS, and press the right knob to enter the tertiary menu. WWW.NANLITE.COM...
  • Page 11 ULTIMATE DMX 8bit DMX MODE DMX REDUCED CHANNELS DMX DIMMING CURVE DMX SMOOTHING SMART SMART PRESS “MENU” TO RETURN PRESS “MENU” TO RETURN Rotate the right knob to DMX MODE, and press the right knob to enter the tertiary menu. WWW.NANLITE.COM...
  • Page 12 ADDRESS DMX MODE DMX REDUCED CHANNELS DMX DIMMING CURVE DMX SMOOTHING SMART SMART PRESS “MENU” TO RETURN PRESS “MENU” TO RETURN Rotate the right knob to DMX REDUCED CHANNELS, and press the right knob to enter the tertiary menu. WWW.NANLITE.COM...
  • Page 13 DMX REDUCED CHANNELS LOGARITHM DMX DIMMING CURVE S CURVE DMX SMOOTHING GAMMA 2.2 PRESS “MENU” TO RETURN SMART PRESS “MENU” TO RETURN SMART Rotate the right knob to DMX DIMMING CURVE, and press the right knob to enter the tertiary menu. WWW.NANLITE.COM...
  • Page 14 CH: 512 ADDRESS DMX MODE DMX REDUCED CHANNELS DMX DIMMING CURVE DMX SMOOTHING SMART SMART PRESS “MENU” TO RETURN PRESS “MENU” TO RETURN Rotate the right knob to DMX SMOOTHING, and press the right knob to enter the tertiary menu. WWW.NANLITE.COM...
  • Page 15 The fixture can match the DMX512 (1990) control signal. 5-pin and 3-pin XLR plug/socket conversion · The fixture comes with 5-pin XLR plug/socket. lf a 3-pin XLR plug is used, please follow the instruction below. · WWW.NANLITE.COM...
  • Page 16 2.3 Address Setting of the Light Fixtutre. 2.4 Refer to the DMX reference guide and control the fixture via DMX/RDM console. (For detailed operation please refer to the DMX/RDM console operation manual.) 2.5 Download the latest technical data from https://www.nanlite.com/index#/en. WWW.NANLITE.COM...
  • Page 17 Note: The UID format of the fixture is as follow: 0008 XXXX XXXX Serial Number 0A02：FC-300B Manufacturer: Nanguang 4. WIRELESS CONTROL 4.1 FC-300B has built-in Bluetooth function for connection via Bluetooth. MENU MENU CH: 512 CH: 512 BLUETOOTH SETTINGS OUTPUT MODE 2.4G SETTINGS...
  • Page 18 Rotate the right knob to BLUETOOTH SETTINGS, and press the right knob to enter the tertiary menu. MENU MENU CH: 512 CH: 512 RESET BLUETOOTH RESET BLUETOOTH BACK RESET SMART SMART PRESS “MENU” TO RETURN PRESS “MENU” TO RETURN Press the right knob enter the interface of RESET. WWW.NANLITE.COM...
  • Page 19 PRESS “MENU” TO RETURN Rotate the right knob to RESET, and press the right knob to set. 4.2 2.4G Setting FC-300B can be remotely controlled by 2.4G remote controller and by Nanlink App via the WS-TB-1 transmitter box. ① Note: 2.4G remote controller and WS-TB-1 transmitter box are sold separately.
  • Page 20 Rotate the right knob to WIRELESS PROTOCOL, and press the right knob to enter the next menu. MENU MENU CH: 512 CH: 512 2.4G WIRELESS PROTOCOL V1.0 V2.0 PRESS “MENU” TO RETURN SMART PRESS “MENU” TO RETURN SMART Rotate the right knob to select V1.0 or V2.0, and press the right knob to set. WWW.NANLITE.COM...
  • Page 21 CH: 512 PRESS “MENU” TO RETURN SMART PRESS “MENU” TO RETURN SMART Rotate the right knob to select ON or OFF, and press the right knob to set. When WIRELESS DMX is on, the WIRELESS DMX UNIVERSE can be adjusted. WWW.NANLITE.COM...
  • Page 22 PRESS “MENU” TO RETURN SMART PRESS “MENU” TO RETURN SMART Rotate the right knob to select the needed universe, and press the right knob to set. Remote control or transmitter box can't be used when wireless DMX is on. WWW.NANLITE.COM...
  • Page 23 Operating Instructions 1. Make sure the fixture is off, connect the fixture with the power supply, and connect the power cable, turn on the power switch, the screen will display "NANLITE". Mode CCT MODE Powered by CH: 512 power supply...
  • Page 24 Note: In other modes, the DIM range is the same as that in CCT MODE. In any mode, press the left knob to turn off the light, and the DIM percentage on the screen will be 0%. Press again to restore the fixture to its previous state. Press continuously to switch the light betweeen on and off. WWW.NANLITE.COM...
  • Page 25 2700K, 3200K, 4300K, 5600K and 6500K, which can be toggled in a loop. 2.2 EFFECT Mode FC-300B has built-in effects including CCT LOOP, INT LOOP, FLASH, PULSE, STORM AUTO, STORM MANUAL, TV, PAPARAZZI, CANDLE/FIRE, BAD BULB, FIREWORK, EXPLOSION AUTO, EXPLOSION MANUAL and WELDING.
  • Page 26 EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: CCT LOOP EFFECT: CCT LOOP DIM: 100% DIM: CCT: 3200K - 5600K CCT: 3200K - 5600K SPEED: 8s SPEED: 8s SMART SMART Rotate the left knob to set the corresponding parameters. WWW.NANLITE.COM...
  • Page 27 EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: INT LOOP EFFECT: INT LOOP DIM: - 100% DIM: - 100% CCT: 5600K CCT: 5600K SPEED: 8s SPEED: 8s SMART SMART Rotate the left knob to set the corresponding parameters. WWW.NANLITE.COM...
  • Page 28 EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: FLASH EFFECT: FLASH DIM: 100% DIM: CCT: 5600K CCT: 5600K INTERVALS: 1s INTERVALS: 1s FLASH RATIO: 50% FLASH RATIO: 50% SMART SMART Rotate the left knob to set the corresponding parameters. WWW.NANLITE.COM...
  • Page 29 Rotate the right knob to select DIM, CCT or PULSES/MIN. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: PULSE EFFECT: PULSE DIM: 100% DIM: CCT: 5600K CCT: 5600K PULSES/MIN: 40 PULSES/MIN: 40 SMART SMART Rotate the left knob to set the corresponding parameters. WWW.NANLITE.COM...
  • Page 30 EFFECT MODE CH: 512 CH: 512 EFFECT: STORM AUTO EFFECT: STORM AUTO DIM: 100% DIM: CCT: 5600K CCT: 5600K INTVL RANGE: 1s - 60s INTVL RANGE: 1s - 60s SMART SMART Rotate the left knob to set the corresponding parameters. WWW.NANLITE.COM...
  • Page 31 EFFECT MODE CH: 512 CH: 512 EFFECT: STORM MANUAL EFFECT: STORM MANUAL DIM: 100% DIM: CCT: 5600K CCT: 5600K SMART SMART PRESS RIGHT KNOB TO TRIGGER PRESS RIGHT KNOB TO TRIGGER Rotate the left knob to set the corresponding parameters. WWW.NANLITE.COM...
  • Page 32 CH: 512 EFFECT: EFFECT: TV DIM: 0% - 100% DIM: - 100% CCT: 5600K CCT: 5600K CCT SHIFT: 0K CCT SHIFT: 0K SPEED: 50 SPEED: 50 SMART SMART Rotate the right knob to select DIM, CCT, CCT SHITF or SPEED. WWW.NANLITE.COM...
  • Page 33 EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: PAPARAZZI EFFECT: STORM AUTO DIM: 100% DIM: 100% CCT: 5600K CCT: 5600K SPEED: 50 SPEED: 50 SMART SMART Rotate the right knob to select DIM, CCT or SPEED. WWW.NANLITE.COM...
  • Page 34 EFFECT: CANDLE/FIRE EFFECT: CANDLE/FIRE DIM: 0% - 100% DIM: - 100% CCT: 5600K CCT: 5600K CCT SHIFT: 600 CCT SHIFT: 600 SPEED: 50 SPEED: 50 SMART SMART Rotate the right knob to select DIM, CCT, CCT SHITF or SPEED. WWW.NANLITE.COM...
  • Page 35 CH: 512 CH: 512 EFFECT: BAD BULB EFFECT: BAD BULB DIM: 100% DIM: 100% CCT: 5600K CCT: 5600K INTENSITY: 50 INTENSITY: 50 SPEED: 50 SPEED: 50 SMART SMART Rotate the right knob to select DIM, CCT, INTENSITY or SPEED. WWW.NANLITE.COM...
  • Page 36 EFFECT MODE CH: 512 CH: 512 EFFECT: FIREWORK EFFECT: FIREWORK DIM: 100% DIM: 100% CCT: 5600K CCT: 5600K SPEED: 50 SPEED: 50 DECAY: 50 DECAY: 50 SMART SMART Rotate the right knob to select DIM, CCT, G/M, SPEED or DECAY. WWW.NANLITE.COM...
  • Page 37 CH: 512 CH: 512 EFFECT: EXPLOSION AUTO EFFECT: EXPLOSION AUTO DIM: 100% DIM: 100% CCT: 5600K CCT: 5600K SPEED: 50 SPEED: 50 DECAY: 50 DECAY: 50 SMART SMART Rotate the right knob to select DIM, CCT, SPEED or DECAY. WWW.NANLITE.COM...
  • Page 38 EXPLOSION MA EFFECT: EXPLOSION MA DIM: 100% DIM: 100% CCT: 5600K CCT: 5600K DECAY: 50 DECAY: 50 SMART SMART PRESS RIGHT KNOB TO TRIGGER PRESS RIGHT KNOB TO TRIGGER Rotate the right knob to select DIM, CCT or DECAY. WWW.NANLITE.COM...
  • Page 39 PRESS RIGHT KNOB TO TRIGGER Rotate the left knob to set the corresponding parameters. EFFECT MODE CH: 512 EFFECT: EXPLOSION MA DIM: 100% CCT: 5600K DECAY: 50 SMART PRESS RIGHT KNOB TO TRIGGER Press the right knob to trigger the explosion effect. WWW.NANLITE.COM...
  • Page 40 NOTE: The PAUSE can be set on/off. When the PAUSE is on, the welding effect will pause. Lighting effects and additional functionality will be probably updated with later firmware version. Detailed information is subject to the instruction of firmware function. WWW.NANLITE.COM...
  • Page 41 Rotate the right knob to select the options, press the right knob to enter the secondary menu, and rotate the right knob to select the corresponding parameters, then press the right knob to set. Press the MENU button to return to the previous menu. MENU CH: 512 OUTPUT MODE ADDRESS/DMX WIRELESS CONTROL FAN CONTROL ROTATE SCREEN SMART MODE MENU WWW.NANLITE.COM...

  • Page 42: Table Of Contents

    PRESS “MENU” TO RETURN Rotate the right knob to select MAX OUTPUT or CONSTANT OUTPUT, and press the right knob to set. 3.2 ADDRESS/DMX For detailed operations please refer to P8. 3.3 WIRELESS CONTROL For detailed operations please refer to P16. WWW.NANLITE.COM...

  • Page 43: Output Mode

    Note: When the fan is in off state, the fan will stop working, at this moment the maximum power output of the fixture is 15%. When the fan is in LOW SPEED state, the maximum power output of the fixture is 50%. When the fan is in SMART or FULL SPEED state, the maximum power output of the fixture is 100%. WWW.NANLITE.COM...

  • Page 44: Press "Menu" To Return Smart

    Rotate the right knob to ROTATE SCREEN, and press the right knob to enter the secondary menu. MENU CH: 512 DO YOU WANT ROTATE SCREEN SMART PRESS “MENU” TO RETURN Rotate the right knob to select YES or NO, and press the right knob to set. WWW.NANLITE.COM...
  • Page 45 Rotate the right knob to SCREEN BRIGHTNESS, and press the right knob to enter the secondary menu. MENU MENU CH: 512 CH: 512 SCREEN BRIGHTNESS SMART PRESS “MENU” TO RETURN PRESS “MENU” TO RETURN SMART Rotate the right knob to select the screen brightness, and press the right knob to set. WWW.NANLITE.COM...
  • Page 46 Rotate the right knob to the LANGUAGE, and press the right knob to enter the secondary menu. MENU MENU CH: 512 CH: 512 ENGLISH 简体中文 已设置 SMART PRESS “MENU” TO RETURN SMART PRESS “MENU” TO RETURN Rotate the right knob to ENGLISH or , and press the right knob to set. 简体中文 WWW.NANLITE.COM...

  • Page 47: Menu Ch

    If all the above steps are done and the firmware file still cannot be found, please try to format the USB drive again. ⑤ If the light fixture still cannot identify the USB drive, please replace the USB drive. WWW.NANLITE.COM...
  • Page 48 SCREEN BRIGHTNESS This will take up to about 1 minute LANGUAGE FIRMWARE UPDATE RESET ALL SETTINGS SMART SMART PRESS “MENU” TO RETURN Rotate the right knob to RESET ALL SETTINGS, and press the right knob to enter the secondary menu. WWW.NANLITE.COM...
  • Page 49 firmware, and FIRMWARE UPDATE choose the FIRMWARE UPDATE RESET ALL SETTINGS option in the menu. www.nanlite.com VERSION SMART SMART PRESS “MENU” TO RETURN Rotate the right knob to VERSION, and press the right knob to check the current version.
  • Page 50 1. Please check whether the DMX address setting is correct. The fixture can be operated manually, 2. Please check whether the DMX adapter cable is connected correctly but DMX control is not working. and without damaged. The fan doesn't work. Please check if the fan is OFF. WWW.NANLITE.COM...
  • Page 51 Nanlite Website Nanlink App This manual has been compiled according to the rigorous testing for Nanlite products. Product designs are subject to change without prior notice. The latest version of the manual for this product is downloadable at www.nanlite.com. WWW.NANLITE.COM...
  • Page 52 Certification Made in China WWW.NANLITE.COM...
  • Page 53 WWW.NANLITE.COM 0754-85751187 info@nanlite.com 0754-85300887 Dongli Section, Highway 324, Chenghai, Shantou City, Guangdong Province, China...
