10) Caring For Your Outdoor Speakers
The two most common ways that outdoor speakers are permanently damaged:
1) Not enough power at higher volumes.
2) Too much power at higher volumes.
Contrary to conventional wisdom, far more speakers are damaged as a result of under-powering,
than by overpowering. When a receiver runs out of power, it still tries to reproduce the musical
signal by "clipping" the waveform. At high volume levels this clipping introduces extreme amounts
of distortion energy to the speaker, eventually destroying it. If the sound from your speakers starts
to sound distorted, turn down the volume.
Having plenty of reserve power will help your speakers reproduce dynamic contrasts and quick
transients of music much more effectively, but use good judgment; too much power will also perma-
nently damage a speaker. Again, if you hear distortion or audible distress, turn the volume down.
Outdoor speakers are designed to withstand outdoor environments, including incidental exposure
to water. They are not designed to be washed using a pressure washer or hose nozzle. If debris
accumulates on the housing of the speaker, use a damp sponge or cloth to remove it.
Model number IO525B/W
Description Indoor/Outdoor Speaker
Woofer 5.25" Mineral-Filled Poly
Tweeter 1" Metallized Mylar Dome 1" Metallized Mylar Dome 1" Metallized Mylar Dome 1" Metallized Mylar Dome
Frequency Response 55-20,000 Hz
Impedance 8
70V Taps No Transformer
Power Handling (RMS/Peak)
40W / 75W
SPL 1W/1m 85 dB
Dimensions HxWxD 9.5" x 6.75" x 7.25"
Color B = Black
W = White
Weight 5.2 lb / 2.4 kg
Warranty Information
Dayton Audio products are constructed by industry experts, and are thoroughly tested before shipment.
®
Dayton Audio products are warranted for the period of one year. This warranty is limited to manufacturer
defects, either in materials or workmanship. Dayton Audio is not responsible for any consequential on incon-
sequential damage to any other unit or component or the cost for installation or extraction of any component
of the audio system. In the rare case of a product failure, please contact your place of purchase or call our
Customer Support Department at (937) 743-8248.
Warranty Limitations
There are no other warranties, either express or implied, which extend the foregoing, and there are no warranties
of merchantability or fitness for any particular purpose. The warranty will not cover incidental or consequential
damage due to defective or improper use of products.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
Non-Warranty Service: If non-warranty service is required, the product may be sent to the Company for repair/
replacement, transportation prepaid, by calling (937) 743-8248 for details, complete instructions, and service
fee charges.
Designed and Engineered in USA
P.O. Box 52 • Springboro, OH • 45066-052 • Phone: (937) 743-8248
Specifications
IO525BT/WT IO655B/W
Indoor/Outdoor Speaker Indoor/Outdoor Speaker Indoor/Outdoor Speaker
5.25" Mineral-Filled Poly 6.5" Mineral-Filled Poly 6.5" Mineral-Filled Poly
55-20,000 Hz 45-20,000 Hz
8 Ohms or 70V 8
4W, 8W, 16W, 30W No Transformer
40W / 75W 50W / 85W
85 dB 87 dB
9.5" x 6.75" x 7.25" 11" x 8.25" x 8.75"
BT = Black B = Black
WT = White W = White
5.9 lb / 2.7 kg 6.7 lb / 3.0 kg
daytonaudio.com
© Dayton Audio ® Last Revised: 10/11/2012
2-Way Indoor/Outdoor
IO655BT/WT
45-20,000 Hz
8 Ohms or 70V
4W, 8W, 16W, 30W
50W / 85W
87 dB
11" x 8.25" x 8.75"
BT = Black
WT = White
7.2 lb / 3.3 kg
Speaker Pair
Models: IO525B/W/BT/WT
IO655B/W/BT/WT
User Manual
daytonaudio.com
Designed and Engineered in USA
