IMPORTANT: To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS, located in
your appliance's Owner's Manual, before operating this appliance.
Control panel appearance may vary depending on your model.
Cycle Guide
This information covers several different models. Your dishwasher may not have all of the cycles and options described.
Cycles:
Descriptions:
Sensor
A cycle that calibrates the dishwasher to use the optimal wash cycle to
clean dishes, detecting changes in water temperature. A turbidity sensor
monitors water clarity and a microprocessor adjusts the water temperature
to match the dish soil level.
Cookware
Cookware/Bakeware cycle uses the added amount of water and heating
temperature for hard-to-clean, heavily soiled pots, pans, casseroles, and
regular tableware.
Normal
This cycle is recommended for daily, regular, or typical use to completely
wash and dry a full load of normally soiled dishes. This dishwasher's
government energy certifications were based on the Normal cycle with
only the Door Open Dry option selected.**
Crystal
A selectable wash cycle that lowers wash temperature and intensity to
protect your dishes.
Rapid
A wash cycle for dishes with light soil, especially useful when entertaining.
Refresh
Pre-rinse dishes without detergent when you are not planning to
immediately run a full wash load. Or, refresh clean dishes before guests
arrive.
NOTE: Do not use detergent.
**No other washing and drying temperature options were selected, and the dishwasher was not subjected to truncated testing. Rinse aid
was not used, and there was no detergent used in the prewash.
NOTE: More water can be used if higher soil levels are detected in all cycles.
Option Guide
Options:
Descriptions:
Top 2 Rack
Prioritized wash time to provide superior cleaning in the
Wash
upper racks.
Extended
Dries dishes with extra heat during rinse. For best
Dry
performance, use Extended Dry with rinse aid and door
opening system.
Dishwasher Cycle and Options Guide
Soil Level:
All Soil Levels
Heavy/Baked
On
Light to Normal
Light
Light to None
All Soil Levels
Can Be
What It Does:
Selected
With:
Sensor
Not applicable
Cookware
Normal
Crystal
Available with
Raises
any cycle
temperature
for the final
rinse to
improve dry
performance.
Water
Estimated
Wash Time
Usage
(Hr:Min):
Gallons
(Liters):
1:55
4.2
(15.8)
2:25
7.3
(27.5)
2:15
2.4 (9.1)
2:00
4.2
(15.8)
1:05
4.8 (18)
0:27
2.7
(10.3)
Added
Water
Time to
Usage
Cycle
Gallons
(Hr:Min):
(Liters):
0:49
0
0:23–0:25
0
1
