- Page 1 ESS3124 Series Quick Start Guide V1.0.0...
-
Page 2: Foreword
Foreword General This manual introduces the functions and operations of the ESS. Models ESS3124S-JR, ESS3124D-JR Safety Instructions The following categorized signal words with defined meaning might appear in the manual. Signal Words Meaning Indicates a high potential hazard which, if not avoided, will DANGER result in death or serious injury. - Page 3 regions. For detailed information, see the paper manual, CD-ROM, QR code or our official website. If there is inconsistency between paper manual and the electronic version, the electronic version shall prevail. All the designs and software are subject to change without prior written notice. The product ...
-
Page 4: Important Safeguards And Warnings
Important Safeguards and Warnings Electrical Safety All installation and operation should conform to your local electrical safety codes. The power source shall conform to the requirement of the Safety Extra Low Voltage (SELV) standard, and supply power with rated voltage which conforms to Limited power Source requirement according to IEC60950-1. -
Page 5: Table Of Contents
Table of Contents Foreword ..............................I Important Safeguards and Warnings ....................III 1 Overview ..............................5 Introduction ........................... 5 Front panel ............................ 5 Rear Panel ............................ 6 Network Diagram .......................... 7 2 Connection ............................. 8 ESS3124S-JR ..........................8 ESS3124D-JR ..........................8 3 Operation .............................. -
Page 6: Overview
Overview Introduction The ESS can work as extended storage for network video storage devices. You can connect the ESS to the target device, and then there are more disk bays available. Front Panel ESS3124S-JR and ESS3124D-JR Table 1-1 Front panel description Name Description Turn the ESS on or off... -
Page 7: Rear Panel
Disk order Rear Panel ESS3124S-JR ESS3124D-JR Table 1-2 Rear panel description Name Description For heat dissipation. Overview 6... -
Page 8: Network Diagram
Name Description Connects to power. Power port Controller See the controller module description in Table 1-3. module Table 1-3 Controller module description Name Description When the Link light is on, it means the IN port is connected to the target device or another ESS. IN indicator When the Access light is on, it means the target device is transferring data with the disks in the ESS. -
Page 9: Connection
Connection When connecting to EVS, you need to connect the IN port on the ESS and the SAS port on the EVS. ESS3124S-JR ESS3124S-JR has one controller, and it can only connect to single controller target devices. Single controller ESS3124D-JR ESS3124D-JR has two controllers, and it can only connect to dual controller target devices. - Page 10 Dual controller Connection 9...
-
Page 11: Operation
Operation Installing Disks It is recommended to use disks with same model and capacity in one ESS. The enterprise level disks are recommended. Single controller network video storage devices support SAS disks and SATA disks. Dual controller network video storage devices support SAS disks. ... -
Page 12: Turning On And Off
Turning on and off Turning on You must turn on the ESS first, and then the target device. Connect the power cable and the eSATA cable properly, and then press the ESS power button. The RUN light on the rear panel flashes, which means the ESS is successfully turned on. Turning off You must turn off the target device first, and then the ESS. - Page 13 RAID Viewing Disk Information Log in the target device web interface, then select Storage > Physical HDD, and then select ESS at Physical Position. The information of the disks in the ESS is displayed. See Figure 3- Physical HDD Operation 12...
-
Page 14: Cybersecurity Recommendations
Cybersecurity Recommendations Cybersecurity is more than just a buzzword: it’s something that pertains to every device that is connected to the internet. IP video surveillance is not immune to cyber risks, but taking basic steps toward protecting and strengthening networks and networked appliances will make them less susceptible to attacks. - Page 15 Change Default HTTP and Other Service Ports We suggest you to change default HTTP and other service ports into any set of numbers between 1024~65535, reducing the risk of outsiders being able to guess which ports you are using. Enable HTTPS We suggest you to enable HTTPS, so that you visit Web service through a secure communication channel.
- Page 16 The network should be partitioned and isolated according to the actual network needs. If there are no communication requirements between two sub networks, it is suggested to use VLAN, network GAP and other technologies to partition the network, so as to achieve the network isolation effect.
