- Page 1 PTS-30 Time Server WEB Manual Kyland Technology (Shanghai) Co., Ltd. Version Copyright...
- Page 2 Kyland Technology (Shanghai) Co., Ltd. Room 802, Building 5, No.3000 Longdong Avenue Pudong District, Shanghai, China Tel: +86-21-80321288 Fax: +86-21-80321289...
-
Page 3: Table Of Contents
Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server Contents 1. Basic Features ......................2 1.1. Introduction ....................2 2. Operations ......................... 3 2.1. Login ......................3 2.2. Logout ......................3 2.3. Languages ....................4 3. Applications ....................... 5 3.1. Status ......................5 3.1.1. -
Page 4: Basic Features
IEEE1588 works in several modes by the software configuration including grandmaster clock, slave clock and boundary clock. PTS-30 time server also has alarm contact output. PTS-30 time server provides 5.7 inch color touch screen as HMI and the visualization interface is available for work status monitoring and parameters setting. -
Page 5: Operations
Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server Operations 2.1. Login Please connect PTS time server and PC by network cable. Open any WEB Browser of PC and input http://192.168.0.111 and press enter, the login WEB screen of PTS will be shown on your screen. -
Page 6: Languages
Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server Figure 2 – Default Screen On the top right corner, system has a [Logout] option, if you want to logout system, you might directly click this and then system will go to original login screen and wait user to input login information again. -
Page 7: Applications
Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server Applications 3.1. Status The WEB management system supports to view time status by WEB. The status information can help user to easy know the current status and help them to analyze problems as soon as possible. -
Page 8: Clock Status
Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server Select different time source channel by manual and the time status of this source will be shown on this screen. For example, if you select SAT1, you might see source status, satellite number, antenna status, and source bump status and source priority. The ‘Normal’... -
Page 9: Sync Source Settings
Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server Figure 6 – Configuration Screen 3.2.1. Sync Source Settings Press ‘SYNC’ on the left navigation bar to show synchronization source setting screen. The sync source setting screen will be shown as: Figure 7 – Sync Source Setting Screen Press ‘Save’... -
Page 10: Clock Settings
Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server Items Parameters Description this parameter to make it work at right mode. According to different antenna types and Antenna Compensation lengths, system implements time delay compensation for each satellite channel. Set the priority for external signal source. 1... - Page 11 Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server Figure 8 – Clock Setting Screen Press ‘Save’ button to save the current setting when you change setting. Items Parameters Description Time Reference UTC / TAI Set UTC time or TAI time as required...
-
Page 12: Ntp Settings
Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server Items Parameters Description JAN/FEB/MAR/APR/MA Y/JUN/JUL/AUG/SEP/OC Start Month T/NOV/DEC Start Time 00:00~24:00 /Last Stop Index MON/TUE/WEN/THU Stop Weekday /FRI/SAT/SUN JAN/FEB/MAR/APR/MA Set stop date of DST. Y/JUN/JUL/AUG/SEP/OC Stop Month T/NOV/DEC Stop Time 00:00~24:00 3.2.3. - Page 13 Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server Figure 10 – PTP Setting Screen Press ‘Save’ button to save the current setting when you change setting. Items Parameters Description PTP Mode Master/Slave /Boundary Set PTP working mode. Delay Measurement Set clock delay measurement mode or...
-
Page 14: Output Settings
Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server Items Parameters Description Tx Compensation Set the time delay for sending PTP message. vLan Enable Yes / No Set whether to send vLan information. vLan Priority Set vLan priority. VLan CFI Set vLan CFI information. - Page 15 Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server Figure 12 – Output Setting Screen (SO) Items Parameters Description PPS,IRIG-B,PPM,PPH Set the signal type for serial port PPS signal. Set the signal type for serial port TxD signal. Message Format DLT1100/CM-TOD/CMBB Set the coding format for serial message.
-
Page 16: Network Settings
Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server Items Parameters Description Output Signal PPS,IRIG-B,PPM,PPH Set the output signal type for 01~05. Second Compensation Set second compensation offset. PPS Compensation Set PPS compensation offset. Set output time format which can be set to... -
Page 17: Tms Settings (Optional)
ETH0:255.255.255.0 ETH1:255.255.255.0 IP Mask Address Set ETH0/1/2/3 Subnet mask address. ETH2:255.255.255.0 ETH3:255.255.255.0 PTS-30 can provide more network type. Auto/Force One of them can set ETH0/ETH1 mode work with Auto or Force. Auto, Interface Mode PTS-30 can provide more network types. - Page 18 Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server Figure 16 – TMS Setting Screen Press ‘Save’ button to save the current setting when you change setting. Press ‘GOOSE channel’ to select GOOSE publisher and subscriber channel. The GOOSE publisher (GOOSE-P0/1) settings include the following parameters:...
- Page 19 Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server Figure 17 – TMS Publisher Screen Items Parameters Description GOOSE Publisher Enable/Disable Enable or Disable GOOSE publisher 01.0C.CD.01.00.01 Set GOOSE MAC address GOOSE GoID PTSTTR/LLN0$GO$gocb0 Set GOOSE ID GOOSE GoCBRef PTSTTR/LLN0$GO$gocb0 Set GOOSE reference...
-
Page 20: System
Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server Items Parameters Description 01.0C.CD.01.00.01 Set GOOSE MAC address GOOSE GoID PTSTTR/LLN0$GO$gocb0 Set GOOSE ID GOOSE GoCBRef PTSTTR/LLN0$GO$gocb0 Set GOOSE reference GOOSE Dataset PTSTTR/LLN0$dsGOOSE0 Set GOOSE dataset Entry 0~31 Set the entry index of GOOSE message. -
Page 21: Route
Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server Figure 20 – Gateway Screen The current routing table will be listed on the bottom of screen. Press ‘Add’ to add a new gateway for PTS time server. Press ‘Del’ to delete the selected route information. -
Page 22: Firmware
Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server file. The configuration screen will be shown as: Figure 22 – Configuration Screen Press ‘Backup’ and system will pop-up a tip window, let user to select a directory to save configuration file. The name of configuration file is named by MAC address. -
Page 23: Management
Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server Figure 24 – Firmware Screen SNMP management supports to modify agent port and to add or delete V1/V2C and V3 access parameters. The default agent port of SNMP is 161. The default access parameter of V1/V2C named ‘public’, it only has read-only permissions. -
Page 24: Reboot
Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server password screen will be shown as: Figure 26 – Change Password Screen Please ‘Save’ to confirm the new password. 3.4.2. Reboot Press ‘Reboot’ on the left navigation bar to reboot device. The reboot screen will be shown as: Figure 27 –... - Page 25 Kyland Technology (Shanghai) Co., Ltd PTS-30 Time Server Table Index Figure 1 – Login Screen ..................... 3 Figure 2 – Default Screen....................4 Figure 3 – Status Screen ....................5 Figure 4 – Source Status Screen ..................5 Figure 5 – Clock Status Screen ..................6 Figure 6 –...
