- Page 1 Opendor IF-281 Cylinder OF-281-0xxxx...
-
Page 2: Table Of Contents
Table of Contents General information......................Short description....................... Scope of delivery ...................... Intended use ......................Target group ......................Safety........................Installation and programming .................... Installation......................... Configuration ......................Operation ..........................Opening doors ......................Activating/deactivating the permanently open mode ..........Maintenance, cleaning, and disinfection ................Battery replacement.................... -
Page 3: General Information
1 General information 1 General information 1.1 Short description IF-281 Cylinder is the ideal solution for cost-effective, uncomplicated and wireless compliance with current security standards for a wide range of applications. The electronic lock cylinder offers stability through precisely manufactured mechanics and electronics as well as highest data security through the integrated Secure Element. -
Page 4: Scope Of Delivery
1 General information Self-locking: Same as standard version, but the cam is brought back into the basic position by a return spring so that the lock can be pressed shut without identification medium. A version for installation in lever handles is available. The following aspects should be taken into consideration for doors along rescue routes which have been installed after April 1, 2003 (locks as per DIN EN 179 or DIN EN 1125): All cylinders of the IF-281 Cylinder series may be used for all locks that have an approval that... -
Page 5: Intended Use
1 General information 1.3 Intended use The devices of the series IF-281 Cylinder are installed into door locks to integrate them into an access control system. IF-281 Cylinder is available in different lengths. The dimensions are printed on the packaging. The dimensions for the outer or electronic side and the inner or mechanical side have to be measured separately. -
Page 6: Installation And Programming
2 Installation and programming Batteries DANGER Risk of poisoning from swallowing button cells This product contains lithium button cells. If button cells are swallowed, they can cause severe internal burns within a few hours and can lead to death. Keep new and used batteries away from children. If the battery case does not close securely, do not use the product anymore and keep it away from children. -
Page 7: Operation
3 Operation The software DoorManager and the technical manual can be found on our FTP server: https://ftpservice.interflex.de user: CD-Software password: 14gBD00ktH96 Opendor components Technical manual for IF-4041 Gateway IF-6040 Online help The technical manual can be found on our website: https://interflex.com/de-de/services/wissenszentrum/ 3 Operation The following sections describe the basics of operation. -
Page 8: Activating/Deactivating The Permanently Open Mode
3 Operation Visual signal Audible signal Description Reading error Credential unauthorized, details can be found in DoorManager under DiagnosticsDiagnostic card (Opendor ) or in IF-6040 under Access > Access management > NoC readers > Information > Last bookings (Opendor If you are using a credential with the Permanently open function, only hold the credential in front of the reader unit as long as the LEDs are flashing. -
Page 9: Maintenance, Cleaning, And Disinfection
4 Maintenance, cleaning, and disinfection The component indicates the Permanently open On log file entry: 3 x green Standard + Permanently open Green Permanently open Deactivating the permanently open mode Hold the credential to the reader unit for more than three seconds The component indicates the Not permanently open log file entry: 3 x green, 1 x red Standard + Permanently open... - Page 10 4 Maintenance, cleaning, and disinfection Description Visual signal Audible signal Stage 1 Stage 2 Stage 3 We recommend changing the battery at stage 2. If the batteries are empty, LED signaling and bookings are no longer possible. NOTICE Damage due to improper handling of the batteries Improper handling of the batteries may damage the components and shorten the battery life.
-
Page 11: Opendor Card Only: Factory Reset (Cold Boot)
4 Maintenance, cleaning, and disinfection 12. Snap the antenna bracket into place on both sides 13. Put on the knob cover (align the three triangle marks as in the diagram) and fasten by turning it about 10 ° in a clockwise direction 14. -
Page 12: Opendor Air Only: Unpair
5 Technical specifications Procedure 1. Log in to DoorManager with Facility card or Site/Installation mode 2. Click the cold start button The component indicates that the cold boot was successful: Purple (approx. 7 sec.), orange (short), red (approx. 1 sec.) 4.3 Opendor only: Unpair Press the reset button for more than 8 seconds Component and IF-4041 Gateway are unpaired... -
Page 13: Disposal
6 Disposal Frequency range/Transmitting RFID (13,56 MHz): 13,553 MHz to 13,567 MHz/ power < 42 dBµA/m (dist. 10 m) ® Bluetooth 5 (2,4 GHz): 2,400 GHz to 2,4835 GHz/ < 10 mW Installation type Indoor and outdoor areas, suitable for fire protection and escape doors Signaling Audible: buzzer Visual: color LED... -
Page 14: Declarations Of Conformity
The original manual is in German. Other languages are translations of the original manual. Version: 02.23 Interflex Datensysteme GmbH +49 711 1322 - 0 Epplestraße 225 (Haus 3) interflex.info@allegion.com 70567 Stuttgart, Germany www.interflex.com © 2023 Interflex Datensysteme GmbH | All specifications are subject to change without notice.
