- Page 1 SmartCD.MP Manual 05.03.2024...
-
Page 2: Table Of Contents
Contents SmartCD.MP (Manual) 2 / 17 Contents Intended use.............................. 3 General safety instructions ........................ 4 Product-specific safety instructions .................... 6 Scope of delivery ............................ 7 Connection to PC, Laptop or Touchbook................... 8 Initial operation ............................ 9 Programming ............................ 10 Programming with a PC/Laptop ...................... 10 Programming with netbook/touchbook .................... -
Page 3: Intended Use
1. Intended use SmartCD.MP (Manual) 3 / 17 1. Intended use The SimonsVoss Mifare® Pure SmartCard products can be programmed with the SmartCD.MP. This includes the following variants: SmartCards resp. SmartTags SC cylinder (.MP) SmartHandle-SC (.MP) SmartRelais-SC (.MP) ... -
Page 4: General Safety Instructions
2. General safety instructions SmartCD.MP (Manual) 4 / 17 2. General safety instructions Signal word: Possible immediate effects of non-compliance WARNING: Death or serious injury (possible, but unlikely) IMPORTANT: Property damage or malfunction NOTE: Low or none WARNING Blocked access Access through a door may stay blocked due to incorrectly fitted and/or in- correctly programmed components. - Page 5 2. General safety instructions SmartCD.MP (Manual) 5 / 17 NOTE Intended use SimonsVoss-products are designed exclusively for opening and closing doors and similar objects. Do not use SimonsVoss products for any other purposes. Qualifications required The installation and commissioning requires specialized knowledge. Only trained personnel may install and commission the product.
-
Page 6: Product-Specific Safety Instructions
3. Product-specific safety instructions SmartCD.MP (Manual) 6 / 17 3. Product-specific safety instructions NOTE USB power supply The SmartCD.MP is supplied with power via USB. Other power supplies are not permitted. Drivers from LSM 3.3 included The drivers required for the SmartCD.MP are included from LSM 3.3 onwards. Make sure that LSM 3.3 or newer is installed. -
Page 7: Scope Of Delivery
4. Scope of delivery SmartCD.MP (Manual) 7 / 17 4. Scope of delivery 1. SmartCD.MP 2. USB cable for connection to a USB port 3. Instruction leaflet... -
Page 8: Connection To Pc, Laptop Or Touchbook
5. Connection to PC, Laptop or Touch- book SmartCD.MP (Manual) 8 / 17 5. Connection to PC, Laptop or Touchbook SmartCD.MP can be directly connected to a free USB port (USB 1.1, USB 2.0 or USB 3.0) on a PC or laptop, or on a netbook or Touch Book in the case of mobile programming, using the supplied cable. -
Page 9: Initial Operation
6. Initial operation SmartCD.MP (Manual) 9 / 17 6. Initial operation After you have connected SmartCD.MP to a PC or laptop using the USB cable, the new USB hardware is detected by the Windows operating system. The drivers are installed together with the LSM software automatically. -
Page 10: Programming
7. Programming SmartCD.MP (Manual) 10 / 17 7. Programming 7.1 Programming with a PC/Laptop Initial programming must always be carried out with the desktop software. Please note the following points: The latest version of LSM 3.3 or newer must be installed on the PC/ ... -
Page 11: Programming With Netbook/Touchbook
7. Programming SmartCD.MP (Manual) 11 / 17 1. Remove the lock from the packaging. 2. Position the SmartCD.MP on the card reader of the locking device. 3. Start programming in the software. 7.2 Programming with netbook/touchbook The latest version of LSM 3.3 or newer must be installed on the PC/laptop. In addition, LSM Mobile 3.3 or newer must be installed and set up on the netbook/touchbook. -
Page 12: Meaning Of Led Signals
8. Meaning of LED signals SmartCD.MP (Manual) 12 / 17 8. Meaning of LED signals LED 1 (green) Lit → Device ready for operation Lit → Device is communicating with LED 2 (green) the SV lock LED 3 Not used LED 4 Not used... -
Page 13: Technical Specifications
9. Technical specifications SmartCD.MP (Manual) 13 / 17 9. Technical specifications Housing dimensions H x W x D: 112 x 63 x 22 mm Weight: 52 g Housing material: Plastic Housing colour: Grey Number of LEDs: Protection rating: IP20 Mini USB (supplied cable: USB-A to USB port: mini-USB) Working temperature range:... -
Page 14: Declaration Of Conformity
10. Declaration of conformity SmartCD.MP (Manual) 14 / 17 10. Declaration of conformity The company SimonsVoss Technologies GmbH hereby declares that the articles (SMARTCD.MP) comply with the following guidelines: 2014/53/EU -RED- or for the UK: UK statutory 2017 No. 1206 -Radio equipment- 2011/65/EU -RoHS- ... -
Page 15: Help And Other Information
Our technical support will be happy to help you (landline, costs depend on provider): +49 (0) 89 / 99 228 333 Email You may prefer to send us an email. support-simonsvoss@allegion.com FAQs You will find information and help in the FAQ section: https://faq.simons-voss.com/otrs/public.pl... - Page 16 11. Help and other information SmartCD.MP (Manual) 16 / 17 Address SimonsVoss Technologies GmbH Feringastr. 4 D-85774 Unterfoehring Germany...
