- Page 1 User’s manual – A S Air compressor 1100W 24 L REBO Air compressor 1100W 24 L AR-HE-LK110024OF Please follow all security measures in this user’s manual to ensure a secure use. Thank you for trusting in AREBOS.
-
Page 2: Table Of Contents
User’s manual – A S Air compressor 1100W 24 L REBO Content 1. Safety instructions ..........3 1.1 Explanation of the symbols ..........3 1.2 General safety instructions ..........4 1.3 Additional safety instructions ......... 5 1.4 Safety information for paint spraying ......6 1.5 Operating pressure vessels .......... -
Page 3: Safety Instructions
User’s manual – A S Air compressor 1100W 24 L REBO Please read and safe these instructions. Read through this user’s manual carefully before using this product. Protect yourself and others by observing all safety information, warnings and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property. -
Page 4: General Safety Instructions
User’s manual – A S Air compressor 1100W 24 L REBO Warning! The unit is equipped with an automatic start control. Keep others away from the work area of the device! The guaranteed sound power level is 96 dB. 1.2 General safety instructions •... -
Page 5: Additional Safety Instructions
User’s manual – A S Air compressor 1100W 24 L REBO • Remain attentive. Pay attention to what you are doing. Remain sensible when working. Do not use the electric tool when you are distracted. • Check the electric tool for potential damage. Protective devices and other parts must be carefully inspected to ensure that they are fault-free and function as intended prior to continued use of the electric tool. -
Page 6: Safety Information For Paint Spraying
User’s manual – A S Air compressor 1100W 24 L REBO 1.4 Safety information for paint spraying • Do not process any paints or solvents with a flash point below 55° C. There is a risk of explosion! • Do not heat up paints or solvents. There is a risk of explosion! •... -
Page 7: Technical Details
User’s manual – A S Air compressor 1100W 24 L REBO 2. Technical Details Model AR-HE-LK110024OF Intake capacity 165 L/min Sound power level (LWA) 96 dB(A) 220 – 24 V, 50 Hz Frequency Gross Weight 21 kg Recording power P1... - Page 8 User’s manual – A S Air compressor 1100W 24 L REBO Number Part name Transport handle Pressure switch Pressure regulator Quick-lock coupling Pressure gauge (for reading the preset vessel pressure) Pressure gauge (for reading the vessel pressure) Pressure vessel Supporting foot Drain plug for condensation water Wheel hub bolt Wheel...
- Page 9 User’s manual – A S Air compressor 1100W 24 L REBO Number Part name Supporting foot Washer Locking ring Fixing nut Mounting screw Wheel hub bolt Wheel...
- Page 10 User’s manual – A S Air compressor 1100W 24 L REBO...
-
Page 11: Before Starting The Equipment
User’s manual – A S Air compressor 1100W 24 L REBO 4. Before starting the equipment • Before you connect the equipment to the mains supply make sure that the data on the rating plate are identical to the mains data. •... -
Page 12: Electrical Connection
User’s manual – A S Air compressor 1100W 24 L REBO 6. Electrical connection • The electrical motor installed is connected and ready for operation. The connection complies with the applicable VDE and DIN provisions. The customer’s mains connection as well as the extension cable used must also comply with these regulations. -
Page 13: Maintenance Work On The Pressure Vessel
User’s manual – A S Air compressor 1100W 24 L REBO 7.2 Maintenance work on the pressure vessel • Important! To ensure a long service life of the pressure vessel (7), drain off the condensed water by opening the drain valve (9) each time after using. •... -
Page 14: Troubleshooting
User’s manual – A S Air compressor 1100W 24 L REBO 8. Troubleshooting Fault Possible cause Remedy The compressor does not start. - No supply voltage. - Check the supply voltage, the power plug and the socket- - Insufficient supply voltage. outlet. -
Page 15: Disposal Instruction
User’s manual – A S Air compressor 1100W 24 L REBO 9.Disposal instruction 9.1 Disposal of the packaging • Please make reference to the guidelines and standards for appropriate disposal of the packaging valid in your region. In part, the package may consist of plastic bags – watch this respect, with special care to ensure that this is not out of the reach of children. - Page 16 Dipl.-Inform. (Univ.) Korhan Canbolat, Managing Director Office address: Canbolat Vertriebs GmbH Gneisenaustraße 10-11 97074 Würzburg You can find the return address in the imprint: https://www.arebos.de/impressum/ VAT identification number: DE 263752326 The court of entry in the commercial register is Würzburg, HRB 10082 WEEE-Reg.-Nr. DE 61617071...
