ZOE C215L-A-EU User Manual
All in one li-ion energy storage system
Hide thumbs
Also See for C215L-A-EU:
- Quick installation manual (7 pages) ,
- User manual (30 pages) ,
- Quick installation manual (10 pages)
Related Manuals for ZOE C215L-A-EU
Summary of Contents for ZOE C215L-A-EU
- Page 1 All in One Li-ion Energy Storage System User Manual Product Model: C215L-A-EU Energy for life...
- Page 2 General information Note: Maintenance personnel are required to hold a qualified electrician's certificate issued by the Safety Supervision Bureau or be authorised by the ZOE to carry out maintenance work. WARNING: It is strictly forbidden to touch the high voltage positive and negative posts of the energy storage system with both hands at any time.
- Page 3 specified below. At the extremes of this temperature range, the cabinet may limit the charging or discharging power to extend battery life. charge temperature -20~55°C discharge temperature -20~55°C Maintenance and cleaning If installed outside, please keep the sides of the energy storage cabinet free of leaves and other debris to maintain optimal airflow.
-
Page 4: Table Of Contents
Contents Safety requirements and accessories list 1. Product description ·························································································· P06-P07 1.1 Applicable products ······························································································ P06 1.2 Main functions ······································································································ P07 2. Product Overview ····························································································· P07-P10 2.1 Product structure ································································································· P08-P09 2.2 Product specification parameters ········································································ P10 3. Transportation and storage ··············································································· P10-P12 3.1 Transportation ······································································································... - Page 5 5. Usage Instructions ···························································································· P18-P21 5.1 Energy storage cabinet temperature characteristics ··········································· P18 5.2 Cable connection confirmation ············································································ P18 5.3 Checking equipment switching status ································································· P18 5.4 Powering up the electrical cabinet ······································································ P19 5.5 Charging energy storage cabinet ········································································· P19-P20 5.6 Discharge energy storage cabinet ········································································...
-
Page 6: Product Description
1. Product description 1.1 Applicable products This manual applies to the following products models of energy storage cabinet: C215L-A-EU Throughout this manual, unless otherwise indicated, references to " energy storage cabinets" are also references to the above-mentioned series. Cabinet overall schematic weights 2450±50kg... -
Page 7: Main Functions
1.2 Main functions The battery system detects the battery operating status (voltage, current, temperature, SOC, etc.) and regulates battery charging and discharging according to the current state of the battery and the actual performance of the electrical components. The Battery system has high voltage sampling and fuse and other safety devices status recheck function, when the battery failure occurs the system will report and limit the charging and discharging current or power, the contactor disconnects, in order to protect the safety of the power system. -
Page 8: Product Structure
2.1 Product structure Front view Rear view Top view Left view Product External Schematic [A] - Operation status indicators [F] - Forklift hole [B] - Emergency stop [G] - Liquid Chiller Exhaust Vents [C] - Door lock [H] - PCS vent, containing 3 fans [D] - Air inlet for liquid cooler [I] - Side cable entry hole [E] - PCS bin air inlet... - Page 9 Product internal schematic [K] - Thermal aerosol fire extinguishers [L] - Product nameplates [M] - Smoke detectors for fire detection [N] - Temperature-sensitive fire detectors [O] - High voltage control box [P] - Battery modules [Q] - EMU control box [R] - Liquid-cooling piping [S] - Liquid cooler [T] - Power box...
-
Page 10: Product Specification Parameters
2.2 Product specification parameters Product Specification Product model C215L-A-EU Battery cell brands CATL (280Ah LFP) Product dimensions (W*D*H)1399 mm *1344mm *2080 mm Cooling/heating management Intelligent Liquid Cooling / Liquid Heating Weights Approx. 2450 kg Installation Outdoor floor-standing installation AC voltage: 400Vac ,3P+N+PE... -
Page 11: Storage
3.1.2 Energy storage cabinet transportation process Requirements (1) Pre-loading inspection of energy storage cabinets ① Check the information of the outside package and labels of the goods before loading, to ensure that the outside package of the goods is complete. (2) energy storage cabinet loading ①... -
Page 12: Installation
shipped from the factory. Capacity verification tests and re-inspections are required every 12 months. 4. Installation Energy storage cabinet is a high-voltage energy storage equipment, belonging to dangerous materials, non-professionals and improper operation and use may cause electric shock, combustion, explosion and other serious consequences. The installation and maintenance of the cabinet must be operated by certified professional technicians, and the relevant safety regulations must be strictly observed when using the cabinet. -
Page 13: Preparation For Installation
4.2 Preparation for installation 4.2.1 Unpacking The unpacking procedure is as follows: 1. Remove the wooden box top cover; 2. After removing the front and back boards separately, remove the bag and remove the desiccant; 3. Use a spanner to unscrew the screws (4) on the wooden pallet and remove the gasket; 4. -
Page 14: Site And Environmental Requirements
Do not use cleaning solvents to clean the cabinet or expose the cabinet to flammable or irritating chemicals or vapors. Do not use the parts or accessories which are not authorized by ZOE. Shoulder-to-shoulder interval between cabinets ≥ 30mm, back-to-back interval ≥ 600mm,... -
Page 15: Installation Steps
more than 300mm, and the coefficient of compaction should be more than 0.97. The side of the refilling layer should be beyond the foundation boundary line for 300mm, and the characteristic value of bearing capacity should not be less than 100Kpa, the particle content of particle size less than 0.75mm should not be more than 10%. -
Page 16: Electrical Connections
at 65~75N.M. D. Recommended use of chemical anchor bolts for fixing requirements: 1) Prior to chemical reinforcement, the flourish layer of the reinforcement needs to be cleaned off and flushed out before proceeding to the next step. 2) The concrete strength class is C30, and the chemical reinforcement needs to be tested for pull-out resistance. -
Page 17: Connection Considerations
Disconnecting switch ‘SWITCH’ and ACB QF1 & QF2 & QF3 are OFF. The lead-in cable is brought in from the bottom of the cabinet and connected to the PCS input terminals A/B/C/N, the mounting torque of the terminal screws is 18-22 N.M; PE is connected to the earthing copper bar, the mounting torque of the terminal screws is 8-10 N.M. -
Page 18: Usage Instructions
[Note] ZOE will not be responsible for any damage to the cabinet or any other loss caused by the usage of the cabinet that is not in accordance with the specified requirements or exceeds the specified range. -
Page 19: Charging Energy Storage Cabinet
5.4 Powering on the energy storage cabinet First confirm the external 400V AC power access, after closing the external circuit breaker, the PCS power indicator lights up. Close the disconnecting SWTICH of high-voltage control box, press the secondary circuit power button of the high-voltage control box, the button indicator red light is on, the front door operation status indicator light is on, at this moment the system is powered on. -
Page 20: Discharge Energy Storage Cabinet
Secondary circuit button Operation status system status PCS indicator ● indicator ● indicator ● Charge Red light always on Green light always on Green light breathing 5.6 Discharging energy storage cabinet After the power on the primary circuit of the cabinet is completed and the discharge command is executed, the PCS controls the cabinet to enter the discharge status, (the BMS detects the discharge current) the cabinet discharges externally, and at this time, the combination of each indicator status will correspond to the following status:... -
Page 21: Explanation Of Terms
5.8 Troubleshooting Malfunctions Possible causes and troubleshooting measures · No power supply > Check cable protection switches, and please switch on if Power indicator is off necessary. > If damaged, please contact your service partner. · Equipment communication failure > Check the wiring of the accessed equipment if they are of short circuits, broken, or of disconnections. -
Page 22: Function Of The Disconnecting Switch
Appendix 2) and keep a record of the inspection. Maintain battery on the energy storage cabinet every three months to prevent damaging battery, please refer to section 6.6 for specific maintenance operation. Before the first usage of the energy storage cabinet unused for long time, in order to activate the cabinet, please fully charge it once minimally, to restore the performance of the battery to the best condition. -
Page 23: Maintenance Requirements Of Liquid-Cooling Systems
6.7 Maintenance requirements of liquid-cooling systems If fluid leakage occurs inside the energy storage cabinet, please shut it down and contact the ZOE for service. Check the liquid level in the liquid cooler, if there is no liquid level (the red is coolant), that is, you need to add liquid, contact operation and maintenance personnel to replenish liquid. -
Page 24: Fire Protection System Maintenance
6.8 Fire Protection System Maintenance Aerosols have a service life of 15 years and require maintenance replacement every 15 years. Monthly inspections of temperature and smoke sensors. Open the cabinet door, input low voltage to the energy storage cabinet, observe that the temperature and smoke sensor indicator flash every few seconds, that is, the normal working status. -
Page 25: Electrical Earthing System Inspection
6.10 Electrical earthing system inspection Monthly routine inspection of the earthing system crimp whether corrosion, oxidation and cause poor contact, resulting in increased earthing resistance phenomenon. Whether the earthing mark is complete and obvious, there is no loss or damaged phenomenon. The earthing of electrical equipment should be checked annually to ensure that the earth cable and earth terminals are in good condition. - Page 26 Appendix 1 Layout of different energy storage cabinets Note: The installation location environment must meet the total air volume ≥ 2260 m³/h.
