NANLITE FS-60B User Manual

Hide thumbs Also See for FS-60B:
Table of Contents

Advertisement

Quick Links

Download this manual
FS-60B
USER MANUAL
Guangdong NanGuang Photo&Video Systems Co., Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FS-60B and is the answer not in the manual?

Questions and answers

Related Manuals for NANLITE FS-60B

Summary of Contents for NANLITE FS-60B

  • Page 1 FS-60B USER MANUAL Guangdong NanGuang Photo&Video Systems Co., Ltd...

  • Page 2: Technical Data

    FS-60B LED Bi-color Spot Light Product Diagram Technical Data Rated Power: 70W Input voltage/current: AC100-240V 50/60Hz Color Temperature: 2700K-6500K CRI: Average 96 TLCI: Average 97...

  • Page 3: Product Details

    Product Details 8. LCD display 9. Umbrella hole 10. Lock catch 1. Lamp body handle 2. Right knob 11. Reflector 3. Left knob 4. MODE button 12. Angle fixing 5. Power socket knob 6. Power switch 13. Yoke 7. USB port 14.

  • Page 4: Detailed Description

    Detailed Description 1. Lamp body handle: Be convenient for users to lift the lamps and adjust the direction of the light. 2. Right knob: For selecting options and adjusting the color temperature under CCT mode. 3. Left knob: For adjusting the DIM and scrolling through different selections. 4.
  • Page 5 Usage 1. Installation of the Reflector ① When installing the reflector, ensure its mounting points align with the slots on the light fixture. When the mounting points and slots are aligned, push the reflector in place and rotate it in the direction shown on the light until it clicks into place.
  • Page 6 2. Installation of Bowens Mount Adapter ① ② Adjust the yoke to the top position before When installing the adapter, ensure its mounting installation. points align with the slots on the light fixture, rotate it according to the direction shown on the light until the adapter is put into place.
  • Page 7 ⑤ ⑥ When removing the accessory, push and hold the When removing the adapter, push and hold the release button and rotate according to the direction release button and rotate according to the direction shown on the adapter until the accessory is free to shown on the light until the adapter is free to be be removed from the adapter.
  • Page 8 4. 2.4G and Bluetooth Remote Control The FS-60B is able to be remotely controlled by 2.4G remote controller or by NANLINK APP via the WS-TB-1 transmitter box, and has built-in Buletooth. ① Note: 2.4G remote controller and transmitter box are sold separately.
  • Page 9 Operating Instructions 1. First ensure that the power switch of the fixture is "off ". Then connect the fixture with power supply and turn on the Iight, the screen will display all the relevant information for the fixture. CH: 512 000% 5600K 2.
  • Page 10 3. EFFECT Mode setting Press MODE button to EFFECT MODE. The FS-60B has built-in effects including CCT LOOP, INT LOOP, FLASH, PULSE, STORM, TV, PAPARAZZI, CANDLE/FIRE, BAD BULB, FIREWORK, EXPLOSION and WELDING.
  • Page 11 CCT LOOP EFFECT CH: 512 EFFECT CH: 512 CCT LOOP CCT LOOP WELDING DIM: 100% DIM: 100% Rotate "Left knob" to select the desired effect. ① CCT LOOP CCT LOOP setting: rotate "Right knob" to select from DIM, CCT and SPD (Range: 02S…30S), then rotate "Left knob"...
  • Page 12 ② INT LOOP INT LOOP setting: rotate "Right knob" to select from DIM, CCT and SPD (Range: 02S…30S), then rotate "Left knob" to adjust the value of DIM, CCT and SPD. EFFECT CH: 512 EFFECT CH: 512 INT LOOP FX: INT LOOP DIM: 000% - 100% DIM: 000% - 100% Rotate "Right knob"...
  • Page 13 EFFECT CH: 512 EFFECT CH: 512 FX: FLASH FX: FLASH DIM: 100% DIM: 099% Rotate "Left knob" to adjust the value of DIM, CCT and INTERVALS. ④ PULSE PULSE setting: rotate "Right knob" to select from DIM, CCT and PULSES/MIN (Range: 001…240), then rotate "Left knob"...
  • Page 14 ⑤ STORM STORM setting: rotate "Right knob" to select from DIM, CCT and INTVL (range: 1s ... 60s) , then rotate "Left knob" to adjust the value of DIM, CCT and INTVL. EFFECT CH: 512 EFFECT CH: 512 STORM FX: STORM DIM: 100% DIM: 100% Rotate "Right knob"...
  • Page 15 EFFECT CH: 512 EFFECT CH: 512 FX: TV FX: TV DIM: 000% - 100% DIM: 099% - 100% Rotate "Left knob" to adjust the value of DIM, CCT and SPD. ⑦ PAPARAZZI PAPARAZZI setting: rotate "Right knob" to select from DIM, CCT and SPD (Range: 001…100), then rotate "Left knob"...
  • Page 16 ⑧ CANDLE/FIRE CANDLE/FIRE setting: rotate "Right knob" to select from DIM, CCT and SPD (Range: 001…100), then rotate "Left knob" to adjust the value of DIM, CCT and SPD. EFFECT CH: 512 EFFECT CH: 512 CANDLE/FIRE FX: CANDLE/FIRE DIM: 000% - 100% DIM: 000% - 100% Rotate "Right knob"...
  • Page 17 EFFECT CH: 512 EFFECT CH: 512 FX: BAD BULB FX: BAD BULB DIM: 100% DIM: 099% Rotate "Left knob" to adjust the value of DIM, CCT and SPD. ⑩ FIREWORK RIREWORK setting: rotate "Right knob" to select from DIM ,CCT, SPD (Range: 001…100) and DECAY (Range: 001…100), then rotate "Left knob"...
  • Page 18 ⑪ EXPLOSION EXPLOSION setting: rotate "Right knob" to select from DIM, CCT, SPD (Range: 001…100) and DECAY (Range: 001…100), then rotate "Left knob" to select from DIM ,CCT, SPD and DECAY. EFFECT CH: 512 EFFECT CH: 512 EXPLOSION FX: EXPLOSION DIM: 100% DIM: 100% Rotate "Right knob"...
  • Page 19 EFFECT CH: 512 EFFECT CH: 512 FX: WELDING FX: WELDING DIM: 000% - 100% DIM: 099% - 100% Rotate "Left knob" to adjust the value of DIM, CCT, SPD and PAUSE. Special effects may be upgraded based on the firmware update. Please refer to the latest firmware function ·...

  • Page 20: Output Mode

    MENU MENU OUTPUT MODE: MAX OUTPUT MODE: MAX Rotate "Left knob" to set the channel. ② OUTPUT MODE MENU MODE OUTPUT MODE: MAX Press MODE button to MENU. MENU MENU CH: 512 OUTPUT MODE: MAX OUTPUT MODE: Rotate "Right knob" to OUTPUT MODE. MENU MENU CH: 512...

  • Page 21: Bluetooth Reset

    ③ BLUETOOTH RESET MENU MODE OUTPUT MODE: MAX Press MODE button to MENU. MENU MENU RESET OUTPUT MODE: MAX WIRELESS PR: V1.0 Rotate "Right knob" to BT. MENU BT RESET RESET BACK RESET WIRELESS PR: V1.0 Press "Right knob" to the interface of bluetooth reset. BT RESET BT RESET BACK...

  • Page 22: Wireless Protocol

    MENU BT RESET BACK RESET OUTPUT MODE: MAX Press "Right knob" to confirm the reset, and it will return to menu after bluetooth reset. ④ WIRELESS PROTOCOL Please refer to P7 for the details of wireless protocol setting. ⑤ MENU MODE OUTPUT MODE: MAX Press MODE button to MENU.

  • Page 23: Firmware Update

    MENU MENU FAN: FAN: FW UPDATE: UPDATE FW UPDATE: UPDATE Rotate "Left knob" to select ON or OFF. Note: When the fan is turned on, the maximum output of the light will be 100%. When the fan is turned off, the maximum output of the light will be 25%. ⑥...
  • Page 24 FOUND FIRMWARE FOUND FIRMWARE _V1.02.08 _V1.02.08 BACK UPDATE BACK UPDATE Rotate "Right knob" to select UPDATE. FOUND FIRMWARE FIRMWARE _V1.02.08 UPDATED BACK UPDATE Press "Right knob" to confirm the update, it will show "FIRMWARE UPDATED" after the firmware update is completed.
  • Page 25 MENU 菜单 LANGUAGE: 语言: 中文 VERSION: V0.01.06 版本: V0.01.06 Rotate "Left knob" to select Chinese or English. ⑧ VERSION MENU MODE OUTPUT MODE: MAX Press MODE button to MENU. MENU MENU LANGUAGE: ENG VERSION: V0.01.06 OUTPUT MODE: MAX Rotate "Right knob" to VERSION to check the firmware version. ⑨...

  • Page 26: Safety Precautions

    EFFECT CH: 512 EFFECT CH: 512 CCT LOOP CCT LOOP DIM: 100% DIM: 100% Long press the "Right knob" again to release the lock status. 5. When the fixture is not in use, please turn off the power switch. Safety Precautions 1.
  • Page 27 Notice 1. Please take off the COB protective cap before using. 2. Please do not look directly at the emitter when the light is on 3. Please wait 10 seconds to turn off the light fixture after any parameter setting in order to save it for future use. 4.
  • Page 28 What's in the box? Please kindly check FS-60B x 1 Power Cable 3M x 1 RF-FMM-45-S Reflector x 1 RF-FMM-45-S COB Protective Cap x 1 Bowens Mount Adapter x 1 User Manual x 1 FS-60B USER MANUAL Guangdong NanGuang Photo&Video Systems Co., Ltd...
  • Page 29 If the failure is not resolved after troubleshooting, please contact with place of purchase or manufacturer. This manual and all stats within it were produced under controlled conditions, and are accurate at time of print. Any future changes to design/technical data can be found at www.nanlite.com.
  • Page 30 Version: V1 2022-07-09 +86-754-85751187 +86-754-85300887 service@nanlite.com Zhanglin,324,Dongli Chenghai Shantou Guangdong China www.nanlite.com...
