- Page 1 SCT-HDBTL522 40m for 4K & 70m for 1080P Ultra-slim HDBase-T Extender User Manual All Rights Reserved Version: SCT-HDBTL522_2024 V1.0.0...
- Page 2 4K HDBase-T Extender Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
-
Page 3: Table Of Contents
4K HDBase-T Extender Table of Contents 1. Introduction ....................2 1.1. Overview .................... 2 1.2. Features .................... 2 1.3. Package Contents ................2 1.4. Specifications..................3 1.5. Panel Descriptions ................4 1.5.1. Front Panel ................4 1.5.2. Rear Panel ................4 2. -
Page 4: Introduction
4K HDBase-T Extender 1. Introduction 1.1. Overview Thank you for purchasing this product. For proper installation and optimum performance, please read the instructions in this manual carefully. This product is a slim transmitter receiver pair, which can extend HDMI 1080P@60Hz signals up to 70m/230ft and 4K@60Hz (chroma sub-sampling 4:2:0 8-bit only) signals up to 40m/130ft via a single Cat 6A/7 cable. -
Page 5: Specifications
4K HDBase-T Extender 1.4. Specifications Video Input/Output Signal Type HDMI with 4K@60Hz 4:2:0, HDCP 2.2 Up to 4096x2160@60Hz, including Input/Output Resolution 4K@60Hz/4K@30Hz/1080P/1080i/720P Supported Note: 4096x2160/3840x2160@50/60Hz is based on chroma sub-sampling 4:2:0 8-bit only. 4K: 8/10/12 bit Deep color 1080P: up to 16 bit Maximum Data Rate 10.2 Gbps Maximum Pixel Clock... -
Page 6: Panel Descriptions
4K HDBase-T Extender 1.5. Panel Descriptions 1.5.1. Front Panel TX & RX Name Description On/Off: The device is powered on/off. Power LED On: The device is working properly. Status LED Off: The device is not working properly. On: HDCP protected content is being transmitted. Blinking: Non-HDCP protected content is being HDCP LED transmitted. - Page 7 4K HDBase-T Extender Name Description Connect to the power adapter provided. With bi-directional PoC function supported, one a & 1 DC 18V power adapter is needed to be connected to the transmitter or receiver to power both units. Connect to the receiver via a Cat 5e/6/6A/7 HDBT OUT cable.
-
Page 8: Wiring
4K HDBase-T Extender 2. Wiring Blu-ray Player TV remote IR Receiver 1 IR Emitter 2 HDMI IN Transmitter HDBT Receiver IR Receiver 2 IR Emitter 1 HDMI OUT Blu-ray Player remote Note: Connect the broadband IR receiver to IR IN and the IR emitter to IR OUT. -
Page 9: Rs232 Operation
4K HDBase-T Extender 3. RS232 Operation RS232 ports can be used for bi-directional RS232 signal pass-through between the transmitter and receiver. RS232 Device RS232 Cable Transmitter HDBT Receiver RS232 Cable RS232 Device... -
Page 10: Troubleshooting
4K HDBase-T Extender 4. Troubleshooting No Power Ensure the power is on. Ensure you use the power adapter provided in the package. No Picture or Video Flash Ensure all devices are on, and all cables are qualified and connected ... -
Page 11: Customer Service
4K HDBase-T Extender 5. Customer Service The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. 5.1. Warranty The limited warranty period of the product is fixed three years. 5.2. - Page 12 4K HDBase-T Extender syscomtec Distribution AG Raiffeisenallee 8 D-82041 Oberhaching (bei München) Tel.: +49 89 666 109 330 Email: post@syscomtec.com https://www.syscomtec.com...
