- Page 1 SCT-USB34-C100 USB3.2/ 2/ 1 Extender/ two way PoH+ User Manual All Rights Reserved Version: SCT-USB34-C100_2024 V1.0.1...
- Page 2 USB3.2/ 2/ 1 Extender/ two way PoH+ Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
-
Page 3: Table Of Contents
USB3.2/ 2/ 1 Extender/ two way PoH+ Table of Contents Introduction ..................... 2 1.1. Overview ..................2 1.2. Features ..................2 1.3. Package Contents................3 1.4. Specifications .................. 3 1.5. Panel Descriptions ................4 1.5.1. Transmitter ................4 1.5.2. Receiver ................. 5 Installation and Wiring ................ -
Page 4: Introduction
USB3.2/ 2/ 1 Extender/ two way PoH+ 1. Introduction 1.1. Overview This product is a new generation of USB 3.2 & USB 3.0 extender. It supports USB 3.2 Gen 1 standard with up to 5Gbit/s USB data transmission rate, and is backward compatible with USB 3.0, USB 2.0 and USB1.1 specifications. -
Page 5: Package Contents
USB3.2/ 2/ 1 Extender/ two way PoH+ Supports RS232 and FSYNC GPIO pass-through for industrial camera control. Plug and play, no driver is required, and compatible with multiple operating systems. Support firmware upgrading via micro-USB port. Built-in PoH + module, only one power adapter is needed to be connected ... -
Page 6: Panel Descriptions
USB3.2/ 2/ 1 Extender/ two way PoH+ General Power Supply 20V/3A Power Consumption (Max) 31.28W (Pair, USB fully loaded) Device Dimension Transmitter/Receiver: 150mm x 20.5mm x 100mm / (W x H x D) 5.9” x 0.81” x 3.94” Transmitter: 0.35kg/0.77lb Product Weight Receiver: 0.34kg/0.75lb Transmission Distance... -
Page 7: Receiver
USB3.2/ 2/ 1 Extender/ two way PoH+ Name Description Connect to the power adapter provided. With two-way PoH+, one power adapter is needed to be connected to the transmitter or receiver to power both units. On: The device is powered on. POWER LED Off: The device is powered off. -
Page 8: Installation And Wiring
USB3.2/ 2/ 1 Extender/ two way PoH+ Name Description Connect to the power adapter provided. With two-way PoH+, one power adapter is needed to be connected to the transmitter or receiver to power both units. On: The device is powered on. POWER LED Off: The device is powered off. -
Page 9: Wiring
USB3.2/ 2/ 1 Extender/ two way PoH+ Repeat the steps from 1 to 2 for the other side of the unit. Attach the brackets to the surface you want to hold the unit against using the screws (provided by others). Repeat the steps from 1 to 4 to install the receiver. -
Page 10: Rs232 & Fsync
USB3.2/ 2/ 1 Extender/ two way PoH+ 3. RS232 & FSYNC The transmitter and receiver feature a RS232 & FSYNC (IN) port and a RS232 & FSYNC (OUT) port respectively, which are used for industrial camera control. RS232 & FSYNC (IN): FSYNC (IN), GPIO digital in port, supports 3.3V ... -
Page 11: Customer Service
USB3.2/ 2/ 1 Extender/ two way PoH+ 4. Customer Service The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. 4.1. Warranty The limited warranty period of the product is fixed three years. - Page 12 USB3.2/ 2/ 1 Extender/ two way PoH+ syscomtec Distribution AG Raiffeisenallee 8 D-82041 Oberhaching (bei München) Tel.: +49 89 666 109 330 Email: post@syscomtec.com https://www.syscomtec.com...
