- Page 1 Hardware Installation Manual for PTS-10AL Economical Rack Clock Server Published: November 2023 Version: V1.0...
- Page 2 Disclaimer: Kyland Technology (Yichang) Co., Ltd. strives to make the information in this manual as accurate and up-to-date as possible. However, we cannot guarantee that this manual is completely free of any technical or clerical errors and reserve the right to modify it without notifying the user.
- Page 3 Instructions For Safe Use This product has good and reliable performance within the designed range of use, but it is necessary to avoid man-made damage or destruction to the device. Please read the manual carefully before using the device to ensure the safety of users and device. Please keep this manual properly after reading it for future reference.
- Page 4 or other metal objects to prevent electric shock or scalding. Do not operate device or connect or disconnect cables in lightning weather. Please use connectors and cables approved by our marketing personnel or technical support personnel to avoid affecting module functions due to non-compliance of connectors and cables. ...
-
Page 5: Table Of Contents
Directory 1 Product Overview ......................... 1 2 Structure And Interface ......................2 3 Dimension Figure ........................4 4 Wiring ..........................5 10/100/1000Base-T (X) Ethernet Interface ...............5 RS-232/RS-485 Interface ....................6 1000Base-X, SFP Interface .................... 7 4.3.1. Gigabit SFP Optical Module ..................7 SAT Antenna Interface .................... -
Page 6: Product Overview
Product Overview 1 Product Overview The PTS-10AL Economical Rack Clock Serveries a clocking and switching device. The board supports rack installation, and at most supports1 gigabit photoelectric multiplexing port, 4 100-megabit electrical ports, 2 BNC interfaces, 2 RS485 TOD outputs, 2 RS232 level B code outputs, 2 BNC antenna interfaces and 1 FI optical fiber interface. -
Page 7: Structure And Interface
Structure and Interface 2 Structure and Interface Device Port Figure Figure1Device Front Port Label Figure Figure2 Label Figure of Side Port of Device Table2 DevicePort Label Description Serial Description number Hanging ear External antenna BNC port SAT2 External antenna BNC port SAT1 RS485 TOD Output Interface RS232 Serial Level B Code Output Interface Device output signal BNC interface P2... - Page 8 Structure and Interface (15) 100-megabit port ETH1 (16) 100-megabit electrical port connection status indicator (17) Gigabit port rate indicator (18) Gigabit port connection status indicator (19) Gigabit port GE0 (20) Gigabit optical port GX0 (21) Console port (22) Input Power 2 (23) Input Power 1 (24)
-
Page 9: Dimension Figure
Dimension Figure 3 Dimension Figure Figure 3 Dimension Figure (Unit: mm) Note: Device casing is a part of the heat dissipation system of the whole machine. The casing will heat up when working normally. Please do not cover the casing when working. ... -
Page 10: Wiring
Wiring 4 Wiring 10/100/1000Base-T (X) Ethernet Interface 10/100/1000Base-T (X) Ethernet interface adopts standard RJ45 connector, which has adaptive function, can be automatically configured to 10M/100M/1000M state and full duplex/half duplex operation mode, and supports MDI/MDI-X self-identification function of cable, that is, it can be connected with terminal device and network device by direct network cable or cross network cable. -
Page 11: Rs-232/Rs-485 Interface
Wiring Figure 5 10/100/1000Base-T (X) RJ45 Connector Direct Wire, Cross Wire Interconnect Description: RJ45 connector wiring according to standard 568B (1-orange white, 2-orange, 3-green white, 4-blue, 5-blue white, 6-green, 7-brown white, 8-brown). RS-232/RS-485 Interface RS-232/RS-485 interface (pin definition as shown in the following figure) 6 Interface Pin Definition Figure 4 Serial Interface Pin Definition... -
Page 12: 1000Base-X, Sfp Interface
Wiring 1000Base-X, SFP Interface 100Base-X, SFP interface (i.e., Gigabit SFP interface) needs to be inserted into SFP optical/electrical module before connecting cables for communication. The Gigabit SFP optical/electrical module (optional) and Gigabit SFP to 100-megabit SFP interface (optional) recommended for this device are shown in the following table. Table 5 Recommended interface models from Gigabit SFP to 100-megabit Multimode/single... - Page 13 Wiring Gigabit SFP optical module interface adopts standard LC optical fiber connector, and each interface is divided into sending port (TX) and receiving port (RX). Device A communicates with device B by connecting TX and RX of device A to RX and TX of device B, respectively. The wiring of Gigabit SFP optical module is shown in the following figure.
-
Page 14: Sat Antenna Interface
Wiring of class 1 laser products, so when the device is powered on, do not look directly at the luminous port of sfp module, so as not to cause damage to eyes. For modules whose transmission distance needs to be greater than 60km,should not be connected with short optical fiber (less than 20km), so as to avoid light saturation and over-power burning at the receiving end of the module. -
Page 15: Optical Signal Input Interface Fi
Wiring Optical Signal Input Interface FI Figure 11 Optical Signal Input Interface FI The optical signal input interface FI of the Device receives the B code input signal Device output Signal Interface Figure 12 Device Output Signal BNC Interface Table 8 Description of BNC Interface Of Device Output Signal Code PPS/PPM/PPH/IRIG-B PPS/PPM/PPH/IRIG-B... -
Page 16: Console Port
Wiring Console Port Use the DB9-RJ45 network pipeline to connect the 9 PIN serial port of the PC to the Console of the device, or connect the DB9-RJ45, USB-DB9 network pipeline in series and then connect the USB port of the PC to the Console of the device. The Console software of the device can be called by running the Hyper Terminal of WINDOWS system or the related software tools, and the configuration, maintenance and management functions of the device can be realized. -
Page 17: Power Terminal
Wiring Figure15 Schematic Figure of Physical Objects Table9 DB9 Interface (PC Terminal 9 Pin Serial) RJ45 Interface (Console) Pin Definition DB9Interface (DB9-RJ45) RJ45Interface (Console) Signal Signal RXD (received data) TXD (send data) TXD (send data) RXD (received data) GND (Ground) GND (Ground) Power Terminal This series of device adopts 3-core 5.08 mm spacing plug-in power terminals and supports... - Page 18 Wiring Wiring and installation Step 1: Remove the power terminal plug from the device. Step 2: Insert one end of the power cord into the plug of the power terminal according to Table 10 and fix the power cord (either one of the two power supplies or the same power supply can be used).
-
Page 19: Led Indicator Status
LED Indicator Status 5 LED Indicator Status Table 11 Description of Board Indicator Light Status Describe The input power supply is connected and running normally Bright (n=1, 2) Power indicator PWRn Input power supply is not connected or not operating properly (n=1, 2) The number of stars searched by the device is not less than Bright... - Page 20 LED Indicator Status Bright 1000M operating state (i.e. 1000Base-T) 10M/100M/1000M Ethernet Interface Rate Indicator 10/100 m operation (i.e. 10/100 Base-T (X)) or no (Yellow) connection Bright Port has established a valid network connection 10M/100M/1000M Ethernet Interface Connection Status Flash Port has network activity Indicator (Link/ACT/Green) Port does not have a valid network connection...
-
Page 21: Access
Access 6 Access You can access the device in three ways. 7.1 Console Port Access Use the 9 PIN serial port connecting the DB9-RJ45 network pipeline to the PC and the Console of the device, or connect the DB9-RJ45 and USB-DB9 network pipeline together, and then connect one end to the USB serial port of the PC. - Page 22 Step 2: Enter the IP address of the device in the address bar of the browser. After opening the login dialog box, enter the default user name and default password, and you can successfully log in to the device Web management page. Table 12 IP And Login Account Password Corresponding To PTS-10AL Network Port Product type Illustrated...
-
Page 23: Basic Performance And Specifications
Basic Performance and Specifications 7 Basic Performance and Specifications Power supply Power identification Rated voltage value PTS-10AL-17511-HV-HV: 220VAC/DC (85-264VAC/100-300VDC) Input voltage PTS-10AL-17211-HV: 220VAC/DC (85-264VAC/100-300VDC) Access terminal 3-core 5.08 mm pitch plug-in terminal Rated power Rated power < 12W Mechanical structure... - Page 24 Customer Service Hotline: 010-88796676 Fax: 010-88796678 Website: http://www.Kyland.com.cn Email: services@Kyland.com.cn For more information about KYLAND products, please visit the website: http://www.Kyland.com.cn http://www.Kyland.com...
