- Page 1 User’s Manual – A S Air Compressor 50 L REBO Air Compressor 50 L AR-HE-LK150050S Please follow all security measures in this user´s manual to ensure a secure use. Thank you for trusting in AREBOS.
-
Page 2: Table Of Contents
User’s Manual – A S Air Compressor 50 L REBO List of contents 1. Safety instructions ............3 1.1 Icon description ..................3 1.2 General safety instructions ................ 4 1.3 Safety instructions for working with compressed air and blow guns ..5 1.4 Safety instructions for paint spraying ............ -
Page 3: Safety Instructions
User’s Manual – A S Air Compressor 50 L REBO Please read and save these instructions. Read through this user’s manual carefully before using product. Protect yourself and others by observing all safety information, warnings and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property. -
Page 4: General Safety Instructions
User’s Manual – A S Air Compressor 50 L REBO The compressor must always stand straight. The compressor must not be placed on an incline. The guaranteed sound power level is 97 dB(A). 1.2 General safety instructions • Keep your work area in order. - Clutter in the work area can result in accidents. -
Page 5: Safety Instructions For Working With Compressed Air And Blow Guns
User’s Manual – A S Air Compressor 50 L REBO • Do not misuse the cable or the hose! - Do not use the power cord to unplug the power cord from the wall outlet. Protect the cable from heat, oil and sharp edges. •... -
Page 6: Safety Instructions For Paint Spraying
User’s Manual – A S Air Compressor 50 L REBO persons or animals. - Do not use the compressed air jet to clean clothing on the body. - Do not insert hands or objects through the protectice grid of the compressor. - Keep children and animals away from the working area of the compressor. - Page 7 User’s Manual – A S Air Compressor 50 L REBO an unsuitable ambient temperature, or in a room containing dusts, acids, vapors, or flammable gases, there is a risk of explosion. - The compressor must not be operated or stored in a room containing dusts, acids, vapors or flammable gases.
-
Page 8: Operation Of Pressure Vessels
User’s Manual – A S Air Compressor 50 L REBO 1.6 Operation of pressure vessels • Anyone who operates a pressure vessel shall maintain it in a proper condition, operate it properly, monitor it, carry out any necessary maintenance and repair work immediately and take the necessary safety measures according to the circumstances. - Page 9 User’s Manual – A S Air Compressor 50 L REBO...
- Page 10 User’s Manual – A S Air Compressor 50 L REBO 1. Drain valve for condensation water 2. Pressure tank 3. Wheel with axle bolt 4. Stand 5. Quick coupling (regulated compressed air) with Y connection 6. Pressure gauge (set pressure can be read) 7.
-
Page 11: Intended Use
User’s Manual – A S Air Compressor 50 L REBO 12. Blower adapter 2 parts (12a/12b) 13. Adapter set 5 parts (13a-13e) 14. Wire helix hose 15. Filling hose (adapter for car valves) 16. Safety valve 17. Blow-out pistole 18. Nozzles 3 parts A Locknut B Screw C Washer... -
Page 12: Exploded View
User’s Manual – A S Air Compressor 50 L REBO 4. Exploded view... - Page 13 User’s Manual – A S Air Compressor 50 L REBO Number Description Number Description Quick coupling with Y Screw connection Pressure Regulator Crankshaft Pressure Gauge Bearing Elbow Safety Valve Screw Motor Cover 1 Set Cover 1 Set Circlip Cover guard Washer Hose Washer...
-
Page 14: Technical Specifications
User’s Manual – A S Air Compressor 50 L REBO 5. Technical specifications Model AR-HE-LK150050S Compressor Power 1500 W Volume 50 L Voltage 230 Va.c. Frequency 50 Hz Idle speed 4000 rpm Theo. suction capacity ca. 220 L/min Protection type... -
Page 15: Assembly And Operation
User’s Manual – A S Air Compressor 50 L REBO Adapter (13 a) Material Cooper Thread (external) 5/16"; Length: 45 mm Adapter (13 b) Material Cooper Thread (external) Ø7.8; Length: 30 mm Adapter (13 c) Material Rubber Thread (external) Ø7.8; Length: 44.5 mm Adapter (13 d) Material Rubber... - Page 16 User’s Manual – A S Air Compressor 50 L REBO Mounting the stand • The enclosed feet must be mounted as shown in Fig. 4. Assembly of the wheels • The enclosed wheels must be mounted as shown in Fig. 5 and Fig. 6. Assembly of the Y-quick coupling •...
- Page 17 User’s Manual – A S Air Compressor 50 L REBO Application: • The tire inflator allows a simple and accurate filling of tires. The pressure gauge is used to control the tire pressure. With the integrated drain valve (e) it is possible to lower too high tire pressure.
- Page 18 User’s Manual – A S Air Compressor 50 L REBO Valve adapter (item 13e) • Application: Fits valves of bicycle tires. • This valve adapter allows easy filling of bicycle tires Instructions for the 3 parts adapter set (Fig. 3b) Adapter 1 (Pos 18) •...
-
Page 19: Cleaning And Maintenanace
User’s Manual – A S Air Compressor 50 L REBO Adapter 3 (Pos 18) • Application: For exhaust valves. • An exhaust valve can be found along with other valves (standard valve, screw valve, ...) on many large volume items. Behavior in emergency situations 1. -
Page 20: Clean The Compressor
User’s Manual – A S Air Compressor 50 L REBO - Do not use a high-pressure cleaner to clean the compressor. - Make sure that no water or other liquids get into the housing. - Disconnect compressed air hose and tools from the compressor before cleaning. 7.2 Clean the compressor 1. -
Page 21: Exchange Mains Connection Cable
User’s Manual – A S Air Compressor 50 L REBO 7.5 Exchange mains connection cable • Risk of electric shock! If the power cord is damaged or improperly installed, there is a risk of electric shock. - The mains connection cable may only be replaced by a qualified specialist to avoid hazards. 7.6 Carbon brushes •... -
Page 22: Troubleshooting
User’s Manual – A S Air Compressor 50 L REBO 1. Disconnect the power plug from the socket. 2. Allow the compressor to cool completely. 3. Vent the compressor via the connected compressed air tool. 4. Clean the compressor and remove the condensation as described in the chapter "Cleaning and maintenance". -
Page 23: Disposal Instruction
User’s Manual – A S Air Compressor 50 L REBO 9. Disposal instruction 9.1 Disposal of the packaging • Please make reference to the guidelines and standards for appropriate disposal of the packaging valid in your region. In part, the package may consist of plastic bags - watch this respect, with special care to ensure that this is not out of the reach of children. - Page 24 Authorised representative for the technical documentation: Korhan Canbolat Office address: Canbolat Vertriebs GmbH Gneisenaustraße 10-11 D-97074 Würzburg Return address can be found in the imprint: https://www.arebos.de/impressum/ VAT identification number: DE 263752326 Court of the Commercial Register is Würzburg, HRB 10082 WEEE Reg.-No. DE 61617071...
