Disassembly Procedure
ASUS Laptop X415DA_DAP_EA_EP
Repair Manual
Service Overview
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X415DA and is the answer not in the manual?

Questions and answers

Related Manuals for Asus X415DA

Summary of Contents for Asus X415DA

  • Page 1 Disassembly Procedure ASUS Laptop X415DA_DAP_EA_EP Repair Manual Service Overview...
  • Page 2 Disassembly Procedure Pre-Repair Check List...
  • Page 3 Disassembly Procedure Precautions Before you perform any service or repair on the notebook, please follow the steps below first. 1. Be sure that the notebook is powered down. 2. Before disassembling any part, please disconnect all power source. ex: AC plug/Battery connector/Power protect screw etc.
  • Page 4 Disassembly Procedure d. Damaged head – unable to drive in. e. Damaged unable to securely tighten. 10. The following chapter includes all part numbers mentioned in service guide are used for reference only, actual part name depends on different SKU, if you need the exact part number for ordering please refer to the orderbook.
  • Page 5 Disassembly Procedure Appropriate Tools The illustrations below show the appropriate tools that should be used for the notebook’s service and repair. ➢ Cross Screwdriver Please accord to different screw specification to choose different screwdriver and head. Below photos are for reference only. Use a cross screwdriver to fasten/remove screws.
  • Page 6 Disassembly Procedure ➢ Thickness gauge Thickness compass specification 0.05mm-1.5mm. Use it to measure the gap.
  • Page 7 Disassembly Procedure Bottom Case Module The illustrations below show how to remove the Bottom Case Module. Notice: After disassembling bottom case, if you want to replace any part, please be sure to disconnect the battery connector more than ten seconds to avoid damaging any part. Remove 10 screws on the bottom case.
  • Page 8 Disassembly Procedure Pull out battery cable. NOTICE: Please follow below steps to disconnect battery connector. Snaps as below Parts: ⚫ Total screw * 10 ⚫ BOTTOM CASE ASSY *1 ⚫ (Actual part name depends on different SKU.)

  • Page 9: Hdd Module

    Disassembly Procedure HDD Module The illustrations below show how to remove the HDD Module. Disconnect the HDD FFC from the Motherboard and remove the HDD . Assembly notice: Insert FFC to the bottom until just accord with the line when lock the latch. Remove the Rubber.
  • Page 10 Disassembly Procedure Parts: ⚫ Total screw * 0 ⚫ HDD SATA3 2.5' 1TB5//SEAGATE *1 ⚫ HDD FFC 10P 0.5,L109.6//XINYA/X18BA1-6771-CV-HF*1 ⚫ HDD RUBBER 3M//3M*1 ⚫ HDD AL MYLAR//滕藝*1 ⚫ (Actual part name depends on different SKU.)

  • Page 11: Battery Module

    Disassembly Procedure Battery Module The illustrations below show how to remove the Battery Module. Follow below numbers to remove 3 screws on the battery module and take out the battery. Assembly Notice: Follow the reverse numbers to lock screws. Screw tightening torque (Kg F-cm): 2.0KG±0.2kgf. 2.

  • Page 12: Speaker Module

    Disassembly Procedure Speaker Module The illustrations below show how to remove the Speaker Module. 1. Disconnect the Antenna & Speaker Cable . 2. Remove the speaker. Assembly Notice: Please well arrange the speaker cables and put it in the hook slot as below. Parts: ⚫...

  • Page 13: Ssd Module

    Disassembly Procedure SSD Module The illustrations below show how to remove the SSD Module. 1. Tear off the SSD Tape. The SSD Tape should be stuck well when you assemble the SSD. 2. Remove 1 screw and take out the SSD . Screw tightening torque (Kg F-cm): 2.0KG±0.2kg SCREW M2*3L D4.5 (K) W-NI NY Parts:...

  • Page 14: Memory Module

    Disassembly Procedure Memory Module The illustrations below show how to remove the Memory Module. 1. Tear off the DIMM Acid type. 2. Pull two latches here to pop the Memory module up at 45 angles, and then pull out the module at that angle.

  • Page 15: Thermal & Fan Module

    Disassembly Procedure Thermal & Fan Module The illustrations below show how to remove the Thermal & Fan Module. 1. Disconnect the antenna fan cable from mainboard. Notice: Please well arrange the antenna when you assemble it. 2. Remove 9 or 7 screws on the Thermal & FAN Module. Assembly Notice: follow the reverse numbers to lock screws.
  • Page 16 Disassembly Procedure For X415JA Thermal SCREW M2*5L (K) B-ZN,NY SCREW M2*3L D4.5 (K) W-NI NY 3. Disconnect Thermal and Fan Module.
  • Page 17 Disassembly Procedure Please refer to Repair Notice RN201907120_1 SOP for thermal material rework when you re-assemble thermal module. For X415JP &JF Thermal For X415JA Thermal ⚫ Please use the correct technique of taking fans in order to avoid being out of shape. Correct demonstration Wrong demonstration...
  • Page 18 Disassembly Procedure Parts: ⚫ Total screw * 9 or 7 ⚫ THM FAN *1 ⚫ THM MOD ASSY//AURAS*1 ⚫ (Actual part name depends on different SKU.)

  • Page 19: Wlan Module

    Disassembly Procedure WLAN Module The illustrations below show how to remove the WLAN Module. Remove 1 screw and take out the WLAN. Screw tightening torque: 2.0KG±0.2kgf SCREW M2*3L D4.5 (K) W-NI NY Notice: Please choose the J2 connector to connect with antenna if it is only single antenna for WLAN Card. Parts: ⚫...

  • Page 20: Touchpad Module

    Disassembly Procedure Touchpad Module The illustrations below show how to remove the Touchpad Module. 1. Disconnect the TP FFC . Insert FFC to the bottom until just accord with the line when lock the latch. Disconnect the FP FFC (Optional by SKU) 2.
  • Page 21 Disassembly Procedure 3. Remove 3 screws on Touch Pad and take out it. Assembly Notice: follow the reverse numbers to lock screws. Screw tightening torque (Kg F-cm): 1.8KG±0.2kgf. SCREW M2*2L D7.0 (K) B-ZN #1 Assembly notice: Please change new one, If FFC is damage during disassembly. Here are some samples of FFC damage:...
  • Page 22 Disassembly Procedure Parts: ⚫ Total screw * 3 ⚫ TP FFC 8P 0.5,L152.5 *1 ⚫ TOUCHPAD *1 ⚫ (Actual part name depends on different SKU.)
  • Page 23 Disassembly Procedure IO Board Module The illustrations below show how to remove the IO Board Module. 1. Disconnect the FFC. Assembly notice: Insert FFC to the bottom until just accord with the line when lock the latch. Remove 4 screws and take out the IO Board. Assembly Notice: follow the reverse numbers to lock screws.
  • Page 24 Disassembly Procedure Assembly notice: Please change new one, If FFC is damage during disassembly. Here are some samples of FFC damage: Parts: ⚫ Total screw * 4 ⚫ IO FFC *1 ⚫ IO_BD.//R2.0*1 ⚫ (Actual part name depends on different SKU.)
  • Page 25 Disassembly Procedure Motherboard Module The illustrations below show how to remove the Motherboard Module. 1. Disconnect EDP Cable Keyboard Cable. Assembly Notice: Please well arrange the EDP Cable. 2. Remove 5 screws on the Mainboard. Assembly Notice: follow the reverse numbers to lock screws. Screw tightening torque: 2.5KG±0.2kgf Screw tightening torque: 2.0KG±0.2kgf...
  • Page 26 Disassembly Procedure M2.5*5.5L(4.5,0.8) (K) SCREW M2*4L D4.6 (K) W-NI NY Notice: Please insert the screw into the loop to lock it. Parts: ⚫ Total screw * 5 ⚫ MAIN_BD *1 ⚫ (Actual part name depends on different SKU.)
  • Page 27 Disassembly Procedure Notice: These pictures for your reference for mylar/gasket/sponge etc. of MB. 1. X530UN TP GASKET TAPE （Just for X415JP X415JF） 2. X415JA MB MYLAR 3. X415EA MB DIM MYLAR...

  • Page 28: Keyboard Module

    Disassembly Procedure Keyboard Module The illustrations below show how to remove the Keyboard Module. Follow the direction of the arrows to rotate the hinges, take out the Keyboard. . Parts: ⚫ Total screw * 0 ⚫ Keyboard Module*1 ⚫ (Actual part name depends on different SKU.)

  • Page 29: Lcd Module

    Disassembly Procedure LCD Module The illustrations below show how to remove the LCD Module. 1. Remove 2 screw mylars. 2. Remove 2 screws on the Bezel. Screw tightening torque: 1.85KG±0.15kgf...
  • Page 30 Disassembly Procedure SCREW M2.5*3.5L (4.5,0.5)(K)#1 3. Use plastic blade to pry up the edge , take the LCD front bezel out . Notice: Use the thinner plastic blade to pry up the edge . The plastic blade thickness : Please refer to the Gap Step of LCD Bezel to Panel on the last page.
  • Page 31 Disassembly Procedure Tips : Usually, it is hard to pry up the inside edge follow below position directly. inside outside First, Use the thinner plastic blade to pry up the red frame area of outside edge. Second, insert the thinner plastic blade into the gap and do not push too hard, disconnect the hooks follow the direction of the red arrow slowly.
  • Page 32 Disassembly Procedure ⚫ Assembly Notice: Please follow the pic below to paste new BEZEL SPONGE *1pc and then paste new ADHESIVE *2pcs. Notice: The ADHESIVE is pasted on the ground side SPONGE, aligned with the central slider line of the mold in the X direction, and pasted from the inside to the outside. The double-sided adhesive shall not exceed the SPONGE.
  • Page 33 Disassembly Procedure SCREW M2.5*3L (K) W-NI NY Notice: If you need to replace hinges (hinge covers), please make sure hinge (hinge cover) R and hinge (hinge cover) L are the same vendor . 5. Remove 2 screws on the bracket. Screw tightening torque (Kg F-cm): 2.0KG±0.2kgf.
  • Page 34 Disassembly Procedure If you change a new panel, please follow below steps:...
  • Page 35 Disassembly Procedure ⚫ Assembly Notice: Insert the left LCD Bracket into the left LCD Cover slot by pressuring, then lock the screw(M2*2.5). hook hook hook Insert the right LCD Bracket into the right LCD Cover slot by pressuring, then lock the screw(M2*2.5). hook hook hook...
  • Page 36 Disassembly Procedure Connect the EDP Cable. Rotate the LCD Panel and insert it into LCD Bracket carefully.
  • Page 37 Disassembly Procedure 8. Disconnect the camera cable and take out it. 9. Tear off the foil and take out the Antenna Cable . Assembly Notice: Please well arrange the cable and put it in the hook slot as below. 10. Take out the EDP Cable . Assembly Notice: Please well arrange the cable and put it in the hook slot as below.
  • Page 38 Disassembly Procedure EDP & Antenna Cable Assembly Notice: Please well arrange the EDP & Antenna Cable and put them in the hook slot as below. The cable path is shown in the blue dotted line. The cable should be in the hook as red box .
  • Page 39 Disassembly Procedure Snaps as below Parts: ⚫ Total screw * 10 ⚫ LCD panel *1 ⚫ EDP CABLE*1 ⚫ LCD HINGE L *1 ⚫ LCD HINGE R *1 ⚫ LCD BKT ASSY L *1 ⚫ LCD BKT ASSY R *1 ⚫...
